DCN0478.1 - Axiom Back Outside.pdf 1 4/10/2020 10:50:58 AM
Tool Needed:
• 10mm wrench
Assemblies Included:
Two sets of
fasteners provided.
Reference Fastener
Key below.
X2
C
M
Y
CM
MY
CY
CMY
K
X2
Fastener Key:
Fastener drawings are actual size so hardware
can be compared to drawings.
35mm (Used for 1" and 1-1/8" back canes)
30mm (Used for 3/4" and 7/8" back canes)
If you have any questions or concerns about any
aspect of this Axiom back, please do not hesitate to
contact us by:
- 100860
- 101824
Telephone:
715-254-0991
In Writing at:
Ki Mobility
5201 Woodward Drive
Stevens Point, WI 54481
U.S.A
Or via email at:
sales@kimobility.com
Ki Mobility
5201 Woodward Drive
Stevens Point, Wisconsin 54481
715-254-0991
www.kimobility.com
DCN0478.1
QUICK START
GUIDE
