ADS7041EVM-PDK Kit Operation
6.3
Capturing Data with the ADS7041-PDK
Access the Data Capture page in the GUI to monitor data acquired by the ADS7041. This GUI page
displays the acquired data versus time. To access the Data Capture page, hover the cursor over the blue
arrow at the left center side of the GUI screen; a menu with different GUI pages appears. Click on the
Data Capture option in the menu as shown in
12
ADS7041EVM-PDK
Figure
Figure 14. Open the Data Capture Page on the GUI
Copyright © 2014, Texas Instruments Incorporated
14.
www.ti.com
SBAU239 – November 2014
