Table of Contents PAGE Installation instructions -Mounting the tank Installation of wiring harness -Wiring diagram Installation of blower band and nozzle assembly Operation instructions -General application chart -Recommended tip for water lubrication Maintenance Parts breakdown Warranty liability...
Installation Instructions Mounting the Tank Begin by bolting the frame legs to forage harvester’s tongue using the 5/8” U-bolts and nuts. The legs with the pump should be attached toward the back and the legs without the pump towards the front.
Installation of Wiring Harnesses Connect the pump wiring harness to applicator switch assembly wiring harness. In the tractor, plug Connector A (see diagram below) directly to the chopper controls if you have a 1085 or 1285 chopper. The chopper control box will supply power and will put the applicator on pause when running in AUTO mode when hooked to Connector A.
Operation Instructions For 1285 and 1085 choppers, the switch in the cab allows the operator to run in manual or automatic modes. In automatic mode, the sprayer will be on unless the feed-roll switch is tripped, which will turn the sprayer off. For all other choppers, the switch will have to run in manual mode, where the sprayer will be on at all times until turned off.
MODEL 655G APPLICATOR Description Part# Description Part# Tank 005-9205 Left saddle leg 001-4703AGL Tank lid 005-9022D Pump 007-4120D Tank straps 001-4402 Elbow fitting 003-EL3812 Tank saddle 001-4701 Tank fitting 005-9100 Right saddle leg 001-4703AGR Not pictured Description Part# Description Part#...
