Rulers, Unit Of Measurement - Microtek ScanMaker i700 User Manual

Preview window

Rulers, Unit of Measurement

The rulers on both sides of the preview window assist you in
measurement or in checking the alignment of your image.
The unit of measurement in the ruler can be selected in two ways: in the
Image Dimension controls located in the Settings window, or by clicking on
the ruler unit button at the 0,0 point of the rulers in the Preview window.
Depending on your selection, the rulers can mark off measurement in
these units: inch, centimeter, millimeter, point, and pixel. The pixel option
is dimmed if the selected resolution unit is lpi, and vice versa.
To select the unit of measurement for the rulers:
Click on the unit box in the Settings window, or click on the ruler unit
button at the 0,0 point of the rulers in the Preview window. When the
submenu appears, select the unit of measurement.
Switch icon
This icon enables you to change/switch to the Advanced Control Panel and
the Standard Control Panel, respectively.
Maximize
To maximize the Preview window, click on the Maximize
the top left corner of the Preview window title bar.
Minimize
To minimize the Preview window, click on the Minimize
the top left corner of the Preview window title bar.
file:///D|/sw56/adv_Preview_window_detail.htm (8 of 11) [8/15/03 3:59:29 PM]
Maximize
Minimize
icon located on
icon located on
