  • Page 1 Order No. MTV0206175C3 Colour Television TX-34P150X MD3A Chassis SPECIFICATIONS Specifications...
  • Page 2 Power Source AC SINGLE 220 V, 50 Hz Power Consumption 209 W Standby condition : 3.0 W 21 Systems Receiving System Function Reception of broadcast 1 PAL B, G, H transmissions and 2 PAL I Playback from Video 3 PAL D, K Cassette Tape Recorders 4 SECAM B, G 5 SECAM D, K...
  • Page 3 (German) Tuning System Frequency synthesizer Auto Search Tuning POSITION : 100 Position DIRECT : 125 Position High Voltage 31.0 ± 1.0 kV at zero beam current Picture Tube Overall Picture tube measured diagonally : 72 cm Viewable Picture tube measured diagonally : 68 cm CRT Deflection : 104°...
  • Page 4: Safety Precautions

    1. SAFETY PRECAUTIONS 1.1. General Guide 1. It is advisable to insert an isolation transformer in the AC supply before servicing a hot chassis. 2. When servicing, observe the original lead dress, especially the lead dress in the high voltage circuits. If a short circuit is found, replace all parts which have been overheated or damaged by the short circuit.
  • Page 5 6. After servicing make the following leakage current checks to prevent the customer from being exposed to shock hazards. 1.2. Leakage Current Cold Check 1. Unplug the AC cord and connect a jumper between the two prongs on the plug. 2.
  • Page 6: Service Hints

    5. Reverse the AC plug in the AC outlet and repeat each of the above measurements. 6. The potential any point should not exceed 1.0 V rms. In the case of a measurement being outside of the limits specified, there is a possibility of a shock hazard, and the receiver should be repaired and rechecked before it is returned to the customer.
  • Page 7: Location Of Controls

    Fig. 1 2.2. LOCATION OF CONTROLS Fig. 2 2.3. HOW TO MOVE THE CHASSIS INTO SERVICE POSITION 1. Hold and lift the rear of the chassis and gently pull the chassis towards you as shown in Fig. 3. 2. Release the respective wiring clips and rotate the chassis vertically through 90°...
  • Page 8: Hotel Mode

    2.4. HOTEL MODE Purpose 1. At Hotels, this Mode prevents the customer from changing the TV preset data such as Channel preset data. / / Note: This Mode is useful for Hotels. You should not get into “Hotel mode” with Normal use.
  • Page 9: Self Check

    button and Channel Up “[+/ ]” key on the TV set simultaneously, after setting the “Off-Timer” mode. 2. In this mode, the Channel Up and Down Function will be enabled as normal and the maximum volume level for this mode is set at the current volume level, ie the setting at the level before entering the mode.
  • Page 10: Service Mode Function

    1. Self Check is used to automatically check the bus lines and hexadecimal code of the TV set. 2. To get into the Self Check mode, press the down n [-/ ] button on the customer controls at the front of the set, at the same time pressing the HELP button on the remote control and the screen will show: 4.
  • Page 13: Adjustment Procedure

    5. ADJUSTMENT PROCEDURE 5.1. VOLTAGE CONFIRMATION Item/Preparation Adjustment Procedure 1. Operate the TV set. 1. TPA55 : 144.8 ± 1.0V (D-Board) 2. Set controls : / Bright Minimum / Contrast Minimum / 2. TPA56 : 12.0 ± 1.0V (D-Board) Volume Minimum 3.
  • Page 14: Sub Contrast

    Item/Preparation Adjustment Procedure 1. Receive an RF signal, window or crosshatch pattern. 1. Check the EHT voltage is (32.0±1.0) kV. 2. Set the Brightness and Contrast to minimum (0 Beam) 2. Switch from AV mode to TV. 3. Connect the High Voltage Voltmeter to the CRT ANODE CAP. 3.
  • Page 15 Item/Preparation Adjustment Procedure 1. Receive SECAM white pattern. 1. Adjust SECAM B-Y so that H-blanking time and colour center 2. Connect oscilloscope to A44 pin 39. level. 3. Set controls: / BRT....CENTER / COLOUR..CENTER / Fig. 6 CONTRAST..MAX / AI....OFF 2.
  • Page 16: Colour Purity

    Fig. 2 Fig. 3 5.8. COLOUR PURITY 1. Operate the TV set for over 60 minutes. 2. Receive a purity pattern signal. (white pattern) 3. Set Bright and Contrast controls to their maximum positions.
  • Page 17 4. Set V-POS to 128. 5. Adjust roughly the static convergence magnets. 6. Fully degauss the picture tube using an external degaussing coil. 7. Loosen a clamp screw for the Deflection Yoke and move the Deflection Yoke as close to the purity magnet as possible. 8.
  • Page 18 B. Receive the cross hatch pattern. C. Picture menu : DYNAMIC Normal and adjust BRIGHT DAC until gray portion of cross hatch. D. Set DY to CRT not to tilt (Up and Down and Left and Right). 3. ADJUSTMENT A. Static Convergence Adjustment a.
  • Page 19 neck and DY so that dynamic convergence is best. 4. Confirm that left upper side line is straight. / When left upper side line isn’t straight, put magnet on DY and adjust the left upper side line to straight. 5.10. CUT OFF Preparation 1.
  • Page 20 4. Adjust the remained R and B-CUTOFF controls so as to get a white horizontal line on the screen. 5. Return to full field SCAN by pushing the position 5 key on the remote control. 6. Adjust the R-Drive and B-Drive controls as to obtain uniform white on the white bar of the greyscale pattern.
  • Page 21: White Balance

