6000C-IPI
6000C-IPILP
8000C-IPI
8000C-IPILP
• Important operating
a n d m a i n t e n a n c e
instructions included.
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly
could result in serious injury, death, or
property damage.
• DO NOT store or use gasoline or other flam-
mable vapors and liquids in the vicinity of this
or any other appliance.
• What to do if you smell gas
- DO NOT try to light any appliance.
- DO NOT touch any electrical switch. DO
NOT use any phone in your building.
- Leave the building immediately.
- Immediately call your gas supplier from
a neighbor's phone. Follow the gas sup-
plier's instructions.
- If you cannot reach your gas supplier, call
the fire department.
• Installation and service must be performed
by a qualified installer, service agency, or the
gas supplier.
In the Commonwealth of Massachusetts installation must be
performed by a licensed plumber or gas fitter.
See Table of Contents for location of additional Commonwealth
of Massachusetts requirements.
NOTICE
DO NOT DISCARD THIS MANUAL
• Read, understand and follow
these instructions for safe
installation and operation.
Heat & Glo • 6000C-IPI, 8000C-IPI • 2164-900 Rev. AH • 5/17
Pour demander un exemplaire en français de ce Manuel
du propriétaire, visitez www.heatnglo.com/translations.
Owner's Manual
Installation and Operation
• Leave this manual with
party responsible for use
and operation.
DANGER
DO NOT TOUCH GLASS
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
A barrier designed to reduce the risk of
burns from the hot viewing glass is provided
with this appliance and shall be installed for
the protection of children and other at-risk
individuals.
This appliance may be installed as an OEM
installation in manufactured home (USA
only) or mobile home and must be installed
in accordance with the manufacturer's
instructions and the Manufactured Home
Construction and Safety Standard, Title 24
CFR, Part 3280 in the United States, or the
Standard for Installation in Mobile Homes,
CAN/CSA Z240 MH Series, in Canada.
This appliance is only for use with the type(s)
of gas indicated on the rating plate. This
appliance is not convertible for use with other
gases, unless a certified kit is used.
HOT GLASS WILL
CAUSE BURNS.
UNTIL COOLED.
1
Advertisement
Table of Contents
Related Manuals for Heat&Glo 6000C-IPILP
Summary of Contents for Heat&Glo 6000C-IPILP
- Page 1 Pour demander un exemplaire en français de ce Manuel du propriétaire, visitez www.heatnglo.com/translations. Owner’s Manual Installation and Operation Models: 6000C-IPI 6000C-IPILP 8000C-IPI 8000C-IPILP NOTICE DO NOT DISCARD THIS MANUAL • Important operating • Read, understand and follow • Leave this manual with...
-
Page 2: Congratulations
Read this manual before installing or operating this appliance. Please retain this owner’s manual for future reference. A. Congratulations This owner’s manual should be retained for future reference. We suggest that you keep it with your other Congratulations on selecting a Heat & Glo gas fireplace, an important documents and product manuals. -
Page 3: Table Of Contents
Safety Alert Key: • DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury. • WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury. • CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury. •... - Page 4 13 Finishing A. Mantel and Wall Projections ..... . . 53 B. Facing Material ....... . . 54 C.
-
Page 5: Limited Lifetime Warranty
B. Limited Lifetime Warranty Hearth & Home Technologies LIMITED LIFETIME WARRANTY Hearth & Home Technologies, on behalf of its hearth brands (“HHT”), extends the following warranty for HHT gas, wood, pellet, coal and electric hearth appliances that are purchased from an HHT authorized dealer. WARRANTY COVERAGE: HHT warrants to the original owner of the HHT appliance at the site of installation, and to any transferee taking ownership of the appliance at the site of installation within two years following the date of original purchase, that the HHT appliance... - Page 6 B. Limited Lifetime Warranty (continued) WARRANTY CONDITIONS: • This warranty only covers HHT appliances that are purchased through an HHT authorized dealer or distributor. A list of HHT authorized dealers is available on the HHT branded websites. • This warranty is only valid while the HHT appliance remains at the site of original installation. •...
