Optional LCD Type Selector (JP5)
Power On By Keyboard (JP8)
Power On By USB 0 &1 (JP9A)
14
LCD On/Off MODE
LCD OFF
LCD ON
LCD TYPE
TFT
TFT
TFT
TFT
DSTN
DSTN
DSTN
DSTN
(default)
1 Disable
1
Disable(default)
This board is able to be turned on by a USB
keyboard hot key or a USB mouse click.
A
2~3
1~2
LCD Resolution D
1024x768x18-bit 2~3
1280x1024x18-bit 2~3
800x600x18-bit 2~3
1024x600x18-bit 2~3
1024x768x16-bit 1~2
1024x600x24-bit 1~2
800x600x16-bit 1~2
1024x768x24-bit 1~2
Enable
Enable
C B
2~3 2~3
2~3 1~2
1~2 2~3
1~2 1~2
2~3 2~3
2~3 1~2
1~2 2~3
1~2 1~2
