TUBESCA-COMABI RAPTOR 2272/182 Technical Instructions

Technical Instructions RAPTOR 2272/182 to 2272/185
Product in compliance with standard NF P 93-353 of 19 December 2016 for products with platforms less than 1.5m above floor level.
4
3
2
1
2 (without stabilizers)
3 (without stabilizers)
4 (without stabilizers)
5 (with stabilizers)
1. Product description
Lightweight Individual Mobile Platforms (P.I.R.L.) are used for interior finishing operations. These platforms are for use by just one
operator working from the floor.
Platforms are fitted with two non-swivel rollers used for positioning and transporting them.
Platforms are fitted with two independent adjustable stabilizers, only available on the 5-step model. The stabilizers hold the unit
perfectly securely, under the normal operating conditions recommended by standards.
2. Use
2.1. Assembly
1
1) Fitting side-feet for 3 and 4-
step models as per instructions
61029/356
4
Stabilisateur
Stabilizer
For product :
Modèle :
5 Steps
5
Marches
4) Put the stabilizers in position: untighten the knurled knob (5), then slide the stabilizer downwards until it touches the floor (6). Lock
the knurled knob (7) in place before using the product.
8
8) The guardrail is put in place by pushing the two tubes upwards.
Warning: ALWAYS check that the pins are correctly locked in position.
04 du 12/2017
61029_355_ind_
H
L1 (m)
0,52 0,96
0,71 1,1
0,95 1,25
1,18 1,41
2
2) Open the platform by lowering the floor.
The platform must be in contact with the
climbing section, the section with the steps.
5
http://www.tubesca-comabi.com/
Ht
Kg
L2 (m)
0,63 10,3
0,63 12,3
0,8 14,1
1,95 17,8
Anti-lift
6
Lg x Ht x Pf en m
Product Fol ded Up
Pf
Lg
1,78 x 0,6 x 0,34
1,97 x 0,83 x 0,34
2,23 x 0,83 x 0,34
2,47 x 0,6 x 0,34
3
3) unfold the brace
3) Déplier la sous lisse.
7
THE PIN
MUST BE
LOCKED IN
PLACE
Kg
Ma x: 150
VERROUILLER LOCK THE
WHEEL
LA MOLETTE
PAGE
1/2
