Product and cut-out dimensions modular combiset program electric barbeque

Advertisement

Product and Cut-out Dimensions

Modular Combiset Program

Electric Barbeque

KM411

Location Codes

E - 5 foot - 208-240 Volt - 15 Amp 3-wire
power supply connects rear right
bottom.

Notes

• All installations must be done in
accordance with local codes.
• Unit height includes 2" for drain valve.
• Recommend 13" space below drain valve
for cleaning unit.
6"
E
1 1/2" min.
NOTE: Drawing is not to scale.
SPECIFICATION SHEETS 010802
