Electrolux N9E Installation And Operating Manual
Bratt pans
Hide thumbs
Also See for N9E:
- Installation and operating manual (26 pages) ,
- Installation and operating manual (28 pages) ,
- Installation and operating manual (28 pages)
Related Manuals for Electrolux N9E
Summary of Contents for Electrolux N9E
- Page 1 Bratt Pans Installation and operating manual * 59589F002- 2022.11 *Original instructions...
- Page 2 Foreword Read the following instructions, including the warranty terms before installing and using the appliance. Visit our website www.electroluxprofessional.com and open the Support section to: Register your product Get hints & tips of your product, service and repair information The installation, use and maintenance manual (hereinafter Manual) provides the user with information necessary for correct and safe use of the appliance.
-
Page 3: Table Of Contents
Contents A WARNING AND SAFETY INFORMATION....................5 General information ........................5 Personal protection equipment ......................6 General safety ..........................6 Protection devices installed on the appliance ..................7 Safety signs to be placed on the appliance or near its area ..............8 Reasonably foreseeable improper use .................... - Page 4 Gas models..........................20 Electrical Models ........................20 G.4.1 Switching On........................20 G.4.2 Switching Off........................21 Lifting the tank ........................... 21 H APPLIANCE CLEANING AND MAINTENANCE..................21 Care information......................... 21 Cleaning introduction........................21 Maintenance intervals........................21 Periods of non-use........................22 External parts ..........................22 Other surfaces ...........................
-
Page 5: Awarning And Safety Information
WARNING AND SAFETY INFORMATION General information To ensure safe use of the appliance and a proper understanding of the manual it is necessary to be familiar with the terms and typographical conventions used in the documentation. The following symbols are used in the manual to indicate and identify the various types of hazards: WARNING Danger for the health and safety of operators. -
Page 6: Personal Protection Equipment
Personal protection equipment Summary table of the Personal Protection Equipment (PPE) to be used during the various stages of the appliance's service life. Stage Protective Safety Gloves Glasses Safety garments footwear helmet ● ○ ○ — — Transport — ● ○... -
Page 7: Protection Devices Installed On The Appliance
Disconnect the appliance from the power supply before carrying out any installation, assembly, cleaning or maintenance procedure. • Do not remove, tamper with or make illegible the CE marking, the safety, danger and instruction signs and labels on the appliance. •... -
Page 8: Safety Signs To Be Placed On The Appliance Or Near Its Area
Safety signs to be placed on the appliance or near its area Prohibition Meaning do not remove the safety devices do not use water to extinguish fires (placed on electrical parts) Keep the area around the appliance clear and free from combustible materials. -
Page 9: Installation And Assembly
To preserve these conditions, the areas around the appliance must always be: • kept free of obstacles (e.g. ladders, tools, containers, boxes, etc.); • clean and dry; • well lit. For the Customer's complete information, the residual risks remaining on the appliance are indicated below: such actions are deemed improper and therefore strictly forbidden. -
Page 10: Water Connection
• Do not spray water or use water jets, steam cleaner or high pressure cleaner. A.14 Preventive Maintenance In order to ensure the safety and performance of your equipment, it is recommended that service is undertaken by Electrolux Professional authorised engineers every 12 months, in... -
Page 11: Parts And Accessories
Electrolux Professional Service Manuals. Please contact your local Electrolux Professional Service Centre for further details. A.15 Parts and accessories Use only original accessories and/or spare parts. Failure to use original accessories and/or spare parts will invalidate the original manufacturer warranty and may render the appliance not compliant with the safety standard. -
Page 12: Ctechnical Data
