4 zone wired intruder alarm system

Advertisement

4 Zone Wired Intruder
Alarm System
Installation & Operating Manual
PA4
CLEAR
24Hr
MAINS
Zone 1
Zone 2
Zone 3
Zone 4
1
2
3
ARM
4
5
6
OMIT
7
8
9
RESET
0
AWAY
ER
HOME
EXIT
1. Check all windows and doors are closed.
2. a) Fullguard - Press 'Away' then 'Arm'.
or b) Partguard - Press 'Home' then 'Arm'.
3. Leave premises by entry/exit route.
ENTRY
1. Enter premises by entry/exit route.
2. Enter your 4 digit password. If a mistake is
made re-enter the correct passcode.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PA4 and is the answer not in the manual?

Questions and answers

Alan MORGANS
July 27, 2025

How do i change the alarm code

Summary of Contents for FRIEDLAND PA4

  • Page 1 4 Zone Wired Intruder Alarm System CLEAR 24Hr MAINS Zone 1 Zone 2 Zone 3 Zone 4 OMIT RESET AWAY HOME EXIT 1. Check all windows and doors are closed. 2. a) Fullguard - Press 'Away' then 'Arm'. or b) Partguard - Press 'Home' then 'Arm'. 3.
  • Page 2 The PA4 Alarm System is designed for ease of 2. Before drilling holes in walls, check for hidden installation using only conventional domestic tools. cables and pipes. The use of a cable/pipe locator However, it is essential that the installer reads and fully may be advisable if in any doubt.
  • Page 3: Table Of Contents

    ALARM RECORD Wiring the Detection Zones TROUBLE SHOOTING INSTALLING THE PIR MOVEMENT DETECTORS Mounting the PIR Movement Detectors EXTENDING YOUR PA4 WIRED Wiring the PIR Movement Detectors INTRUDER ALARM SYSTEM Testing the PIR Movement Detectors at the Control Panel COMPONENT SPECIFICATION...
  • Page 4: Introduction & Overview

    INTRODUCTION & OVERVIEW The PA4 Alarm Package contains all components correctly and during this period they effectively necessary to install a complete system. The items generate an alarm signal to the Control Panel. included in your Package are shown opposite. The...
  • Page 5: Kit Contents

    KIT CONTENTS The PA4 Wired Intruder Alarm System contains the following components. CLEAR 24Hr MAINS Zone 1 Zone 2 Zone 3 Zone 4 OMIT RESET AWAY HOME EXIT 1. Check all windows and doors are closed. 2. a) Fullguard - Press 'Away' then 'Arm'.
  • Page 6: System Features

    Note 2: Zone(s) selected as ‘Walk Through’, cannot which are located on the Entry/Exit route and will also be selected to operate on the ‘HOME’ feature. operate the Entry/Exit timers and associated tones. PA4 Alarm...
  • Page 7: General System Programmable Options

    Duration time is 20 minutes, however this can be set to between 01 - 20 minutes, depending on individual requirements. Note: Most Local Authority noise pollution requirements set limits acceptable for alarm duration. You should therefore check your Local Authority requirements. PA4 Alarm...
  • Page 8: Planning The Installation

    When running the cable to the The Magnetic Contact Detectors are suitable for siren, the cable should pass through a hole in the mounting in dry interior locations only. external wall and enter through the rear of the casing. PA4 Alarm...
  • Page 9: Installation Example

    1. Enter premises by entry/exit route. 2. Enter your 4 digit password. If a mistake is made re-enter the correct passcode. Detector Bedroom 2 (Zone 4) (omitted during night setting) Bedroom 1 Landing Bedroom 3 TYPICAL FIRST FLOOR PLAN External Siren PA4 Alarm...
  • Page 10: Installing The Control Panel

    Wiring Terminal Blocks and Link Fixings Speaker Leads Keypad OMIT Bottom Cover RESET AWAY HOME Cover Cover Tamper Fixing Switch Screws Leads and Connectors for Bottom Fixing Mains Adaptor Optional Back-up Batteries Hole Socket Control Panel Internal Physical Layout PA4 Alarm...
  • Page 11: Wiring The Detection Zones

    Mains Adaptor Circuit Siren Power Supply Factory Links Note: Remove factory wire links before connecting circuit wiring. Leave the factory wire links in place where a zone/circuit is unused. Control Panel Schematic Wiring Diagram Showing Factory Links Fitted PA4 Alarm...
  • Page 12: Installing The Pir Movement Detectors

    PIR Sensor (Do Not Touch) metres Anti- Tamper Switch Distance (metres) Alarm metres 1 2 3 24HR Pulse 8° Tilt Count Jumper Link Cover Distance (metres) Retaining Retaining Connection Terminals Screw Clip PIR Detection Zone Patterns PIR Movement Detector PCB Layout PA4 Alarm...
  • Page 13: Wiring The Pir Movement Detectors

    4. If the PIR Movement Detector LED is operating, but wire links, then connect the wires to the terminals not activating an alarm, check that the relevant Zone wire link has been removed at the Control Panel. as shown in the diagrams on pages 13 - 15. PA4 Alarm...
  • Page 14: Typical Wiring Arrangements

    WHITE CONTACT BLACK BLACK YELLOW BLUE BLUE YELLOW WHITE Twist (or Solder) cable cores together GREEN and insulate Wiring diagram for PIR Detector and Magnetic Contact Detector on different zones with all cables returning to the Control Panel PA4 Alarm...
  • Page 15 Detector 1 Detector 2 Detector 3 Detector 4 Detector 1 Detector 2 Detector 3 Detector 4 Siren Tamper Connections Series wiring of zone connections from Series wiring of 24-hour connections multiple detectors on a single zone from multiple detectors PA4 Alarm...
  • Page 16: Installing The Magnetic Contact Detectors

    2. Carefully remove the outer sheath of the cable and then slot in the rear of the Control Panel and strip back strip 5mm of insulation from the Yellow and Blue wires. 5mm of each core and twist the strand ends. PA4 Alarm...
  • Page 17: Testing Magnetic Contacts At The Control Panel

    SIREN Contacts fitted. BRACKET 5. When the Magnetic Contacts have been tested SIREN successfully, press to return to the Standby RESET Mode. 6. Now disconnect the Mains Adaptor before CABLE continuing with the installation. ENTRY HOLE SIREN COVER PA4 Alarm...
  • Page 18: Wiring The Siren Unit

    Note: The Green and White Tamper circuit wires should be wired in series with the Green and White Note: Although optional, it is strongly tamper circuit wires from the detectors at the recommended that backup batteries are fitted. Control Panel terminal block. PA4 Alarm...
  • Page 19: Programming

    To change the setting proceed as follows: or Current Installer Access Code With the Control Panel already in the Installer The ‘Clear’ LED will flash to indicate that the system is programming Mode (‘Clear’ LED flashing), now in the Installer Programming Mode. PA4 Alarm...
  • Page 20: Entry Delay Time Adjustment

    RESET facility is not required. The system will return to the top level Installer To select the Zones to be configured as "Walk Through" Programming Mode with only the Clear LED flashing. zones proceed as follows: PA4 Alarm...
