OWNER'S MANUAL
Model 239DM
Dye Sprayer Marking System
Accessory upgrade to CNH DIA Moisture kits 439618, 48189657, & 90420182
Forage Harvester
239DM - 20
5/21
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 239DM and is the answer not in the manual?

Questions and answers

Related Manuals for Harvest TEC 239DM

Summary of Contents for Harvest TEC 239DM

  • Page 1 OWNER’S MANUAL Model 239DM Dye Sprayer Marking System Accessory upgrade to CNH DIA Moisture kits 439618, 48189657, & 90420182 Forage Harvester 239DM - 20 5/21...

  • Page 2: Table Of Contents

    Congratulations on purchasing a Harvest Tec Dye Sprayer Marking System. When attached to a DIA star wheel moisture sensor for Case/New Holland large square balers the 239DM allows you to visibly mark the wet areas on your bales. The system includes the tank, pump, plumbing, mounting hardware and necessary harnesses.

  • Page 3: Installation Of Dye Sprayer Tank & Plumbing

    Installation of Dye Sprayer Tank & Plumbing Installation of Mounting Bracket & Tank – CASE & New Holland Large Squares Locate the tank and mounting bracket assembly. Looking at Figure 1 decide where a desirable mounting location will be the most convenient and work the best for the user. a.

  • Page 4: System Wiring

    System Wiring Diagram ptional tablet displa with use recision aling stem iring iagram moisture module is removed rom and connected to aler...

  • Page 5: Installation Of Plumbing

    Installation of Plumbing To most effectively mark the wet spots in any bale, Harvest Tec recommends that the nozzles are mounted directly above or below the Star Wheels. To get the best spray pattern focused directly on the wet spot of the bale the nozzles will need to be approximately 1” above the bale that is being marked.
  • Page 6 Installation of Plumbing (continued) 4. Install the tip and nozzle holder assemblies in the suggested locations pictured shown below. se the 1/ ” hardware provided to do so. a. Make sure that the tip assemblies (A) are mounted in line with the star wheels (B) so that the system is marking the wet spots of the bale.

  • Page 7: Plumbing Diagram

    Installation of Plumbing (continued) Plumbing Diagram Figure 3 Tank 005-9019 Hose Barb Tee 3/8” Hose 003-T3838 002-9003AS Pump 007-4120LF Drain Valve 002-2216 Brass Tip Common Question 004-TX-5 1. Is the marking dye safe for livestock consumption? The Dye Marker uses red-colored, food-grade dye and is safe for all livestock. 2.

  • Page 8: Baler Display Integration

    Baler Display Integration Case LB334/434 & New Holland Big Baler Series (MY2020 and Prior) (continued) The ISOBUS Monitor utilizes touch screen options to make selections. Selections are made by finding the desired selection and pressing the touch screen icon. All buttons are labeled and color coded. When the moisture system is connected thru the baler CAN1 and powered on the first time it is necessary to load the object pools to the Virtual Terminal (VT).
  • Page 9 Case LB334/434 & New Holland Big Baler Series (MY2020 and Prior) (continued) Icon (1) indicates that the object pools are in the process of loading and saving to the VT. Note that if the language selection of the VT is changed, the corresponding object pool must be reloaded to the VT. The object pool loading process takes approximately two minutes to complete.
  • Page 10 Case LB334/434 & New Holland Big Baler Series (MY2020 and Prior) (continued) Scroll through the Menu bar until the INFORMATION icon (5) is visible. Press the INFORMATION button so the Information page appears. Verify that the controller software loaded to the baler is version 4.2.0.0 or higher.
  • Page 11 Case LB334/434 & New Holland Big Baler Series (MY2020 and Prior) (continued) Once Dealer Mode has been entered, select the down arrow in the Menu Bar (9) to scroll to the second ealer ode creen where ‘ oisture’ is a selection. nce ou have reached the second ealer ode screen, select the area under ‘...
  • Page 12 Case LB334/434 & New Holland Big Baler Series (MY2020 and Prior) (continued) Once the configuration has been set press the MACHINE SETUP icon (12) to return to the Machine Setup Screen and the Menu Bar. Press the arrow down button at the bottom of the Menu Bar (13) to scroll down thru the Menu Bar until you reach the SCREEN SETUP pages.
  • Page 13 Case LB334/434 & New Holland Big Baler Series (MY2020 and Prior) (continued) Selections related to the moisture system include “Moisture” and “Moisture Bale” and are highlighted by arrows above and in the next picture. Scroll to additional options in the popup window by pressing the down arrow on the side of the popup window (15).
  • Page 14 Baler Work Screen. Cycle back and forth between the Baler Work Screen and the Moisture System Work Screen by pressing the NEXT IMPLEMENT button (19) during operation. Harvest Tec Icons signified by arrows 19-22 are as follows: (19) Next Implement Button...