    10. Be certain that the four wedges are firmly fixed and the Deflection Yoke is tightly clamped in place otherwise the Deflection Yoke may shift its position and cause a loss of convergence and purity. 5.11. WHITE BALANCE Item/Preparation Adjustment Procedure 1.
  • Page 22: Deflection Adjustment

    Item/Preparation Adjustment Procedure 1. Receive the sub bright pattern. 1. Adjust Sub Bright so that brightness level becomes 1 ± 0.2 cd/m 2. Picture Menu: / BRT....CENTER / COLOUR..CENTER / CONT....MAX 3. Connect the photo sensor of the Colour Analyser to the center of the CRT.
  • Page 23 2. Set scan mode to progressive by remote control key. 3. Adjust V-POS (60p / 4:3) so that the scale of the top and bottom side is equal. Fig. 1 6.1.3. V-HEIGHT ADJUSTMENT (4:3 MODE) 6.1.3.1. 100i V-AMP ADJUSTMENT 1. Receive PAL monoscope pattern. 2.
  • Page 24: H-Deflection Confirmation/Adjustment (4:3 Mode)

    6.2. H-DEFLECTION CONFIRMATION/ADJUSTMENT (4:3 MODE) 6.2.1. H-HOLD CONFIRMATION 1. Receive PAL monoscope pattern. 2. Set scan mode to 100 Hz by remote control key. 3. Set aspect to 4:3. 4. Confirm that H-hold is normal. 6.2.2. H-CENTER ADJUSTMENT (4:3 MODE) 6.2.2.1.
  • Page 25 2. Set scan mode to 100 Hz by remote control key. 3. Adjust H-POS (100i / 4:3) so that the horizontal position is center of CRT. 6.2.2.2. 120i H-POS ADJUSTMENT 1. Receive NTSC monoscope pattern. 2. Set scan mode to 100 Hz by remote control key. 3.
  • Page 26 6.3. EW ADJUSTMENT/CONFIRMATION (4:3 MODE) 6.3.1. 100i SIDE EW ADJUSTMENT (4:3 MODE) 1. Receive PAL cross-hatch pattern. 2. Set scan mode to 100 Hz by remote control key. 3. Adjust the vertical line to straight by Parabola (100i / 4:3). 4.
  • Page 27 6.3.3. 50p SIDE EW ADJUSTMENT (4:3 MODE) 1. Receive PAL cross-hatch pattern. 2. Set scan mode to progressive by remote control key. 3. Adjust the vertical line to straight by Parabola (50p / 4:3). 4. Adjust the vertical line to straight line of both sides vertical line in Fig.
  • Page 28 2. Set scan mode to progressive by remote control key. 3. Adjust the vertical line to straight by Parabola (60p / 4:3). 4. Adjust the vertical line to straight line of both sides vertical line in Fig. 5 by Trapezoid (60p / 4:3). 5.
  • Page 29 2. Set scan mode to 100 Hz by remote control key. 3. Confirm V-linear (100i / 4:3) as to the balance of circle. / If needed, adjust V-linear (100i / 4:3). 6.4.2. 120i V-Linear ADJUSTMENT 1. Receive NTSC monoscope pattern. 2.
  • Page 30 6.5. DEFLECTION (16:9 MODE) ADJUSTMENT / CONFIRMATION 6.5.1. DATA SETTING (16:9) 1. Copy the adjusted data of 100i / 4:3 mode to 100i / 16:9 in the Table. 1 (Except H-POS, V-S-Correct). 2. Copy the adjusted data of 120i / 4:3 mode to 120i / 16:9 in the Table.
  • Page 31: Deflection Adjustment / Confirmation

    3. Set scan mode to 100 Hz. 4. Confirm that A, B in Fig. 7 is 6.0 cm ± 1 cm. If not, adjust V-AMP (100i / 16:9). 5. Set scan mode to progressive. 6. Confirm that A, B in Fig. 7 is 6.0 cm ± 1 cm. If not, adjust V-AMP (50p / 16:9).
  • Page 32 3. Copy the data of F5h to EEROM ADDRESS [332] (525p / H-POS). 4. Confirm H-center and if needed, adjust H-POS (525p). 6.7. 625p DEFLECTION ADJUSTMENT 6.7.1. H-CENTER (625p) ADJUSTMENT 1. Receive 625p signal. 2. Copy the data of EEROM ADDRESS [332] (525p / H-POS) to EEROM ADDRESS [330] (625p / H-POS).
  • Page 33 3. Confirm there is no H-Parallel distortion. / If there is distortion, adjust by H-Parallel (VGA). / In that case, repeat 2 and 3 so that there is no trapezoid / parallel distortion. 4. Confirmation vertical EW of the corner side. / If needed, adjust Top -Corner (VGA) and Bottom-Corner (VGA).
  • Page 34 6.9.4. V-LINEARITY CONFIRMATION / ADJUSTMENT 1. Confirm V-linear as to the balance of the circle. / If needed, adjust V-linear (VGA 400). 6.9.5. SIDE EW CONFIRMATION / ADJUSTMENT 1. Confirm the vertical line is straight line. / If needed, adjust the vertical line to straight line by Parabola (VGA 400).
  • Page 35: Location Of Lead Wiring

