Preview window
Toolbar
The Toolbar simplifies the performance of certain tasks. The buttons in the
Toolbar consist of: Scan Frame, Zoom, Pan, and Pickers.

Scan Frame tool

The Scan Frame lets you create a single scan frame or multiple scan
frames in the preview image, which is the active area on which controls
and commands can be applied.
The Scan Frame can also be used to create batch scans. The current scan
frame is indicated by a marquee (cascading border). The current scan
frame can be more easily distinguished if you turn on the Smoked Glass
Background command (in the Preferences menu).

Zoom tool

The Zoom tool enlarges your view of the preview image, allowing you to
set the scan frame with greater precision if you need to. Only your view of
the preview image is changed; the actual output size of the image remains
unaffected.
Each click of the Zoom tool magnifies or reduces image view by a factor of
2. Thus, the magnification levels increase from 100% to 200%, to 400%,
to 800%, and to the maximum of 1600%.
Note: If the Info window is open, the zoom level will be indicated. This
file:///D|/sw56/adv_Preview_window_detail.htm (9 of 11) [8/15/03 3:59:29 PM]
Scan Frame
Zoom
Pan
White Picker
Black Picker
