LAS/VAS Auxiliary Section Removal and Disassembly | Auxiliary Section Service Procedures
2. Place the Low Range Synchronizer on a bench with the
larger ring facing down, (place a shop towel over the
assembly to avoid losing any springs) pull the High
Range Synchronizer from the Blocker Ring
24
© 2022 Eaton Cummins Automated Transmission Technologies. All rights reserved.
3. Remove the Sliding Clutch from the pins of the Syn-
chronizer Ring.
TRSM0940
2022.10.7