    7. LOCATION OF LEAD WIRING...
  • Page 37 Note: / - SINGLE CLAMP / - DOUBLE CLAMP / / Caution Points: 1. All leads must not touch the high temperature parts which are specified in safety specification (heat sink / FBT / power circuit / etc.) 2. DY lead must be kept distant minimum 10 mm from FBT. 3.
  • Page 38: Conductor Views

    8. CONDUCTOR VIEWS 8.1. A-Board 9. SCHEMATIC DIAGRAMS 9.1. SCHEMATIC DIAGRAM NOTES...
  • Page 40 9.2. A BOARD 9.2.1. A BOARD (1/3) 9.2.2. A BOARD (2/3) 9.2.3. A BOARD (3/3) 9.3. DF BOARD 9.3.1. DF BOARD (1/2) 9.3.2. DF BOARD (2/2) 9.4. DG BOARD 9.4.1. DG BOARD (1/3) 9.4.2. DG BOARD (2/3) 9.4.3. DG BOARD (3/3)
  • Page 41: Parts Location

    9.5. GM BOARD 9.5.1. GM BOARD (1/2) 9.5.2. GM BOARD (2/2) 9.6. DG2 BOARD 9.6.1. DG2 BOARD (1/2) 9.6.2. DG2 BOARD (2/2) 9.7. H BOARD 9.7.1. H BOARD (1/2) 9.7.2. H BOARD (2/2) 9.8. K BOARD 9.8.1. K BOARD (1/2) 9.8.2.
  • Page 42: Replacement Parts List