  • Page 15: Case Lb436Hd & My2021 And Later Lb4 Series

    Baler Display Integration Case LB436HD & MY2021 and later LB4 Series New Holland 340/1290HD & MY2021 and later Big Baler Series Follow the steps below to setup the integration of the Moisture System into the baler display. 1. Select the baler Setup tab in the top right corner of the baler run screen. 2.
  • Page 16 Case LB436HD & MY2021 and later LB4 Series New Holland 340/1290HD & MY2021 and later Big Baler Series (continued) 3. On the System Information page press and hold the first blank square box under the down arrow on the right side of the screen for 10 Seconds. ter 1 seconds the irst screen below will appear prompting ou or a code.
  • Page 17 Case LB436HD & MY2021 and later LB4 Series New Holland 340/1290HD & MY2021 and later Big Baler Series (continued) 5. Select the baler Setup tab in the top right corner of the baler run screen. Then press Machine Configuration from the baler setup page (wrench icon at top). 6.
  • Page 18 Case LB436HD & MY2021 and later LB4 Series New Holland 340/1290HD & MY2021 and later Big Baler Series (continued) The current bale moisture content will now display above the baler next to the water droplet and the previous bale moisture will display next to the bale in above the are above the bale chute (below).

  • Page 19: Display Options

    Optional Baler Tablet Integration The 700 series is easily integrated into the CNH Baler VT. This allows the operator to monitor both real time baler settings and Harvest Tec system parameters on one screen to ensure the most precise application to every bale.

  • Page 20: Operation Of Tablets

    Operation of Tablets Turn On/Off Tablet using the Sleep/Wake button iPad Turn iPad ON: Hold down the Sleep/Wake button until Apple logo appears. iPad will take a moment to load. You can lock iPad and put it to sleep when you are not using it. Locking iPad puts the display to sleep, saves the battery, and prevents anything from happening if you touch the screen.
  • Page 21 5. Select app store icon (below) and open. *You will need a Wi-Fi connection available to download app* iPad Android ownload the recision aling pp in the app stores b searching or ‘Harvest Tec’ in the search bar: *The advertisements displayed on the screens will change.* The app will have the icon as shown:...
  • Page 22 ISO Communication Module Once app is installed, operate the applicator by connecting the tablet lightning cable to the USB port. ISO Communication Module Blinking Green Light – Module is connected and ready to operate. *Recommended to use the original USB cable included with tablet Shutting Down the Precision Baling App iPad 1.
  • Page 23 Android 1. To shut down the Precision Baling App click the recent button. This will show the open apps that are running on your tablet. *Note: By pressing the home button to return to the home screen, the Precision Baling App does not shut down.

