Summary of Contents for Buhler FK358
-
Page 3: Table Of Contents
Swath Roller TABLE OF CONTENTS DESCRIPTION PAGE NUMBER Warranty ............1 Operation ............2 General Safety..........3 Assembly ............3 8’ Swath Roller Drawing ....... 4 8’ Swath Roller Parts List........ 5 10’ Swath Roller Drawing ......7 10’ Swath Roller Parts List......7 & 8 Shipping Bundles .......... -
Page 4: Warranty
Swath Roller WARRANTY POLICY Buhler Manufacturing products are warranted for a period of twelve (12) months (90 days for commercial application) from original date of purchase, by original purchaser, to be free from defects in material and workmanship under correct, normal agricultural use and proper applications. -
Page 5: Operation
Swath Roller SWATH ROLLER OPERATION This machine is available in two sizes: Approximately eight feet wide and approximately 10 feet wide. The 8 foot drum is made of 16 gauge steel. The 10 foot drum is made of 14 gauge steel and has an extra set of braces for the hitch. Frame sides have a threaded crank to adjust the drum height. -
Page 6: General Safety
Swath Roller GENERAL SAFETY Stop engine, set brake and remove ignition key before: connecting or disconnecting. servicing or making adjustments. Do not allow riders. Clear the area of people and foreign objects before starting the swather. Use hazard warning lights and a SMV sign when transporting. ASSEMBLY Center the drum shaft (#2) in the drum (#1) and tighten in place using the set screws supplied in the hubs at the ends of the drum. -
Page 7: 8' Swath Roller Drawing
Swath Roller 8’ SWATH ROLLER... -
Page 8: 8' Swath Roller Parts List
Swath Roller WHEN ORDERING PARTS Always give your dealer the Model, Color and Serial Number of your machine to assist him in ordering and obtaining the correct parts. Use the exploded view and tabular listing of the area of interest to exactly identify the required part. 8' SWATH ROLLER ITEM PART #... - Page 9 Swath Roller 32 901078 Clevis Pin 3/4" x 3 1/2" 33 900368 SMV Mounting Bracket 34 84050 3/4" S.A.E. Flat Washer (pl) 35 9812433 3/16" x 1 1/2" Cotter Pin (pl) 36 812026 5/16" x 1" Hex Bolt (pl) 37 81568 5/16"...
-
Page 10: 10' Swath Roller Drawing
Swath Roller 10’ SWATH ROLLER 10' SWATH ROLLER ITEM PART # DESCRIPTION F6551 Drum Weldment 967577 Drum Shaft Weldment 967589 Cross-Brace 967579 Hitch Weldment 967504 Hitch Clamp 967505 Crank... - Page 11 Swath Roller 901146 Right Side Frame 901147 Left Side Frame 967508 Slider Bracket 961792 1" Pillow Bearing 81599 7/16" x 1 1/2" Hex Bolt (pl) 981616 7/16" BS Flat Washer (pl) 81615 7/16" Lock Washer (pl) 81614 7/16" Hex Nut (pl) 812338 7/16"...
-
Page 12: Shipping Bundles
Swath Roller SWATH ROLLER SHIPPING BUNDLES QUANTITY BUNDLE NUMBER DESCRIPTION 8’ SWATH ROLLER: C800SR F6500 Drum Weldment F6620 Frame Bundle F6622 Hitch, Shaft, Brace Bundle F7110 Wheel 15” 10’ SWATH ROLLER: C1000SR F6551 Drum Weldment F6625 Hitch, Shaft, Brace Bundle F6626 Frame Bundle F7110... - Page 13 NOTES...
- Page 14 NOTES...
- Page 16 011-46-500-452651 (306) 781-2300 Naestved, Denmark ON, Woodstock 011-45-557-29511 (519) 539-0435 ON, Jasper (613) 283-1758 QC, Dorion (450) 455-4840 Buhler Manufacturing “a partnership” 301 Mountain Street S. Morden MB. R6M 1X7 Ph.: (204) 822-4467 Fax: (204) 822-6348 www.buhler.com Printed in Canada...