    11. REPLACEMENT PARTS LIST 11.1. Replacement Parts List Notes...
  • Page 43 KRCBC160928B CORE CLAMPER M80LSW196X PICTURE TUBE ( S’PORE ONLY ) M80LSW195XV PICTURE TUBE ( M’EAST ONLY ) TBMA059 PANASONIC BADGE TBM4G0834 MODEL NAME PLATE ( S’PORE ONLY ) TBM4G0872 MODEL NAME PLATE ( M’EAST ONLY ) TBX4G86800 POWER BUTTON TEK6940...
  • Page 44 Ref. No. Part No. Part Name & Description Remarks TJB1726400 75OHM ADAPTOR TKP4G12620 REAR AV BRACKET TKP4G12631 DOOR TKU4G8504 BACK COVER TLK4G9041S ROTATION COIL TLK4G9062S DEGAUSSING COIL TMM4G503 RUBBER WEDGE TNP4G118AV GM BOARD TNP4G189AH DG BOARD ( S’PORE ONLY ) TNP4G189AL DG BOARD ( M’EAST ONLY )
  • Page 45 Ref. No. Part No. Part Name & Description Remarks R468 ERJ3GEYJ224 M 220KOHM,J,1/16W R469 ERJ3GEYJ222 M 2.2KOHM,J,1/16W R470 ERJ3GEY0R00 M 0OHM,J,1/16W R471 ERJ3GEYJ563 M 56KOHM,J,1/16W R472 ERJ3GEYJ683 M 68KOHM,J,1/16W R502 ERDS1TJ100 C 10OHM,J, 1/2W R503 ER0S2CKF1152 M11.5KOHM,F, 1/4W R504 ER0S2CHF8661 M8.66KOHM,F, 1/4W R506 ERDS1FJ1R0...
  • Page 46 Ref. No. Part No. Part Name & Description Remarks R955 ERJ3GEYJ271 M 270OHM,J,1/16W R956 ERDS1FJ561 C 560OHM,J, 1/2W R957 ERDS1TJ330 C 33OHM,J, 1/2W R958 ERDS1TJ330 C 33OHM,J, 1/2W R960 ERQ14AJ100E F 10OHM,J, 1/4W R962 ERQ14AJ120E F 12OHM,J, 1/4W R963 ERQ14AJ120E F 12OHM,J, 1/4W R964 ERJ3GEYJ122...
  • Page 47 Ref. No. Part No. Part Name & Description Remarks R1128 ERJ3GEYJ101 M 100OHM,J,1/16W R1129 ERJ3GEYJ223 M 22KOHM,J,1/16W R1130 ERJ3GEYJ101 M 100OHM,J,1/16W R1131 ERJ3GEYJ472 M 4.7KOHM,J,1/16W R1132 ERJ3GEYJ473 M 47KOHM,J,1/16W R1133 ERJ3GEYJ182 M 1.8KOHM,J,1/16W R1134 ERJ3GEYJ222 M 2.2KOHM,J,1/16W R1135 ERJ3GEYJ102 M 1KOHM,J,1/16W R1136 ERJ3GEYJ101 M 100OHM,J,1/16W...
  • Page 48 Ref. No. Part No. Part Name & Description Remarks R1336 ERJ3EKF2201 M 2.2KOHM,F,1/16W R1337 ERJ3GEYJ121 M 120OHM,J,1/16W R1338 ERJ3GEYJ182 M 1.8KOHM,J,1/16W R1339 ERJ3EKF2201 M 2.2KOHM,F,1/16W R1340 ERJ3GEYJ121 M 120OHM,J,1/16W R1341 ERJ3GEYJ911 M 910OHM,J,1/16W R1342 ERJ3EKF2201 M 2.2KOHM,F,1/16W R1343 ERJ3EKF1200 M 120OHM,F,1/16W R1345 ERJ3GEYJ220 M 22OHM,J,1/16W...
  • Page 49 Ref. No. Part No. Part Name & Description Remarks R1585 ERJ3EKF4700 M 470OHM,F,1/16W R1586 ERJ3EKF1800 M 180OHM,F,1/16W R1587 ERJ3EKF1800 M 180OHM,F,1/16W R1588 ERJ3EKF1800 M 180OHM,F,1/16W R1590 ERJ3GEY0R00 M 0OHM,J,1/16W R1591 ERJ3GEY0R00 M 0OHM,J,1/16W R1592 ERJ3GEY0R00 M 0OHM,J,1/16W R1593 ERJ3GEY0R00 M 0OHM,J,1/16W R1594 ERJ3GEY0R00 M 0OHM,J,1/16W...
  • Page 50 Ref. No. Part No. Part Name & Description Remarks R3075 ERJ3GEY0R00 M 0OHM,J,1/16W R3076 ERJ3GEY0R00 M 0OHM,J,1/16W R3080 ERJ3GEYJ331 M 330OHM,J,1/16W R3081 ERJ3GEYJ750 M 75OHM,J,1/16W R3082 ERJ3GEYJ184 M 180KOHM,J,1/16W R3083 ERJ3GEYJ102 M 1KOHM,J,1/16W R3084 ERJ3GEYJ184 M 180KOHM,J,1/16W R3085 ERJ3GEYJ102 M 1KOHM,J,1/16W R3086 ERJ3GEYJ331 M 330OHM,J,1/16W...
  • Page 51 Ref. No. Part No. Part Name & Description Remarks C105 ECJ1VF1C104Z C 0.1UF, Z, 16V C110 ECJ1VC1H100C C 10PF, C, 50V C111 ECJ1VF1C104Z C 0.1UF, Z, 16V C115 ECA1CM221B E 220UF, 16V C121 ECJ1VC1H100C C 10PF, C, 50V C352 ECJ1VB1H103K C 0.01UF, K, 50V C354 ECJ1VB1E223K...