  • Page 24: Operating The Harvest Tec 700 Series System

    Operating the Harvest Tec 700 Series System (Designed for Automatic Preservative Application – not all features are utilized with the Moisture Dye Marker) The 700 series display is broken down into four main categories: ▪ Top: Status Messages ▪ Bottom Center: Current Job Summary Information ▪...
  • Page 25 Operating the Harvest Tec 700 Series Applicator (continued) Current Job Summary Boxes J) RFV - Last Bale: Displays the RFV reading for the last bale made. - Average: Displays the average of all RFV readings for the current job. K) Job Totals - Bales: Displays the total number of bales made for the current job.
  • Page 26 Screen Menus (screens shown in Precision Baling App using tablet display) Use the screen shots below to navigate through the operation screens. Note – not all functions utilized with operation of moisture dye marker. Automatic Mode Manual Mode...
  • Page 27 Setup Mode Adjusting Moisture Levels Select and change input boxes / sliders as needed Adjusting Baling Rate Adjusting Application Rate Select and change input boxes / sliders as needed Select and change input boxes / sliders as needed...
  • Page 28 Job Records View Job List View Current Job List View Selected Job List...
  • Page 29 Create a New Job v Software Versions Select Job Details to view job records Press Create Job Select and fill out blank input boxes as needed Software Versions...
  • Page 30 Moisture System with Dye Marker Object Pool Setup (screens shown in Precision Baling App using tablet display) Service - Sensors screen Set the module in which moisture readings are displayed in Select SENSORS SERVICE menu Required - Update Moisture sensor selection to IDM (ISO Dye Module) Select Rate Sensor and choose Manual Set the baler sensors utilized from ISOBUS Select Bale Tie Sensor and choose ISO.
  • Page 31 Within BALING RATE SETUP customize Moisture Alarm Turn ON Moisture Dye Marking. Customize set point moisture Setpoint for dye marker to spray when moisture is above threshold Dye Marker can be manually primed from either this screen or button located on dye marker. Note – prime dye marker upon each refill.

  • Page 32: Filling Tank & Start Up

    Filling Tank & First Time and Annual Startup 1. Filling the Tank A. Remove the tank lid from the 3 gallon tank. Make sure the tank is clean and completely empty. Mix the Dye (009-0800) with warm water inside the Dye bottle. Make sure that the bottle is shaken vigorously so that the dye completely dissolves.

  • Page 33: Pin Outs

    Pin Outs Integrated Control Module (ICM) on harness 006-765IC (Deutsch Plug Number: DTM06-12SA) Pin 1 +12V from ECU Pin 2 Purple Signal Wire Pin 3 Red/White +12V CAN X Pin 4 Black/White Ground CAN X Pin 5 Orange CAN X Hi Pin 6 Blue CAN X Lo...
  • Page 34 Power / Communication Harness 006-765BN at Baler Hitch (Deutsch Plug Number: HDP26-24-18SN) Pin 1 Not Used ---- Pin 2 Yellow ISO CAN Hi Pin 3 Green ISO CAN Lo Pin 4 +12V Power to ECU Pin 5 Black Ground to ECU Pin 6 Not Used ----...
  • Page 35 Key Switch Harness 006-765CPH at Tractor (Deutsch Plug Number: DT06-4S) Pin 1 +12V from ECU Pin 2 Not Used ---- Pin 3 Not Used ---- Pin 4 Black ISO CAN Lo Pump Plug Harness 006-765IDM2 (Deutsch Plug Number: DT04-3P-L012) Pin 1 Black/White Ground to End of Bale Sensors Pin 2...
  • Page 36 ISOBUS Plug on harness 006-7307CMS (Deutsch Plug Number: DT04-4P and DT06-4S) Pin 1 +12V from ECU Pin 2 ISO CAN Hi Pin 3 Ground from ECU Pin 4 ISO CAN Lo Prime Switch Plug on Harness 006-7307CMS (Deutsch Plug Number: DT06-3S) Pin 1 +12V to Pump Pin 2...

  • Page 37: Parts Breakdown

    Tank Cap Gasket 005-9022CG Integration Harness 006-765VN Baler Harness 006-765BN Key Power Switch 006-765CPH Dust Plug Kit 006-765DP Tractor Harness 006-765IC 239DM ext harness 006-765IDM3 Description Part# Nozzle Holder 001-4216 Straight Fitting 003-A1438 Quick Connect 004-1207H Rubber Gasket 004-1207W Tip Screen...

  • Page 38: Warranty

    Harvest Tec, Inc. within 30 days of the failure. If it is determined that a non-Harvest Tec branded hay preservative has been used inside the Harvest Tec applicator system where the failure occurred, then Harvest Tec reserves the right to deny the warranty request at their discretion.
