Driver Instructions
UltraShift
PLUS
®
Automated Transmission
TRDR1110 EN-US
December 2017
UltraShift PLUS Linehaul Active Shifting (LAS)
UltraShift PLUS Linehaul Small Step Efficiency (LSE)
UltraShift PLUS Multipurpose Extreme Performance (MXP)
UltraShift PLUS Multipurpose High Performance (MHP)
UltraShift PLUS Vocational Active Shifting (VAS)
UltraShift PLUS Vocational Construction Series (VCS)
UltraShift PLUS Vocational High Performance (VHP)
UltraShift PLUS Vocational Multipurpose Series (VMS)
UltraShift PLUS Vocational Extreme Performance (VXP)
UltraShift PLUS Passenger Vehicle (PV)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UltraShift PLUS FO(M) E310C-LAS Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Eaton UltraShift PLUS FO(M) E310C-LAS Series

Summary of Contents for Eaton UltraShift PLUS FO(M) E310C-LAS Series

  • Page 1 Driver Instructions UltraShift PLUS ® Automated Transmission TRDR1110 EN-US December 2017 UltraShift PLUS Linehaul Active Shifting (LAS) UltraShift PLUS Linehaul Small Step Efficiency (LSE) UltraShift PLUS Multipurpose Extreme Performance (MXP) UltraShift PLUS Multipurpose High Performance (MHP) UltraShift PLUS Vocational Active Shifting (VAS) UltraShift PLUS Vocational Construction Series (VCS) UltraShift PLUS Vocational High Performance (VHP) UltraShift PLUS Vocational Multipurpose Series (VMS)

  • Page 3: Warnings And Cautions

    Warnings and Cautions Warnings and Cautions Definitions Warning: Indicates you will be Severely Injured or Killed if you do not follow the indicated procedure. Caution: Indicates an Immediate Hazard, which could result in Severe Per- sonal Injury if you do not follow the indicated procedure. Important: Indicates vehicle or property damage could occur if you do not fol- low the indicated procedure.
  • Page 4 Warnings and Cautions Caution Do not release the parking brake or attempt to select a gear until the air pres- sure is at the correct level. Before operating the PTO, refer to “Transmission Power Take Off Operation.” Battery (+) and (-) must be disconnected prior to any type of welding on any UltraShift PLUS equipped vehicle.

  • Page 5: Table Of Contents

    Table of Contents Warnings and Cautions ....... i Operation Shift Console Modes ........1 Gear Display .

  • Page 6: Operation

    D - Drive - Upshift MANUAL MANUAL SHIFT - Downshift EATON FULLER TRANSMISSIONS Selects Reverse (see page 4 for more details) Mode used for Start-up and Power-down Selects Drive (see page 6 for more details) MANUAL Selects MANUAL (see page 7 for more details)

  • Page 7: Gear Display

    Operation Gear Display The Gear Display indicates the current gear position of the transmission. During an upshift or downshift the gear display may momentarily flash the tar- get gear position. Gear Shift Transition Successful Gear Current Gear Shift Solid Solid May Momentarily Flash The “DASH”...

  • Page 8: Start-Up And Power Down

    Operation Start-up and Power Down Start-up ® Turn the ignition key to “ON” and allow the UltraShift PLUS to power-up. • Engine cranking is delayed until the transmission power-up is complete and the gear display shows a solid “N.” Start the engine. Apply service brake.

  • Page 9: Reverse Mode

    Operation Reverse Mode • Selects default Reverse gear (see Note*). • Each time Reverse is selected from Neutral, the default Reverse gear is engaged. • The vehicle will not engage Reverse above 2 mph. • On multi-speed auxiliary models, R1 to R2 and R3 to R4 shifts will only be made by manually using up and downshift buttons while driving.
  • Page 10 Operation UltraShift PLUS Passenger Vehicle (PV) LO Range UltraShift PLUS Linehaul Active Shifting (LAS) and UltraShift PLUS Vocational Active Shifting (VAS) LO Range HI Range UltraShift PLUS Linehaul Small Step Efficiency (LSE) LO Range LO Range LO Split HI Split UltraShift PLUS Multipurpose High Performance (MHP) and UltraShift PLUS Vocational High Performance (VHP) HI Range...

  • Page 11: Drive Mode

    Operation Drive Mode • Automatically selects the start gear (see Note*). The selected start gear will vary depending on several vehicle inputs like load, grade, and axle/transmission ratio. This start gear can be changed by using the up/down buttons, as long as the selection still falls into a gear that would allow the vehicle to launch without allowing the transmis- sion to obtain damage.

  • Page 12: Manual Mode

    Operation MANUAL Mode MANUAL mode should be used whenever the driver wants to select the shifts instead of letting UltraShift select them automatically. For example, when the driver is moving around the yard, over railroad tracks, or on steep grades. •...
  • Page 13 Operation Warning: UltraShift PLUS initiates upshifts from MANUAL and LOW for engine over speed protection. Some engines do not use the engine overspeed protection. • The system will automatically shift or inhibit shifts to prevent over- speed or under-speed of the engine. •...