  • Page 52 Ref. No. Part No. Part Name & Description Remarks C862 ECA1CM102B E 1000UF, 16V C863 ECA1CM102B E 1000UF, 16V C864 ECA1EM331B E 330UF, 25V C867 ECJ1VB1H272K C 2700PF, K, 50V C870 ECJ1VB1H102K C 1000PF, K, 50V C882 ECA1CM101B E 100UF, 16V C883 ECA1CM101B E 100UF, 16V...
  • Page 53 Ref. No. Part No. Part Name & Description Remarks C1337 ECJ1VC1H121J C 120PF, J, 50V C1338 EEVHP1E220P E 22UF, 25V C1339 ECJ1VC1H101J C 100PF, J, 50V C1340 ECJ1VC1H121J C 120PF, J, 50V C1341 ECJ1VC1H100D C 10PF, D, 50V C1342 ECJ1VC1H220J C 22PF, J, 50V C1343 ECJ1VC1H680J...
  • Page 54 Ref. No. Part No. Part Name & Description Remarks C1403 ECJ1VB1H123K C 0.012UF, K, 50V C1404 EEVHB0G221P E 220UF, 4V C1405 ECJ1VB0J105K C 1UF, K,6.3V C1406 ECJ1VB0J105K C 1UF, K,6.3V C1407 ECJ1VB1H103K C 0.01UF, K, 50V C1410 ECJ1VB0J105K C 1UF, K,6.3V C1411 ECJ1VB1C104K C 0.1UF, K, 16V...
  • Page 55 Ref. No. Part No. Part Name & Description Remarks C2139 ECJ1VC1H010C C 1PF, C, 50V C2140 ECJ1VC1H010C C 1PF, C, 50V C2301 ECJ1VF1H104Z C 0.1UF, Z, 50V C2302 ECJ1VC1H561K C 560PF, K, 50V C2303 ECQV1H684JM P 0.68UF, J, 50V C2304 ECQV1H154JM P 0.15UF, J, 50V C2305...
  • Page 56 Ref. No. Part No. Part Name & Description Remarks C4813 ECA1CM101B E 100UF, 16V C4814 ECA1CM101B E 100UF, 16V C4815 ECA1CM101B E 100UF, 16V C4822 ECHU1C103JA5 P 0.01UF, J, 16V C4823 ECEA1CN100U E 10UF, 16V C4824 ECEA1CN100U E 10UF, 16V C4825 EEUFC1C560B E 56UF, 16V...
  • Page 57 Ref. No. Part No. Part Name & Description Remarks L1492 TALC325T4R7M CHIP INDUCTOR COIL L1495 TALC325T4R7M CHIP INDUCTOR COIL L1501 TALC325T4R7M CHIP INDUCTOR COIL L1580 TALC325T4R7M CHIP INDUCTOR COIL L2101 TLTACT100K PEAKING COIL 10U L2130 EXCELSA35T BEAD CORE L2132 G0C6R8KA0004 PEAKING COIL L2133 TLTACT100K...
  • Page 58 Ref. No. Part No. Part Name & Description Remarks D527 MA152KTX DIODE D530 MA165 DIODE D532 MA4360H DIODE D534 MA182 DIODE D535 MA182 DIODE D545 B0JAME000052 DIODE D547 MA4150M DIODE D548 D1NL40V70 DIODE D551 EU02 DIODE D552 RH3GLF102 DIODE D553 FMV-3GULF730 DIODE D555...
  • Page 59 IC1301 C1ZBZ0001989 Ref. No. Part No. Part Name & Description Remarks IC1302 PQ1X251M2ZP IC1303 NJM2904M LINEAR IC IC1305 PQ1X251M2ZP IC1354 C0DBZFC00048 IC1403 AN5876S IC1404 NJM2904M LINEAR IC IC1440 C3HBKZ000001 IC1441 C3HBKZ000001 IC1470 C0CBCBD00006 IC1501 TC7MBD3245KL IC1502 TVR4GAS125 EEPROM IC IC1503 TVR4GAS127 EEPROM IC IC1601...
  • Page 60 Ref. No. Part No. Part Name & Description Remarks Q953 B1ABCF000078 TRANSISTOR TJS3A9650 4P CONNECTOR TJS118590 2P CONNECTOR TJS3A9890 9P CONNECTOR TJS4G8020 16P CONNECTOR TJS4G8020 16P CONNECTOR TJS3A9660 CONNECTOR TJS3A9660 CONNECTOR TJSF29207 CONNECTOR K1MM82A00001 CONNECTOR TJS118590 2P CONNECTOR K1KA05A00164 CONNECTOR TJS3A9640 3P CONNECTOR DF31...
  • Page 61 Ref. No. Part No. Part Name & Description Remarks JS1109 ERJ3GEY0R00 M 0OHM,J,1/16W JS1110 ERJ3GEY0R00 M 0OHM,J,1/16W JS1150 ERJ3GEY0R00 M 0OHM,J,1/16W JS1320 ERJ3GEY0R00 M 0OHM,J,1/16W JS1321 ERJ3GEY0R00 M 0OHM,J,1/16W JS1322 ERJ3GEY0R00 M 0OHM,J,1/16W JS1338 ERJ3GEY0R00 M 0OHM,J,1/16W JS1360 ERJ3GEY0R00 M 0OHM,J,1/16W JS1361 ERJ3GEY0R00 M 0OHM,J,1/16W...
