setup
automatic registration of network cameras
1. In the <channel setup> field, click on the <auto detect> button.
2. <auto detect> window appears.
￭
Click < > in the camera list on the live screen to automatically search and register the camera.
3. Select a camera to register in the <Searched camera> list and press the <register> button.
You can check the selected camera in the <camera to register> list.
￭
An already registered camera will be marked in blue in the list.
￭
If you search for the camera again or if the IP is an old IP that was not assigned by the DHCP server (such as 192.168.1.100), then press the
<Refresh> button to check if a new IP has been assigned.
￭
<Status> shows the camera authentication status. In the <Auth failed> state, click <
￭
Click a header at the top of the list to sort the list according to that header.
4. To change the IP address of the camera, select the desired camera from the <camera to register> list and
press the <change ip> button.
5. Click <next> at the bottom of the screen to set the registered camera channel.
6. Press the <register> button on the lower right of the screen to register the selected camera.
￭
If you register a camera using a user account—not admin account—the camera features may be limited.
￭
When you change the camera ID/password in the camera web viewer, if the camera is already registered in Recorder, you also have to
change the camera ID/password information registered in Recorder.
￭
When the camera is factory reset, it defaults to the ID and password set in "Setup > Camera > Camera password".
￭
If the camera's ID and password have already been set, the registered information matches the ID and password set in the "Setup >
Camera > Camera password". (up to 3 sets)
￭
Wisenet camera is registered via Wisenet protocol while a third party camera is registered via ONVIF protocol.
￭
A device running a DHCP server should never be connected to a PoE port or a camera setup port. (e.g. router)
￭
If your camera uses its own power supply unit, you need to manually register or auto-register the camera.
￭
For products that support PoE, refer to the "Functions Supported by Model" page.
46_ setup
> to enter the camera ID and password.
registering a network camera manually
1. In the <channel setup> field, click on the <manual> button.
2. <manual registration> window appears.
￭
You can register the camera manually by clicking <+> from the camera list on the live screen.
3. Select a channel and protocol used to connect to a camera.
The input items may differ depending on the selected protocol.
Wisenet : Wisenet camera's protocol can be used.
●
ONVIF : Means the camera supports ONVIF protocols. When connecting a camera that its name cannot be
●
found from the list, select <onVif>.
￭
When a camera is registered with ONVIF, if the difference in system time between the camera and recorder is 2 minutes or more, you
won't be able to register it. In this case, synchronize the camera and recorder time.
RTSP : Comply with RFC 2326, one of "Real Time Streaming Protocol (RTSP)" for real-time streaming.
●
4. If you select the <Wisenet> protocol, check options as necessary.
Model : Select a camera model.
●
– Unknown : Select when the camera model cannot be identified.
– Wisenet Camera : You can register Hanwha Techwin's cameras and encoders.
– Wisenet Multi-Channel : You can register Hanwha Techwin's multi directional cameras and multi-imager
cameras. A multi-channel camera is a camera that has multiple camera modules in one body. Auto-
registering your camera to Recorder lets you register multiple channels at once. However, if you want to
manually register it, you need to register one channel at a time.
