Ki Mobility AXiOM BACKS BTX BACKREST HARDWARE Quick Start Manual

Tool Needed:
• 10mm wrench • 5 Allen wrench
• tape measure or level
Clamp Positioning Chart
Front Clamp Rear Clamp
Position Position
Front Rear Front Rear
Holes Holes Holes Holes
Depth A djustment
Fo rward
Rear Ho le P o sitio n 1" (2.5 cm) -1" ( 2.5 cm)
Rear Clamp P o sitio n
Fro nt Ho le P o sitio n 1 .5" (4 cm) -0.5" ( 1cm)
Rear Ho le P o sitio n 3.5" (9 cm)
Fro nt Clamp P o sitio n
Fro nt Ho le P o sitio n 3" (7 cm)
Assemblies Included:
If you have any questions or concerns about any
aspect of this Axiom back, please do not hesitate to
contact us by:
Rearward
1 .5" (4 cm)
1 " (2.5 cm)
X2
Stevens Point, Wisconsin 54481
X2
Telephone:
715-254-0991
In Writing at:
Ki Mobility
5201 Woodward Drive
Stevens Point, WI 54481
U.S.A
Or via email at:
sales@kimobility.com
Ki Mobility
5201 Woodward Drive
715-254-0991
www.kimobility.com
DCN1078.0
BT X BACKREST HARDWARE
QUICK START
GUIDE