  • Page 62 Ref. No. Part No. Part Name & Description Remarks R356 ERJ3GEYJ822 M 8.2KOHM,J,1/16W R357 ERC12GK561 S 560OHM,K, 1/2W R360 ERJ3GEYJ221 M 220OHM,J,1/16W R361 ERJ3EKF1801 M 1.8KOHM,F,1/16W R362 ERG3FJ823H M 82KOHM,J, 3W R363 ERJ3EKF1401 M 1.4KOHM,F,1/16W R364 ERJ3GEY0R00 M 0OHM,J,1/16W R365 ERJ3GEYJ682 M 6.8KOHM,J,1/16W R366...
  • Page 63 Ref. No. Part No. Part Name & Description Remarks R705 ERF5ZJ220 W 22OHM,J, 5W R714 ERDS1FJ680 C 68OHM,J, 1/2W R719 ERF5AK5R6 W 5.6OHM,K, 5W R801 TAR26NJ2R7Z W 2.7OHM,J, 7W R808 ERQ14AJ100E F 10OHM,J, 1/4W R809 ERG2FJ470H M 47OHM,J, 2W R812 ERDS2TJ104 C 100KOHM,J, 1/4W R813...
  • Page 64 Ref. No. Part No. Part Name & Description Remarks R1139 ERJ3GEYJ103 M 10KOHM,J,1/16W R1140 ERJ3GEYJ101 M 100OHM,J,1/16W R1141 ERJ3GEYJ103 M 10KOHM,J,1/16W R1143 ERJ3GEYJ102 M 1KOHM,J,1/16W R1144 ERJ3GEYJ102 M 1KOHM,J,1/16W R1145 ERJ3GEYJ332 M 3.3KOHM,J,1/16W R1146 ERJ3GEYJ332 M 3.3KOHM,J,1/16W R1147 ERJ3GEYJ103 M 10KOHM,J,1/16W R1148 ERJ3GEYJ472 M 4.7KOHM,J,1/16W...
  • Page 65 Ref. No. Part No. Part Name & Description Remarks R1217 ERDS2TJ332 C 3.3KOHM,J, 1/4W R1218 ERJ3GEYJ102 M 1KOHM,J,1/16W R1219 ERJ3GEYJ102 M 1KOHM,J,1/16W R1220 ERJ3GEYJ473 M 47KOHM,J,1/16W R1221 ERJ3GEYJ473 M 47KOHM,J,1/16W R1222 ERJ3GEYJ563 M 56KOHM,J,1/16W R1223 ERJ3GEYJ563 M 56KOHM,J,1/16W R1367 ERJ3GEYJ221 M 220OHM,J,1/16W R1370 ERJ3GEYJ471...
  • Page 66 Ref. No. Part No. Part Name & Description Remarks R1443 ERJ3GEYJ680 M 68OHM,J,1/16W R1444 EXB38V680J RESISTOR ARRAY R1445 EXB38V680J RESISTOR ARRAY R1446 EXB38V680J RESISTOR ARRAY R1447 ERJ3GEYJ680 M 68OHM,J,1/16W R1450 EXB38V680J RESISTOR ARRAY R1451 EXB38V680J RESISTOR ARRAY R1452 EXB38V680J RESISTOR ARRAY R1453 ERJ3GEYJ680 M 68OHM,J,1/16W...
  • Page 67 Ref. No. Part No. Part Name & Description Remarks R3004 ERJ3GEYJ102 M 1KOHM,J,1/16W R3005 ERJ3GEYJ184 M 180KOHM,J,1/16W R3006 ERJ3GEYJ102 M 1KOHM,J,1/16W R3007 ERJ3GEYJ221 M 220OHM,J,1/16W R3009 ERJ3GEYJ331 M 330OHM,J,1/16W R3010 ERJ3GEYJ750 M 75OHM,J,1/16W R3011 ERJ3GEYJ331 M 330OHM,J,1/16W R3012 ERJ3GEYJ750 M 75OHM,J,1/16W R3015 ERJ3GEYJ331 M 330OHM,J,1/16W...
  • Page 68 Ref. No. Part No. Part Name & Description Remarks R4823 ERJ6GEYJ472 M 4.7KOHM,J,1/10W R4824 ERJ6ENF5621 M5.62KOHM, 1/10W R4825 ERJ6ENF3832 M38.3KOHM, 1/10W R4826 ERJ6ENF2213 M 221KOHM, 1/10W R4827 ERJ6ENF9091 M9.09KOHM, 1/10W R4828 ERJ6ENF6651 M6.65KOHM, 1/10W R4829 ERJ6GEYJ102 M 1KOHM,J,1/10W R4831 ERDS1FJ220 C 22OHM,J, 1/2W R4837 ERJ6GEYJ102...
  • Page 69 Ref. No. Part No. Part Name & Description Remarks C565 ECQP1183JZ P 0.018UF, J,100V C567 ECKR3A821JBP C 820PF, J, 1KV C568 ECEA1HKA0R1 E 0.1UF, 50V C575 ECJ1VC1H221J C 220PF, J, 50V C581 ECWF4364JBB P 0.36UF, J,400V C582 ECWF4394JBB P 0.39UF, J,400V C583 ECWF4364JBB P 0.36UF, J,400V...
  • Page 70 Ref. No. Part No. Part Name & Description Remarks C1230 ECEA1CN470U E 47UF, 16V C1231 ECA1CM471B E 470UF, 16V C1232 ECJ1VC1H680J C 68PF, J, 50V C1250 ECJ1VF1H104Z C 0.1UF, Z, 50V C1251 ECA1CM222B E 2200UF, 16V C1252 ECA0JM222B E 2200UF, 6.3V C1253 EEUFC1A471B E 470UF, 10V...
