HMS Networks Ewon COSY 131 Quick Start Manual

USR LED :
for Ewon COSY 131
Step 1: Create & configure your Talk2M account
Download and install eCatcher.
Create your account by clicking on "Create a Free+ Account".
To complete the process, you will need to activate your
account by clicking on the URL sent by email.
Log into eCatcher and add your Ewon Cosy by clicking on the
"Add" button. Follow the dialog boxes to personalize & identify
easily your Ewon Cosy
Insert a USB stick/SD card and click "Launch Setup Wizard".
Once files are on your USB stick/SD card,
close the eCatcher application.

Step 2: Configure your Ewon Cosy

Power ON your Ewon Cosy
Plug the Internet cable into the WAN port.
By default, the WAN port is the No. 4, on the bottom left.
You can check it with the red led (instead of green) beneath
the Ethernet port.
When the PWR LED is green & the USR LED is blinking green,
insert your configured USB stick/SD card into your Ewon Cosy
USR LED will start a quick orange pattern to indicate that a valid
file has been detected.
Quick Start Guide
