MA2 - Window Alarm
Installation and Operating Instructions
These instructions should be retained in a safe place for future reference.
Kit Contents:
1 x Alarm Unit
4 x 1.5V A76 (LR44) Button Cells
(supplied fitted)
1 x Adhesive Pad
1 x Instruction Leaflet
1 x Window Sticker
Tools and Equipment Required:
None
INTRODUCTION
The Window Alarm is a vibration-
activated alarm that is fitted
directly to the glass of windows
(and doors).
caused by an impact on the
window or by someone forcing
open and breaking the window
will activate the alarm.
The vibration
Siren
Battery
Test
Switch
Battery Compartment
Cover
Safety: The use of ear protection
is advisable when working in close
proximity to the Siren due to the
high sound level produced
Battery
Status
Indicator
Lo
Hi
Off
Sensitivity
Selector
Switch
.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for FRIEDLAND MA2
Summary of Contents for FRIEDLAND MA2
- Page 1 MA2 - Window Alarm Installation and Operating Instructions These instructions should be retained in a safe place for future reference. Kit Contents: 1 x Alarm Unit 4 x 1.5V A76 (LR44) Button Cells Siren (supplied fitted) Battery Status 1 x Adhesive Pad...
- Page 2 INSTALLATION This alarm is suitable for mounting Note: Setting the alarm to Low in dry interior locations only. sensitivity will require a greater amount of vibration to trigger the 1) Fix the alarm in position on alarm but will make it less prone to the window glass using the false alarms.
- Page 3 To test the battery remove the not allow water to enter or battery cover and press the attempt to clean inside the unit. battery test button, if the battery Batteries: status indicator LED does not illuminate or is dim then the Do not allow batteries to corrode battery should be replaced.
- Page 4 Proof of purchase. A full description of the fault. All relevant batteries (disconnected). In the second year it should be returned direct to Friedland Technical Sales Services Department at the address shown below. Friedland is a trademark of Novar ED&S.