  • Page 71 Ref. No. Part No. Part Name & Description Remarks C1335 ECJ1VC1H101J C 100PF, J, 50V C1336 ECJ1VC1H100D C 10PF, D, 50V C1415 ECJ1VC1H680J C 68PF, J, 50V C1416 ECJ1VC1H330J C 33PF, J, 50V C1417 ECJ1VB1H103K C 0.01UF, K, 50V C1418 ECJ1VB1C104K C 0.1UF, K, 16V C1419...
  • Page 72 Ref. No. Part No. Part Name & Description Remarks C1486 ECJ1VB1H103K C 0.01UF, K, 50V C1487 ECJ1VB1H103K C 0.01UF, K, 50V C1490 ECJ1VB1H103K C 0.01UF, K, 50V C1491 ECJ1VB1H103K C 0.01UF, K, 50V C1492 ECJ1VB1C223K C 0.022UF, K, 16V C1495 ECHU1C333JB5 P 0.033UF, J, 16V C1496...
  • Page 73 Ref. No. Part No. Part Name & Description Remarks C3034 ECJ1VC1H561K C 560PF, K, 50V C3035 ECJ1VC1H471J C 470PF, J, 50V C3036 ECA1HM2R2B E 2.2UF, 50V C3037 ECJ1VC1H471J C 470PF, J, 50V C3038 ECA1HM2R2B E 2.2UF, 50V C3048 ECJ2VF1C105Z C 1UF, Z, 16V C3049 ECA1HM220B E 22UF, 50V...
  • Page 74 Ref. No. Part No. Part Name & Description Remarks L820 EXCELSA39E BEAD CHOKE L828 EXCELDR35V CORE L840 TLP4GD005 LINE FILTER L850 EXCELSA35B BEAD CORE L851 EXCELSA35B BEAD CORE L853 EXCELDR35C BEAD CORE L855 EXCELDR35C BEAD CORE L892 EXCELDR25V CORE L893 EXCELDR25V CORE L904...
  • Page 75 LC1535 J0HAAB000012 EMI FILTER Ref. No. Part No. Part Name & Description Remarks LC1536 J0HAAB000012 EMI FILTER LC1537 J0HAAB000012 EMI FILTER LC1540 J0HAAB000012 EMI FILTER LC1541 J0HAAB000012 EMI FILTER LC1542 J0HAAB000012 EMI FILTER LC1543 J0HAAB000012 EMI FILTER LC1544 J0HAAB000012 EMI FILTER LC1545 J0HAAB000012 EMI FILTER...
  • Page 76 Ref. No. Part No. Part Name & Description Remarks D1250 RK34LFC4 DIODE D1251 MA704ATX DIODE D1252 MAZ30390LL ZENER DIODE D1253 MAZ30330LL ZENER DIODE D1440 MA152KTX DIODE D1511 MA152KTX DIODE D2101 MTZJ5.6A ZENER DIODE D2102 MTZJ5.6A ZENER DIODE D2103 MTZJ6.2A ZENER DIODE D2104 B0BA01100028 ZENER DIODE...
  • Page 77 Ref. No. Part No. Part Name & Description Remarks Q1001 B1ABCF000078 TRANSISTOR Q1060 B1ABCF000078 TRANSISTOR Q1130 B1ABCF000078 TRANSISTOR Q1131 2SA1037AKT TRANSISTOR Q1150 B1ABCF000078 TRANSISTOR Q1230 B1ABCF000078 TRANSISTOR Q1231 2SA1037AKT TRANSISTOR Q1301 B1ABCF000078 TRANSISTOR Q1302 B1ABCF000078 TRANSISTOR Q1303 B1ABCF000078 TRANSISTOR Q1335 2SA1037AKT TRANSISTOR Q1336...
  • Page 78 Ref. No. Part No. Part Name & Description Remarks TJS3A9900 10P CONNECTOR K1ZZ00001205 CONNECTOR TJS3A9890 9P CONNECTOR TJS3A9890 9P CONNECTOR TJSF17335 CONNECTOR TJS3A9670 6P CONNECTOR JS1370 ERJ3GEY0R00 M 0OHM,J,1/16W JS1371 ERJ3GEY0R00 M 0OHM,J,1/16W JS1372 ERJ3GEY0R00 M 0OHM,J,1/16W JS1386 ERJ3GEY0R00 M 0OHM,J,1/16W JS1387 ERJ3GEY0R00 M 0OHM,J,1/16W...
  • Page 79 Ref. No. Part No. Part Name & Description Remarks JS3032 ERJ3GEY0R00 M 0OHM,J,1/16W JS3051 ERJ3GEY0R00 M 0OHM,J,1/16W JS3052 ERJ3GEY0R00 M 0OHM,J,1/16W JS3171 ERJ3GEY0R00 M 0OHM,J,1/16W JS3172 ERJ3GEY0R00 M 0OHM,J,1/16W JS3310 ERJ3GEY0R00 M 0OHM,J,1/16W JS4815 ERJ3GEY0R00 M 0OHM,J,1/16W TJS3A9890 9P CONNECTOR TJS3A9670 6P CONNECTOR TJS3A9650...
  • Page 80 <1A> <2A> <3A> <4A> <5A> <6A>...
  • Page 81 <1A> <2A> <3A> <4A> <5A> <6A>...
  • Page 82 <1A> <2A> <3A> <4A> <5A> <6A> <7A> <8A> <9A> <10A> <11A> <12A>...
