Linak EM-322 Quick Manual

Q U I C K G U I D E
Ventillationsstyring / Ventilation control EM-322
Tilslutning og indstilling / Connection, jumper and DIP-settings
N L
arbetsbrytare
Service-
afbryder
Service
230 Vac
Switch
LA12 Pot.meter LA12 HallPot
ON
DIP
OFF
1 2 3 4 5 6 7 8
Jumper
Tilslutning
4 5 6 7 8 9
R S GR
BL GU
LA31 kan kun betjenes via digital betjening / LA31 can only be operated by digital control
*)
DIP 4: ON = Digitalt styresignal, OFF= Analogt styresignal.
DIP 4 On= Digital, OFF= Analog styrsignal
DIP 5: ON = 2-10V styresignal, OFF = 0-10V styresignal.
DIP 5 On= 2-10 V Styrsignal, OFF= 0-10 V Styrsignal
DIP 6: OFF= Fuld åbning ved strømsvigt, ON = Intelligent åbning ved strømsvigt (gennemsnittet af positionen de sidste 2 timer, dog mindst 15%)
DIP 6 ON= Nödöppning till ett snitt av de senaste 2 tim. position, dock minst 15%., OFF= Full öppning vid strömsvikt.
DIP 7: ON = Modsat som DIP 5 (10-0V / 10-2V signal), OFF = Direkte som indstillet ved DIP 5)
DIP 7= On= Vid inverterad styrsignal, 10-2 V resp. 10-0 V, Off= Normalläge
DIP 8: ON = Parametre kan ændres vhj.a EM-236, OFF= Fabriksindstillet parametre.
DIP 8= Externt programmeringsläge. OFF= Fabriksinställning.
DIP 4: ON = Digital control signal, OFF= Analog control signal.
DIP 5: ON = 2-10V control signal, OFF = 0-10V control signal.
DIP 6: OFF = Emergency run position full open, ON= Intelligent position in emergency run. ( average of positions of last hour x2. -at least 15% open)
DIP 7: ON = inverted control signal (10-0V / 10-2V signal), OFF = Direct control)
DIP 8: ON = parameters can be modi ed, OFF= preset default parameter are in use = parameter are xed.
Specifikationerne kan ændre sig uden forudgående varsel. Det er brugerens ansvar at fastslå
LINAK produktets egnethed til en specifik applikation. LINAK vil ved levering ombytte/reparere
defekte produkter, som er dækket af garanti, hvis de straks returneres til LINAK Danmark A/S.
Der påtages intet ansvar udover denne ombytning/reparation.
Specifications subject to change without prior notice. It is the responsibility of the product user to
determine the suitability of the products for a specific application. LINAK Danmark will at point of
delivery replace/repair defective products covered by the warranty if promptly returned
to LINAK Danmark. No liability is assumed beyond such replacement/repair.
Back-up
Trafo
battery
DIP
Sikring
ON
Fuse
OFF
4 5 6 7 8 9 10 11 12 13
LA32 Pot.meter LA35 HallPot
ON ON
OFF OFF
1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8
4 5 6 7 8 9 4 5 6 7 8 9
BL S GR R+GU S BR
R GU HV+GR BL
Tilslut back-up
batteri før drift.
Jumper
Jumper- og DIP-
indstilling, se skema
nedenfor.
Fejl-relæ er sluttet ved
14 15 16 17
normal drift. Kontakt
bryder ved fejl.
Styrcentral
Kontrolenhed / Control unit
Analog
Digital
10 11 13 11 13
0/10V GND
IND/ FW UD/ BW
2/10V
*)
LA31
ON ON
OFF OFF
1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8
4 5 6 7 8 9 4 5 6 7 8 9
BR S HV BR
BL V BL
Forhandler:/
LINAK Danmark A/S
Mønstedsvej 9
DK-8600 Silkeborg
Tlf. +45 86803611 - www.linak.dk
Farvekoder / Color codes
R = Rød / Red
S = Sort / Black
V = Violet
BL = Blå / Blue
BR = Brun / Brown
GR = Grøn / Green
GU = Gul / Yellow
HV = Hvid / White
Connect back-up
Anslut back-up batteri före
battery before use
före uppstart.
Jumper- og DIP-
Jumper och dip inställningar,
settings, see table
se shema nedan.
below.
Fault relay is nor-
Felindikeringsrelä normalt
mally energized and
slutet.
contact is closed.
Opens in fault situations
Alarm
14 15
3x LA12
ON
OFF
1 2 3 4 5 6 7 8
Act. 1 Act. 2
4 5 6 7 8 9
4 5 6 7 8 9
R S GR
BR
BL GU
BL
Distributor:
Act. 3
4 5 6 7 8 9
BR
BL
