Cudy GS108D Quick Installation Manual

3
Main Features
IEEE802.3 10Base-T,IEEE802.3u 100Base-TX,
Standards
IEEE802.3ab 1000Base-T,IEEE802.3az
10BASE-T: UTP category 3,4,5 cable (maximum 100m)
Network Media
100BASE-Tx: UTP category 5, 5e cable (maximum 100m)
(Cable)
1000BASE-T: UTP category 5e, 6 cable (maximum 100m)
Number of Ports 8 x 10/100/1000Mbps Auto-Negotiation ports
LED Indication Power, Link/Act LEDs
Transfer Method Store-and-Forward
Switching Capacity 16Gbps
Power Input: DC 5V /1A(adapter)
Max2.3W
Consumption
10Mbps: 14880pps
Frame Filtering
100Mbps: 148800pps
and Forward Rate
1000Mbps: 1488000pps
Dimensions 143*72.7*26.9mm (L x W x H)
Operating Temperature: 0℃-40℃
Working Humidity: 10%-90%(non-condensing)
Environment
Storage Temperature: -40℃-70℃
Storage Humidity: 5%-90%(non-condensing)
CE Mark Warning
This is a class B product. In a domestic environment, this product
may cause radio interference, in which case the user may be
required to take adequate measures.
EU declaration of conformity
Cudy hereby declares that the device is in compliance with the
essential requirements and other relevant provisions of directives
2014/30/EU, 2014/35/EU, 2009/125/EC and 2011/65/EU.The
original EU declaration of conformity may be found at
http://www.cudy.com/en/ce
For support and warranty, please visit: http://www.cudy.com/.
Specifications are subject to change without notice. Cudy is a
registered trademark of Shenzhen Cudy Technologies Co., Ltd.
Other brands and product names are trademarks or registered
trademarks of their respective holders.Copyright©2022 Shenzhen
Cudy Technology Co., Ltd. All rights reserved.
Quick Installation Guide
8-Port Gigabit Desktop Switch
Model: GS108D