  • Page 83 <1A> <1B> <2A> <2B> <3A> <3B> <4B> <4A> <5B> <5A> <6B> <7B> <6A> <8B> <7A> <9B> <8A> <9A> <10B> <10A> <11A> <11B> <12A> <12B>...
  • Page 84 <1B> <2B> <3B> <4B> <5B> <6B> <7B> <8B> <9B> <10B> <11B> <12B>...
  • Page 85 <1A> <2A> <3A> <4A> <5A> <6A> <7A> <8A>...
  • Page 86 <1A> <2A> <3A> <4A> <5A> <6A> <7A> <8A>...
  • Page 87 <1A> <2A> <3A> <4A> <5A> <6A> <7A> <8A> <9A> <10A> <11A> <12A>...
  • Page 88 <1B> <1A> <2A> <3A> <4A> <2B> <3B> <5A> <4B> <6A> <7A> <8A> <5B> <9A> <6B> <7B> <10A> <11A> <8B> <12A>...
  • Page 89 <1B> <2B> <3B> <4B> <5B> <6B> <7B> <8B>...
  • Page 90 <1A> <2A> <3A> <4A> <5A> <6A> <7A>...
  • Page 91 <1A> <2A> <3A> <4A> <5A> <6A> <7A>...
  • Page 92 <1A> <2A> <3A> <4A>...
  • Page 93 <1A> <2A> <3A> <4A>...
  • Page 94 <1A> <2A> <3A>...
  • Page 95 <1A> <2A> <3A>...
  • Page 96 <1A> <2A> <3A>...
  • Page 97 <1A> <2A> <3A>...
  • Page 98 <1A> <2A> <3A>...
  • Page 99 <1A> <2A> <3A>...
  • Page 100 <1A> <2A>...
  • Page 101 <1A> <2A>...
  • Page 103 <1A> <2A> <3A> <4A> <5A> <6A> TX-34P150X GM-Board (1 of 2) Schematic Diagram...
  • Page 104 <1A> <2A> <3A> <4A> <5A> <6A> TX-34P150X GM-Board (2 of 2) Schematic Diagram...
  • Page 105 <1A> <2A> <3A> <4A> <5A> <6A> <7A> <8A> <9A> <10A> <11A> <12A> TX-34P150X DG-Board (3 of 3) Schematic Diagram...
  • Page 106 <1A> <1B> <2A> <2B> <3A> <3B> <4B> <4A> <5B> <5A> <6B> <7B> <6A> <8B> <7A> <9B> <8A> <9A> <10B> <10A> <11A> <11B> <12A> <12B> TX-34P150X DG-Board (2 of 3) Schematic Diagram...
  • Page 107 <1B> <2B> <3B> <4B> <5B> <6B> <7B> <8B> <9B> <10B> <11B> <12B> TX-34P150X DG-Board (3 of 3) Schematic Diagram...
  • Page 108 <1A> <2A> <3A> <4A> <5A> <6A> <7A> <8A> TX-34P150X DG2-Board (1 of 2) Schematic Diagram...
  • Page 109 <1A> <2A> <3A> <4A> <5A> <6A> <7A> <8A> TX-34P150X DG2-Board (2 of 2) Schematic Diagram...
  • Page 110 <1A> <2A> <3A> <4A> <5A> <6A> <7A> <8A> <9A> <10A> <11A> <12A> TX-34P150X A-Board (1 of 3) Schematic Diagram...
  • Page 111 <1B> <1A> <2A> <3A> <4A> <2B> <3B> <5A> <4B> <6A> <7A> <8A> <5B> <9A> <6B> <7B> <10A> <11A> <8B> <12A> TX-34P150X A-Board (2 of 3) Schematic Diagram...
  • Page 112 <1B> <2B> <3B> <4B> <5B> <6B> <7B> <8B> TX-34P150X A-Board (3 of 3) Schematic Diagram...
  • Page 113 <1A> <2A> <3A> <4A> <5A> <6A> <7A> TX-34P150X H-Board (1 of 2) Schematic Diagram...
  • Page 114 <1A> <2A> <3A> <4A> <5A> <6A> <7A> TX-34P150X H-Board (2 of 2) Schematic Diagram...
  • Page 115 <1A> <2A> <3A> <4A> TX-34P150X K-Board (1 of 2) Schematic Diagram...
  • Page 116 <1A> <2A> <3A> <4A> TX-34P150X K-Board (2 of 2) Schematic Diagram...
  • Page 117 <1A> <2A> <3A> TX-34P150X X-Board (1 of 2) Schematic Diagram...
  • Page 118 <1A> <2A> <3A> TX-34P150X X-Board (2 of 2) Schematic Diagram...
  • Page 119 <1A> <2A> <3A> TX-34P150X DF-Board (1 of 2) Schematic Diagram...
  • Page 120 <1A> <2A> <3A> TX-34P150X DF-Board (2 of 2) Schematic Diagram...
  • Page 121 <1A> <2A> <3A> TX-34P150X L-Board (1 of 2) Schematic Diagram...
  • Page 122 <1A> <2A> <3A> TX-34P150X L-Board (2 of 2) Schematic Diagram...
  • Page 123 <1A> <2A> TX-34P150X P-Board (1 of 2) Schematic Diagram...
  • Page 124 <1A> <2A> TX-34P150X P-Board (2 of 2) Schematic Diagram...
