NavTool NAVRGB6.0-VI+GMIRC1 Installation Manual page 9

Installation Instructions
Step 11: Assemble the navigation headunit in reverse order of steps, staring from step 6 down to step 1.
Step 12: Connect both 10 pin connectors on the Interface harness and the Vehicle Specific Harness
LONG-RIB together.
Step 13: Cut off the Red (+12 Volts ACC) and Black (Ground) wires off of the 6-pin plug on the interface
harness.
Step 14: Connect the Red wire (+12 Volts ACC) to the Vehicle's factory accessory wire. (Ignition Switch)
Step 15: Connect the Black wire (Ground) to the Vehicle's factory ground. (Radio Ground)
Step 16: Connect the Orange wire (+12 Volt Reverse Input) to the Vehicle's factory reverse wire. (Rev. Light)
Step 17: Connect one wire of the push button to +12 Volt ACC power in the vehicle and the other wire to the
white manual activation wire on the interface harness. (Not required for installations with reverse camera only)
Step 18: Connect your aftermarket cameras/video inputs to Rear Camera Input/Video Input 1 and Front
Camera Input/Video Input 2 on the interface harness.
Step 19: Make sure both dip switches on the interface are facing UP in the OFF Position. Plug the interface
harness into the interface.
See Next Page for Quick Connection Diagram >