  • Page 14: Low Mode

    Operation LOW Mode LOW mode should be used to maximize engine braking and minimize the use of the brake pedal. For example, when driving down long grades or when coming to a stop. • Selects lowest available gear for start gear. (see Note *). The starting gear cannot be changed in LOW mode.

  • Page 15: Transmission Shift Console Mode Configuration / Operation Standard (Default)

    Each shifter mode can be independently configured to function with one of the clutch control features below. The default clutch engagement configuration in all modes is set at Standard from the factory, but can be changed using Eaton ServiceRanger. Standard (Default) •...

  • Page 16: Urge To Move

    Operation Urge to Move • Urge to Move allows the vehicle to automatically start moving when the transmission is in gear and the driver releases the service brake. After the vehicle has launched the vehicle will creep at a constant speed at engine idle without the need to hold the throttle pedal posi- tion.

  • Page 17: Creep

    Operation Creep • Creep allows the vehicle to be driven at a constant speed at engine idle without the need to hold the throttle pedal position. The configu- ration is useful for slow speed applications where steady vehicle speed is required (e.g. dump / spreader applications). •...

  • Page 18: Blended Pedal

    Operation Stopping: Release the accelerator (vehicle will creep at constant engine idle). • Upshifts and Downshifts can be made while at constant engine idle by pushing the Upshift / Downshift buttons. Apply service brake. Blended Pedal • Blended Pedal allows the driver to directly control the clutch engage- ment through accelerator positioning.

  • Page 19: Transmission Configuration Switch

    Operation Launching: Engage the desired gear. Release service brake. Apply the amount of throttle pedal needed to accelerate the vehicle to the desired speed or desired distance. Apply full accelerator to accelerate the vehicle above idle. Stopping: Release the accelerator. Apply service brake.
  • Page 20 The Transmission Configuration switch should be used whenever the driver wants to select the secondary configurations. To select the secondary configuration settings, perform the following steps: Eaton Cobra Lever: 1. Select Secondary Configuration Settings • Press and hold the Upshift button for 4 seconds.
  • Page 21 Note: The gear display will display “C1” on the gear display for 3 seconds indi- cating the transmission Primary Configuration settings have been reselected. Eaton Push Button Note: Not all Eaton Push Button controllers have Configuration Switch capa- bility. 1. Select Secondary Configuration Settings •...

  • Page 22: Transmission Power Take Off (Pto)

    Operation Transmission Power Take Off (PTO) UltraShift PLUS Multipurpose High Performance (MHP), Multipurpose Extreme Performance (MXP), Vocational High Performance (VHP), Voca- tional Extreme Performance (VXP), Vocational Construction Series (VCS), Vocational Multipurpose Series (VMS), Linehaul Small Step Efficiency (LSE), Vocational Active Shifting (VAS) and Linehaul Active Shifting (LAS) The ability to prevent a mode selection while the PTO is active is desired for certain vocational applications such as a vehicle with a boom.

  • Page 23: Mobile Pto Operation

    Operation Mobile PTO Operation The transmission countershaft PTO is used in this application and provides limited mobile operation in the start gears. To engage the PTO for mobile operation, perform the following steps: Depress the service brake. Release the parking brake. Select “D”...

  • Page 24: Soft Soil Operation (Heavy-Duty Models Only)

    Operation Note: If the vehicle is equipped with remote Upshift/Downshift Buttons, the transmission can be remotely shifted after the SSSPTO engagement pro- cedure is completed. However the SSPTO may come to a stop while the transmission is completing the shift. Note: If the vehicle is equipped with a remote clutch control, the vehicle throt- tle pedal cannot be used for transmission clutch engagement in SSPTO mode, the remote clutch control must be used to engage the clutch.

  • Page 25: Sliding Trailer Axle

    Operation Snow/Ice Operation • The UltraShift PLUS transmission is designed to work in coordina- tion with the ATC system to ensure optimal operation. However, if the driver observes low friction road conditions (snow, rain, ice, etc.) and does not want the transmission to shift, risking wheel slippage, the driver should select MANUAL mode.

  • Page 26: Transfer Dump Application Power Down And Start-Up

    Operation Transfer Dump Application Power Down and Start-up Warning: Only people trained in the use of Transfer Dump equipment and its hazards should operate the vehicle. Warning: Operator must ensure trailer connect and disconnect is completed in a manner that is safe to themselves and others in the vicinity of the truck/ trailer.
  • Page 27 Operation Gear Shift Transition Successful Gear Current Gear Shift Solid Solid May Momentarily Flash Slowly release service brake. Warning: If vehicle movement occurs, immediately depress service brake and repeat Power Down procedure. 10. Perform out-of-cab operation following the manufacturers' operating instructions.

  • Page 28: 2-Speed Axle

    Operation 2-Speed Axle If equipped, a 2-speed axle allows the vehicle operator to select a lower axle ratio for improved performance when launching from a stop with a heavy load. Warning: Do not shift the 2-speed axle when the vehicle is on a grade. Important: If the 2-speed axle "Low"...