– Use of non-original components (e. g.: consumables, subject to local terms and conditions. wear and tear, or spare parts); Check on Electrolux Professional website the list of authorized customer care. TECHNICAL DATA Dataplate position IMPORTANT This instruction manual contains information relevant to various appliances. -
Page 13: Gas And Electrical Models
The meaning of the various information given on it is listed below: F.Mod. factory description of product Comm.Mod. commercial description production number code Ser.No. serial number Type ref. certification group of the appliance power supply voltage power supply frequency power input absorbed current Tipe-Bauart-Tipo construction type (fume exhaust system) -
Page 14: Dgeneral Information
AS5601-gas installation, health authorities and any other maintenance, cleaning, repair and trans- statutory regulations. port personnel. Manufacturer Electrolux Professional SpA or any other Introduction service centre authorised by Electrolux This manual contains information relevant to various applian- Professional SpA. ces. The product images in this guide are only an example. -
Page 15: D.10 Customer Packaging Checks
• non-application of the current provisions in the country of • The driver must sign the dispatch note: the forwarder can use, concerning safety, hygiene and health in the workplace. reject the claim if the dispatch note is not signed (the forwarder can provide the necessary form). -
Page 16: Installation On Base, Oven, Bridge, Cantilever Frame Or Cement Plinth
• Secure the plate with two flat head M5 screws provided (detail “1D“). Electrical appliances Gas connection E.7.1 Introduction CAUTION This appliance is arranged and tested to operate with G20 gas 20 mbar (for AUS- TRALIA: Natural gas 1.0 kPa or propane 2.65 kPa). -
Page 17: Connection
Gas appliances regulations A supply line with insufficient flow will affect correct operation of the appliances connected to it. IMPORTANT Incorrect levelling of the appliance can affect combustion and cause malfunctioning. E.7.4 Connection 1. See the installation diagram for the position of the gas connection on the bottom of the appliance. -
Page 18: Replacing The Adjustment Spring Of The Pressure Regulator (Only For Australia)
E.10 Replacing the adjustment spring of the E.11.1 Electrical appliances pressure regulator (Only for Australia) To replace the spring “D“ of the pressure regulator with one suitable for the gas pressure type indicated in table “B“ (see Appendix) proceed as follows: 1. -
Page 19: Equipotential Node And Earth Connection
E.16 Water connection The contact opening max. distance and leakage current must comply with the local safety regulations. IMPORTANT • Carry out the water connection by referring to E.14 Equipotential node and Earth paragraph A.10 Water connection. connection • If the water pressure is higher than that specified, use a pressure reducer to avoid damaging the Connect the appliance to an earth;... -
Page 20: Water Filling
• Spread a layer of oil (2mm) in the tank and heat at minimum The green indicator “G“ signals that the power is on. until drying it; The yellow indicator “B“ signals the heating phase. • Clean the braiser thoroughly, drying it. The red indicator “R“... -
Page 21: Switching Off
IMPORTANT lighting up of yellow indicator “B“ signals the heating Always lift the lid before lifting the tank. phase; NOTE! Automatic lifting A safety device prevents the heating element • Use the controls “C“ for power-operated lifting of the tank. from switching on if the braiser is not com- pletely lowered. -
Page 22: Periods Of Non-Use
Maintenance, inspections, checks and Frequency Responsability cleaning Ordinary cleaning • Daily • Operator • general cleaning of appliance and surrounding area Mechanical protection devices • Every 6 months • check their condition and for any deformation, • Service loosening or removed parts Control •... -
Page 23: Internal Parts (Every Year)
Maintenance contacts (only for Australia) For service and spare parts, please contact: • Electrolux Professional – Electrolux Professional Australia Pty Ltd – 5–7 Keith Campbell Court – Scoresby, 3179 – call 03-9765- 8444 • Zanussi - Electrolux Professional Australia Pty Ltd – 5–7 Keith Campbell Court — Scoresby, 3179 – call 03-9765-8444 •... -
Page 24: Kenclosed Documents
ENCLOSED DOCUMENTS • Set of test and inspection documents. • Installation diagram. • Wiring diagram. • Declaration of Conformity... - Page 26 Electrolux Professional SPA Viale Treviso 15 33170 Pordenone www.electroluxprofessional.com...