-
Page 7: Listing And Code Approvals
27,000 14,400 (2000-4500 FT) 29,000 17,000 This product is listed to ANSI standards for “Vented Gas (0-2000 FT) 6000C-IPILP Fireplace Heaters” and applicable sections of “Gas Burn- CANADA 26,100 15,300 (2000-4500 FT) ing Heating Appliances for Manufactured Homes and Recreational Vehicles”, and “Gas Fired Appliances for... -
Page 8: Requirements For The Commonwealth Of Massachusetts
Inspection Note: The following requirements reference various The state or local gas inspector of the side wall horizon- Massachusetts and national codes not contained in this tally vented gas fueled equipment shall not approve the document. installation unless, upon inspection, the inspector ob- serves carbon monoxide detectors and signage installed H. -
Page 9: User Guide
User Guide Operating Instructions A. Gas Fireplace Safety • Teach children to NEVER touch the fireplace. WARNING! DO NOT operate fireplace before reading • Consider not using the fireplace when children will be and understanding operating instructions. Failure present. to operate fireplace according to operating instructions Contact your dealer for more information, or visit: www. -
Page 10: Fan Kit (Optional)
C. Fan Kit (optional) G. Remote Controls, Wall Controls and Wall Switches If desired, a fan kit may be added. Contact your dealer to order the correct fan kit. Follow the instructions supplied with the control installed to operate your fireplace: D. -
Page 11: Ipi Battery Tray/Battery Installation
H. IPI Battery Tray/Battery Installation MODULE The IntelliFire Plus system has a battery backup option. Battery longevity and performance will be affected by the service temperatures of this appliance. NOTICE: Batteries should only be used as a power source in the event of an emergency such as an outage. SELECTOR I. -
Page 12: Lighting Instructions (Ipi)
K. Lighting Instructions (IPI) FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fi re or explosion may result causing property damage, personal injury or loss of life. • Immediately call your gas supplier from a neighbor’s phone. Follow the gas sup- A. -
Page 13: After Fireplace Is Lit
L. After Fireplace is Lit Initial Break-in Procedure • The fireplace should be run three to four hours continuously on high. • Turn the fireplace off and allow it to completely cool. • Remove fixed glass assembly. See Section 14.H. •... -
Page 14: Maintenance And Service
Maintenance and Service Surrounds, Decorative Fronts Any safety screen or guard removed for servicing must be replaced prior to operating the fireplace. Frequency: Annually By: Homeowner When properly maintained, your fireplace will give you Tools needed: Protective gloves, stable work surface many years of trouble-free service. -
Page 15: Maintenance Tasks-Qualified Service Technician
Venting Control Compartment and Firebox Top Frequency: Seasonally Frequency: Annually By: Homeowner By: Qualified Service Technician Tools needed: Protective gloves and safety glasses. Tools needed: Protective gloves, vacuum cleaner, dust cloths • Inspect venting and termination cap for blockage or obstruction such plants, bird nests, leaves, snow, debris, •... -
Page 16: Refractory, Grate And Valve Assembly Removal
Figure 3.1 IPI Pilot Flame Patterns C. Refractory, Grate and Valve Assembly Removal It may become necessary to remove the refractory, grate Figure 3.2 Grate Removal and valve assemblies. This task should be performed by a qualified service technician. The grate and base refrac- tory do not need to be removed to service the burner Note: The base refractory must be assembly. -
Page 17: Burner Identification/Verification
Figure 3.4 Valve Assembly Removal D. Burner Identification/Verification The burner may be accessed for identification and verification purposes. This task should be performed by a qualified ser- vice technician. The base refractory, valve plate and grate do not need to be removed to access the burner assembly. The logs and fiber burner top need to be removed to access the burner. -
Page 18: Installer Guide
Installer Guide Getting Started A. Typical Appliance System NOTICE: Illustrations and photos reflect typical installations and are for design purposes only. Illustrations/diagrams are not drawn to scale. Actual product may vary from pictures in manual HORIZONTAL TERMINATION CAP Note: Dual venting configurations (SECTION 10.L) ARE NOT allowed. -
Page 19: Design And Installation Considerations
B. Design and Installation Considerations D. Inspect Appliance and Components Heat & Glo direct vent gas appliances are designed to • Carefully remove the appliance and components from operate with all combustion air siphoned from outside of the packaging. the building and all exhaust gases expelled to the outside. •... -
Page 20: Framing And Clearances
Framing and Clearances A. Selecting Appliance Location NOTICE: Illustrations reflect typical installations and are FOR DESIGN PURPOSES ONLY. Illustrations/diagrams When selecting a location for the appliance it is important to are not drawn to scale. Actual installation may vary due to consider the required clearances to walls (see Figure 5.1).
