Xilin CDDR Operation Manual page 10

1.1 Manufacturer(abbreviated)
1.2 Model
Driving model ： Electric(Storage battery), diesel,
1.3
gasoline, fuel gas
Driving model（Manual, Walking, Stand driving, seat
1.4
driving ,Order picking）
1.5 Rated load
1.6 Load center distance
1.8 Front overhang
1.9 Tread
2.1 Service weight(with battery)
2.2 Axle load, front/rear, laden
2.3 Axle load, front/rear, unladen
Wheels (rubber, high elasticity, pneumatic tyre,
3.1
polyurethane wheel)
3.2 Wheel dimension, front
3.3 Wheel dimension, rear
3.4 Additional wheel(dimension)
Wheel number, front/rear （x = driving wheel）
3.5
3.6 Tread, front
3.7 Tread, rear
4.2 Height of mast, lowered
4.3 Free lift height( optional)
4.4 Lift height
4.5 Max. height of mast, extended
4.9 Min. /Max. height of operation handle in driving position
4.15 Height, lowered
4.19 Overall length
4.20 Length to fork face
4.21 Overall width of truck body
4.22 Fork dimension
4.25 Overall width of fork
4.32 Wheelbase ground distance
4.33 Aisle width, with pallet 1000x1200 crosswise
4.34 Aisle width, with pallet 800x1200 lengthwise
4.35 Turning radius
5.1 Traveling speed, laden/unladen
5.2 Lifting speed, laden/unladen
5.3 Descending speed, laden/ unladen
5.8 Max. gradeability, laden/unladen
5.10 Traveling brake
6.1 Driving motor power
6.2 Lifting motor power
6.4 Battery voltage/rated capacity
6.5 Battery weight
Battery dimension（LXWXH）
8.4 Noise level at operator's ear, according to DIN12053
1. Parameters relating to h1、l、Q shall be calculated according to h1=3000mm and l=1070mm.
CDDR Electric Pallet Stacker
Ningbo Ruyi
CDDR20-Ⅰ(highstandard） CDDR20-Ⅱ（standard）
Electric(storage battery)
walking
Q(kg) 2000
c (mm) 600
x
(mm) 697
Y
(mm) 1383
kg 1290
kg 1740/1550
kg 907/383
polyurethane
φ250×70
φ80×84
φ150×60
1x+1/4
b
(mm) 520
10
b (mm) 404/525
11
h
(mm) 1735/1985/2135/2235
1
h
(mm) 1300/1550/1700/1800
2

h (mm) 2500/3000/3300/3500
3
h
(mm) 2955/3455/3755/3955
4
h
(mm) 670/1300
14
h
(mm)
13
l (mm) 1950
1
l
(mm) 878
2
b (mm) 820
1
s/e/l(mm) 60/180/1070(1150)
b
(mm) 570/695
5
m (mm)
2
A
(mm) 2450
st
A
(mm) 2420
st
W (mm) 1575
a
Km/h 5.8/6
m/s 0--0.12/0--0.19
m/s 0--0.35/0--0.12
% 8/15
Electromagnetic brake
kW 1.6(AC)
kW
V/Ah 24/300
kg 300
mm 675×254×545
dB(A)
Ningbo Ruyi
Electric(storage
battery)
walking
2000
600
697
1383
1230
1710/1520
877/353
polyurethane
φ250×70
φ80×84
φ150×60
1x+1/4
520
404/525
1735/1985/2135/2235
1300/1550/1700/1800

2500/3000/3300/3500
2955/3455/3755/3955
670/1300
90 90
1950
878
820
60/180/1070(1150)
570/695
31 31
2450
2420
1575
5.8/6
0.11/0.20
0.12/0.12
6/10
Electromagnetic brake
1.2(AC)
3 3
24/240
240
675×254×500
65 65
6
