Chapter 4
Parameters and Function Codes
58
Parameter
Description
Number
P090
Skip Frequency 1 Lower Limit
P091
Skip Frequency 1 Upper Limit
P092
Skip Frequency 2 Lower Limit
P093
Skip Frequency 2 Upper Limit
P113
Flying Start-Initial Output Voltage Percentage (%)
P114
Flying Start-Current Comparison Delay For Motor Speed
Search (ms)
P115
Flying Start-Current Threshold For Successful Motor
Speed Search
P198
HECS Rated Current (A)
P199
Motor Rated Current (A)
P200
Ia Motor Current Memory Address
P201
Motor Ia Scaling Correction Factor
P202
Ib Motor Current Memory Address
P203
Motor Ib Scaling Correction Factor
P204
Motor Uab Voltage Address
P205
Motor Uab Voltage Scaling Factor Correction
P206
Motor Uac Voltage Scaling Factor Correction
P211
Filter Time For Abnormal Output Voltage (ms)
P212
Filter Time For Output Short-Circuit (ms)
P213
Output Short-Circuit Fault Threshold
P214
Over Current Low/High Speed Region Boundary
P215
Filter Time For Output Over Current (0.1 s)
P216
High-Frequency Output Over Current Threshold
P217
Low-Frequency Output Over Current Threshold
P218
Filter Time For Motor Over Temperature (0.1 s)
P219
Motor Over Temperature Warning Threshold
P220
Motor Over Temperature Fault Threshold
P221
Filter Time For Output Over Voltage (ms)
P222
Output Over Voltage Fault Threshold
P223
Output Voltage Deviation Warning Threshold
P224
Output Voltage Deviation Fault Threshold
P225
Motor Over Temperature Warning Cancellation
Temperature
P226
Output Voltage Abnormality Warning Cancellation
Threshold
P227
Ground Fault Detection Scaling Correction Factor
P228
Filter Time For Ground Fault (ms)
P229
Ground Fault Warning Threshold
P230
Ground Fault Trip Threshold
P231
Filter Time For Overspeed Fault (Upper Limit)
Rockwell Automation Publication 6000-UM001B-EN-P - October 2014
Default
Modify
Lower
Upper
Value
Root
Limit
Limit
0
ON
0
75
0
ON
0
75
0
ON
0
75
0
ON
0
75
5
ON
0
100
1000
ON
0
5000
5
ON
0
100
0
ON
0
5000
0
ON
0
5000
13
ON
0
500
100
ON
0
199.99
14
ON
0
500
100
ON
0
199.99
11
ON
0
500
199.99
ON
0
199.99
199.99
ON
0
199.99
1000
ON
0
32767
10
ON
0
32767
180
ON
0
199.99
5
ON
0
100
200
ON
0
32767
120
ON
0
199.99
70
ON
0
199.99
6000
ON
0
32767
110
ON
0
199.99
120
ON
0
199.99
100
ON
0
32767
130
ON
0
199.99
60
ON
0
199.99
80
ON
0
199.99
100
ON
0
199.99
50
ON
0
199.99
100
ON
0
199.99
1000
ON
0
32767
20
ON
0
199.99
60
ON
0
199.99
100
ON
0
32767
