Taiwan Commate Computer Inc. 370SMA User Manual page 4

Expansion Slots:
BIOS :
I/O Devices :
IR Port :
USB Ports :
Sound :
ATX Power :
Others :
Operating System : - Supports Windows 3.x/95/98/2000, Windows NT, MS-DOS V6.22, OS/2, Novell, Unix,
Dimension :
1.4 Content
The motherboard box contains the following items:
One Motherboard
One IDE Ribbon Cable
One Floppy Ribbon Cable
One Serial Ribbon Cable
One Driver CD
User's Manual & Quick Installation Chart
1.5 MotherBoard Layout
- Two 32-bit PCI expansion slots
- One 32-bit AGP expansion slot
- One Audio Modem Riser (AMR ) slot
- 4Mbits Award BIOS v6.00PGN with built-in Anti-Virus, DMI, ACPI support, and green
function (Plug-and-Play BIOS)
- Supports CD-ROM/HD/SCSI/Floppy/LS120/ZIP and LAN boot up
- Supports NCR SCSI BIOS.
- One FDD control port supports two of the 5.25" or 3.5" floppy drives up to 2.88 MB.
- Two high-speed 16550 UART compatible serial ports
- One parallel ports with ECP/ EPP compatibility.
- One PS/2 mouse port
- One PS/2 Keyboard connector
- One IrDA/ASKIR compatible Infrared interface port. (Cable optional)
- Two Universal Serial Bus (USB) ports support up to 127 peripheral devices.
- ADI AD1881A Audio Codec
- AC '97 Rev 2.1 compliant
- 16-bit Stereo Full-Duplex Codec
- High quality Sample Rate Conversion (SRC) from 7kHz to 48kHz in 1Hz increments
TM
- Inside Phat
Stereo 3D sound enhancement technology
- Audio Amp Power Down Signal
- Extended 6-bit Master Volume Control
- Stereo Headphone Amplifier
- DSP 16-bit Serial Port Format, Slot 16 Mode
- Split Power Supplies ( 3.3V Digital / 5V Analog )
- Supports Modem remote Ring-On function
- Supports software power off function
- Supports RTC Wake-Up.
- Supports Wake up on LAN.
- Supports Keyboard Wake-Up.
- Supports Creative's Sound Blaster 16 compatibility for real-mode DOS games.
SCO UNIX.....Supports Windows 3.x/95/98/2000, Windows NT, MS-DOS V6.22, OS/2,
Novell, Unix, SCO UNIX.....
- 246 mm x 190 mm Micro ATX Form factor
