Xilin CDDR Operation Manual page 34

1，4
Static Return To Off
2，1
Throttle Wiper High
2，2
EMR Wiring Open
2，3
High Pedal Disable
2，4
Throttle Wiper Low
3，1
Multiplexer Fault
3，2 Main Contactor
Precharge
3，3
Brake Fault
4，1
Service Total Disable
Service Driver Disable
Service Total Expired
Service Driver Expired
Battery Over voltage
4，2
Battery Under voltage
4，3
Temperature Cutback
SRO sequencing error
Accelerator voltage is too
high.
EMR wiring fault
HPD
Accelerator voltage is too
low.
Multiplexer malfunction
Misssing or welded main
contactor.
Precharge fault
Electromagnetic brake fault. 1 Brake coil shorted or open.
Total KSI timer has expired. Expired total KSI timer.
Total driving timer
expired.
Setted (KSI) service timer
has expired.
Setted (driver) service timer
has expired.
Battery voltage is too high. Battery voltage is too high.
Battery voltage is too low.
Controller heatsink is too hot
or too cold.
1 Improper
KSI,INTERLOCK,F/R
2 Wrong SRO type selected.
3 Direction switch malfunction.
4 Sequencing delay too short.
1 Accelerator is damaged.
2 Wrong accelerator type selected.
1 EMR wire or check wire broken.
1 Incorrect sequence of accelerator and
KSI,INTERLOCK.
2 Wrong HPD type selected.
3 Accelerator malfunction
4 Key switch and INTERLOCK power-off.
5 Sequencing delay too short.
6 Wrong accelerator type selected.
1 Accelerator is damaged.
2 Wrong accelerator type selected.
Multiplexer malfunction
1 Main contactor coil open.
2 Main contactor stuck closed
3 Welded main contactor
4 Main contactor driver shorted.
1 Controller defective.
2 Low battery voltage.
2 Brake driver fault.
has
Total driving timer has expired.
Setted (KSI) service timer has expired.
Setted (driver) service timer has expired.
1 Battery voltage is too low.
2 Corroded battery terminal.
3 Storage battery is damaged.
1 The power of controller is small.
2 Excessive load on vehicle fo a long time.
3 Abstraction of heat is bad.
sequence of
