Product description
3.1
Product design
1
1
Important components of a measuring device
1
Electronics compartment cover
2
Display module
3
Main electronics module
4
Cable glands
5
Transmitter housing (incl. HistoROM)
6
I/O electronics module
7
Terminals (spring loaded terminals, pluggable)
8
Connection compartment cover
9
Sensor
Endress+Hauser
3
2
9
5
4
Product description
6
8
7
A0020649
7
