Icom IC-F3011 Service Manual Addendum page 2

Jun. 2012
SECTION 7.
[CHASSIS PARTS]
REF ORDER
NO. NO.
J1 6910021491 ANT CONNECTOR 106-1 <SSC>
J2 6910015860 IMSA-6277S-02A-G
SP1 2510001530 PSC-3650P-0806A2 <PRI>
W1 8900009640 OPC-963
MP1 8010019698 2775 CHASSIS-8 1X2T
MP2 8210024600 2775 A-FRONT PANEL ASSEMBLY
MP8 8210020551 2721 REAR PANEL-1
MP9 8930063351 2775 LENS-1
MP10 8610011930 KNOB N318
MP11 8610012130 KNOB N323
MP13 8930075190 2775 C-MAIN SEAL (TOP)
MP14 8930063061 2721 T-RUBBER-1 (TOT)
MP16 8930063400 2775 SIDE PLATE
MP17 8930063412 2775 B-TOP PLATE-2
MP20 8930043760 1923 MIC SEAL
MP21 8930059361 2600 RELEASE BUTTON-1
MP22 8930070363 2775 RELEASE PLATE (A)-3
MP25 8830003440 3285 ANT NUT
MP26 8810009221 PHB0 M2 X 8 NI-ZK3 BT
MP27 8810009561 PHBT M2 X 6 NI-ZK3
MP28 8810009511 PHBT M2 X 4 NI-ZC3 (3.6-4.0)
MP29 8810009511 PHBT M2 X 4 NI-ZC3 (3.6-4.0)
MP30 8810009511 PHBT M2 X 4 NI-ZC3 (3.6-4.0)
MP31 8810010430 TRUSS M3 X 5 SUS SSBC
MP32 8310072660 2775 OPT PLATE
MP33 8930042350 1922 MIC SHEET
MP34 8930056540 PUSH SPRING (AH)
MP35 8830001701 VR NUT (Q)-1
MP36 8830001701 VR NUT (Q)-1
MP42 8930074580 2775 NAME SHEET
[ANT UNIT]
REF ORDER
NO. NO.
MP601 8510016350 2721 ANT PLATE Y720
[CONNECT UNIT]
REF ORDER
NO. NO.
J501* 6910016390 IMSA-9230B-1-02Z145-PT1
[MAIN UNIT]
REF ORDER
NO. NO.
J1* 6510021901 BM02B-ASRS-TF (LF) (SN)
J2 6450001680 HSJ1122-010010
J3 6450002250 HSJ1456-010320
F1* 5210001160 ERBRE3R00V
MC1 7700002750 EM9745P-38-G <HOR>
S1 2260001900 SW-149 (SKHLLD)
S2* 2260002800 SW-167 (SKQTLAE010)
S3* 2260002800 SW-167 (SKQTLAE010)
S4 2250000490 TP70TF5163-15.9F-2775
MP1* 8410002531 2681 PA HEATSINK-1
MP2* 8510016461 2775 VCO COVER-1
MP3* 8510016471 2775 VCO CASE-1
MP4 8510016580 2775 SHIELD PLATE Y738
*: Refer to "BOARD LAYOUTS."
**: Optional product.
Screw abbreviations
MECHANICAL PARTS
DESCRIPTION
DESCRIPTION
DESCRIPTION
DESCRIPTION
A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
[ACC UNIT]
REF ORDER
QTY.
NO. NO.
EP1 (Optional) FA-SC55V-2
1
EP2 (Optional) BP-232H
1
EP3 (Optional) BC-160
EP4 (Optional) BC-145SA
1
(Optional) BC-145SE
1
MP1 (Optional) MB-94
MP2 8210022780 2927 JACK PANEL
1
MP3 8810004861 PH M2 X 6 ZK3
1
1
1
1
1
1
1
1
1
EP1
1
1
1
1
2
2
9
1
1
1
1
1
2
1
1
1
QTY.
1
QTY.
1
QTY.
1
1
1
1
1
1
1
1
1
1
1
1
1
7 - 1
DESCRIPTION
[USA-01], [CSA-01]
EP2
MP2
EP3
EP4
QTY.
1
1
1
1
[CSA-02] 1
1
1
2
MP1
MP3