  • Page 29: Features

    Operation Features Hill Start Aid Operation (HSA) Hill Start Aid defaults to the “On” position. In heavy-duty UltraShift PLUS models, it can be turned “Off” by pressing and releasing the Hill Start Aid switch, however, it will turn back on after the first successful launch. If the switch is turned off, the lamp in the Hill Start switch will flash.
  • Page 30 Operation Vehicle Facing Downhill - Reverse Mode • Vehicle must be on a decline greater than 1% and in Reverse mode. • Bring vehicle to a stop and depress the service brakes then release the service brakes. Note: Vehicle will begin to move after 3 seconds, and the clutch will perform partial engagements to slow the vehicle motion.
  • Page 31 Operation Shuttle Shifting • Shuttle shifting from Reverse to any forward mode is only allowed if the vehicle speed is approximately zero. Auto Start Gear Selection • The transmission system uses various inputs to automatically select the best start gear in Drive and MANUAL. •...
  • Page 32 Operation Load Based Shifting • The transmission system will adapt to the conditions of the vehicle to change the shift points based on the followings inputs: • Vehicle grade • Engine RPM • Throttle position • Vehicle load • After changing loads or powering up the transmission system needs to relearn these inputs for the first few shifts to make the proper adjustments.
  • Page 33 Operation • The transmission will exit Neutral Coast Mode and reengage an appropriate gear under any of the following conditions: Vehicle brakes are applied Driver depresses accelerator pedal Cruise control is canceled A mode other than Drive is selected Cruise high or low set speeds are exceeded Maximum vehicle grade is exceeded Request by an adaptive cruise system •...

  • Page 34: Service & Maintenance

    Service & Maintenance General Model Information Nomenclature UltraShift PLUS Linehaul Transmissions O (M) L A S Brand - Fuller Overdrive Linehaul Active Multi-torque Shifting X 100 + 50 Ratio Set Nominal Torque Lb. Ft. Number of Speeds Configuration Design Level Mechicanical &...
  • Page 35 Service & Maintenance UltraShift PLUS Vocational Transmissions V X P Extreme Brand - Fuller Performance Overdrive X 100 + 50 Vocational Nominal Torque Lb. Ft. Ratio Set Configuration Number of Speeds Design Level Mechicanical & Electronic - V C S Construction Brand - Fuller Series...
  • Page 36 Service & Maintenance UltraShift PLUS Passenger Transmissions Passenger Brand - Eaton Vehicle Overdrive Ratio Set X 100 + 50 Number of Speeds Nominal Torque Lb. Ft. Configuration Design Level Mechicanical & Electronic Tag Location The blank spaces provided below are for recording transmission identification data and part numbers of maintenance items.

  • Page 37: Troubleshooting

    Service & Maintenance Troubleshooting Diagnostics In the event there is a problem with a UltraShift PLUS model transmission, there are three primary tasks the driver should perform: Note the driving condition under which the problem occurred. Note the condition of the transmission under which the problem occurred (i.e.
  • Page 38 Service & Maintenance Product Diagnostic Mode “PD” In the event the transmission is put in Product Diagnostic mode, a “PD” will be displayed on the gear display, and the truck will not start. Use the follow- ing procedure to exit Product Diagnostic mode: Select Neutral “N”...

  • Page 39: Proper Clutch Lubrication

    Service & Maintenance Proper Clutch Lubrication Heavy-Duty UltraShift PLUS ECA Clutch Greasing Guidelines Service Intervals • Linehaul - 50,000 miles (80,000 Km) or 3 months • Vocational - 250 hours or 1 month Important: It is highly important to follow proper ECA Clutch lube intervals. Failure to do so may result in clutch failure and unnecessary repairs.

  • Page 40: Proper Transmission Lubrication

    When switching between types of lubricants, all areas of each affected component must be thoroughly flushed. Note: For a list of Eaton Approved Synthetic Lubricants, see TCMT0021 or call 1-800-826-HELP (4357). Note: Additives and friction modifiers must not be introduced.
  • Page 41 Service & Maintenance Proper Transmission Lubrication Level Make sure the transmission lubricant is level with the bottom of the fill open- ing. Being able to reach the lubricant with your finger does not mean the lubri- cant is at the proper level. Hole Hole Improper Oil Level...
  • Page 42 Service & Maintenance To check the oil level with the sight glass (Heavy-Duty Models Only) Vehicle engine must be stopped and parked on level ground. Wipe dirt from the oil level sight glass. Proper oil level is obtained when the oil level is at the middle of the clear plastic bubble.

  • Page 43: Vehicle Towing

    Service & Maintenance Vehicle Towing When towing the vehicle, the output shaft of the transmission must not be allowed to spin or turn. If the vehicle is towed with the drive wheels still in contact with the road surface, the vehicle axle shafts or driveline must be removed or disconnected.
