TUBESCA-COMABI EVOKLIP Operating Instructions

EVOKLIP roof ladder operating instructions
1. Description of the EVOKLIP roof ladder
The EVOKLIP roof ladder is comprised of a set of modular elements designed for working on roofs when doing jobs lasting less than one
hour: for longer operations, other types of equipment such as nacelles or scaffolding must be used.
A ridge hook must ALWAYS be used (supplied with references 725/733/739)
Reference
EVOKLIP PACK
02453 725
250 MM BETWEEN
EVOKLIP PACK
02453 733
330 MM BETWEEN
EVOKLIP PACK
02453 739
390 MM BETWEEN
2. Introduction
Since working on roofs is a high-risk operation, it is imperative to read these instructions before use.
Under no circumstances may the roof ladder be used as a substitute for a fall prevention safety element. A harness connected to a
lifeline firmly attached to the roof MUST ALWAYS be worn.
Planning interventions and rigorous preparation are essential for working safely, as is the use of equipment that complies with current
standards.
Using a roof ladder requires extreme care. In addition to the type of equipment used, multiple factors can contribute to or cause a fall from
a height (e.g., lack of personal protective equipment, awkward working postures, or unsuitable working methods).
Take account of the type of roof on which the ladder is going to rest as well as the type of work you are going to carry out.
3. Use
3.1 Before use:
- Make sure you are in sufficiently good form before using the roof ladder.
- Systematically check the ladder visually before using it to make sure that it has not been damaged and can be used in complete
safety:
- Check that the roof surface is flat, firm, stable, and non-slip:
- Use a safety harness attached to a solid anchor point:
- Clean the area around the ladder:
- Postpone the intervention in case of any adverse changes in the weather (wind, rain, snow, ice, etc.):
- Do not work close to any electrical power sources:
- Check that the roof is sufficiently resistant.
3.2 Installation:
61029_413_ind_01 dated 06/2018
Description Weight
23.5 kg
RUNGS
22.8 kg
RUNGS
20.6 kg
RUNGS
The ridge hook must ALWAYS be fitted. It must be assembled as per instruction leaflet 61029_414 to be found
in the screw bag.
http://www.tubesca-comabi.com/
Composition
4 LADDERS 02453 401
1 HOOK KIT 02453 413
4 LADDERS 02453 402
1 HOOK KIT 02453 413
4 LADDERS 02453 403
1 HOOK KIT 02453 413
Length: Distance
between rungs
6.1m 250 mm
6.7m 330 mm
6.3m 390 mm
