User Manual
Thank you for purchasing our product. If there are any
questions, or requests, do not hesitate to contact the
dealer.
This manual applies to the models below:
Type I Camera
Type II Camera
Type III Camera
Type IV Camera
This manual may contain several technical mistakes or
printing errors, and the content is subject to change
without notice. The updates will be added to the new
version of this manual. We will readily improve or
update the products or procedures described in the
manual.
Dual-Light Bullet & Turret
Type
Eco Camera
User Manual
Model
DS-2CE16D0T-EXLF
DS-2CE16D0T-EXLPF
DS-2CE16K0T-EXLF
DS-2CE16K0T-EXLPF
DS-2CE17D0T-EXLF
DS-2CE17K0T-EXLF
DS-2CE76D0T-EXLMF
DS-2CE76K0T-EXLMF
DS-2CE76D0T-EXLPF
DS-2CE76K0T-EXLPF
01000020221014
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for HIKVISION DS-2CE16D0T-EXLF
Summary of Contents for HIKVISION DS-2CE16D0T-EXLF
- Page 1 Thank you for purchasing our product. If there are any questions, or requests, do not hesitate to contact the dealer. This manual applies to the models below: Type Model DS-2CE16D0T-EXLF DS-2CE16D0T-EXLPF Type I Camera DS-2CE16K0T-EXLF DS-2CE16K0T-EXLPF DS-2CE17D0T-EXLF Type II Camera...
- Page 2 With the philosophy of “Technology for the Good”, Hikvision requests that every end user of video technology and video products shall comply with all the applicable laws and regulations, as well as ethical customs, aiming to jointly create a better community.
- Page 3 establishing and constantly optimizing network security. Video products have made great contributions to the improvement of social security around the world, and we believe that these products will also play an active role in more aspects of social life. Any abuse of video products in violation of human rights or leading to criminal activities are contrary to the original intent of technological innovation and product development.
- Page 4 The information contained in the Manual is subject to change, without notice, due to firmware updates or other reasons. Please find the latest version of this Manual at the Hikvision website (https://www.hikvision.com/). Please use this Manual with the guidance and assistance of professionals trained in supporting the Product.
-
Page 5: Regulatory Information
UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF HUMAN RIGHTS ABUSES. IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATTER PREVAILS. Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. - Page 6 Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions”. Warnings: Serious injury or death may occur if any of the warnings are neglected.
-
Page 7: Product Features
Do not aim the camera at the sun or extra bright places. The sensor may be burned out by a laser beam, so when any laser equipment is in using, make sure that the surface of sensor will not be exposed to the laser beam. -
Page 8: Installation
Note: Press and hold the switch button for 5 seconds to switch the video output. Four kinds of video outputs are available: TVI, AHD, CVI, and CVBS. 1.2.3 Overview of Type III Camera Base Set Screw Enclosure Main Body Switch Button Power Cord Video Cable Figure 1-3 Overview of Type III Camera... - Page 9 2. (Optional) For cement ceiling, drill the screw holes with a 5.5 mm drill and insert the supplied wall plugs. 3. (Optional) Drill the cable hole, when the cables are routed through the ceiling. 4. Secure the camera to ceiling with three PA4 × 25 screws (supplied).
- Page 10 Figure 2-4 Secure Junction Box on Wall 7. Route the cables through the bottom cable hole or side cable hole of the junction box and connect the cables. 8. Fix the junction box cover on its body with three PM3 × 16 L6 screws. Figure 2-5 Fix Cover to Its Body 9.
- Page 11 Figure 2-7 Secure Base to Ceiling 6. Align the screw hole with the triangle mark to install the camera back to the base and secure it. Triangle Mark Figure 2-8 Install Camera Back 7. Connect the cables. 8. Power on the camera to check whether the image on the monitor is gotten from the optimum angle.
- Page 12 Figure 2-10 Secure Junction Box Body 6. Route the cables through the bottom cable hole or the side cable hole of the junction box. 7. Combine the junction box cover with its body and secure it with three PM3 × 13 screws. Figure 2-11 Combine Junction Box Cover and Body 8.
- Page 13 Figure 2-14 Fix Wall Mount 3. Loosen the set screw. 4. Rotate the camera to align the triangle mark with the screw hole, and disassemble the camera. Figure 2-15 Dissemble Camera 5. Use M4 × 10 screws to fix the base onto the wall mount.
- Page 14 Figure 2-18 Install Camera to Ceiling 4. Connect the cables. 5. Power on the camera to adjust the view angle according to the figure below. Figure 2-19 3-Axis Adjustment 1). Rotate the enclosure to adjust the pan position [0° to 360°]. 2).
-
Page 15: Menu Description
Figure 2-21 Fix Wall Mount 3. Use three PM4 screws to fix the installation plate onto the wall mount. Figure 2-22 Fix Installation Plate 4. Refer to steps 3 to 5 of Section 2.3.1 Ceiling Mounting without Junction Box to finish installation. Figure 2-23 Finish Installation 3 Menu Description Please follow the steps below to call the menu. -
Page 16: Video Format
VIDEO FORMAT EXPOSURE MODE EXPOSURE BACK EXIT SAVE & EXIT LIGHTING MODE WHITE LIGHT BACK LIGHTING EXIT SETTINGS SAVE & EXIT IMAGE MODE WHITE BALANCE BRIGHTNESS CONTRAST VIDEO SHARPNESS SETTINGS SATURATION BACK MAIN MENU EXIT SAVE & EXIT CANCEL FACTORY DEFAULT CONFIRM EXIT... - Page 17 GLOBAL GLOBAL refers to the normal exposure mode which adjusts lighting distribution, variations, and non-standard processing. BLC (Backlight Compensation) BLC (Backlight Compensation) compensates light to the object in the front to make it clear, but this may cause over-exposure of the background where the light is strong.
-
Page 18: Video Settings
3.4 VIDEO SETTINGS Move the cursor to VIDEO SETTINGS and click Iris+ to enter the submenu. IMAGE MODE, WHITE BALANCE, BRIGHTNESS, CONTRAST, SHARPNESS, SATURATION, and DNR are adjustable. VIDEO SETT INGS IMAGE MO DE WHITE BALANC E BRIGHTNESS CON TRAST SHARPNESS SATURATIO N BACK... -
Page 19: Factory Default
3.5 FACTORY DEFAULT Reset all the settings except video format to factory defaults. 3.6 EXIT Move the cursor to EXIT and click Iris+ to exit the menu. 3.7 SAVE & EXIT Move the cursor to SAVE & EXIT and click Iris+ to save the settings and exit the menu.
