- Page 1 CH Series Installation, Operation & Maintenance Manual Project: _________________________ Installation: ___________________ Pump Model: ____________ Serial Number: ____________ HOMA Pump Technology, Inc. 390 Birmingham Boulevard Ansonia, CT 06401...
- Page 2 If any problems are detected contact an authorized Homa Pump Technology SAFETY PRECAUTIONS: Representative immediately. Only trained qualified personnel shall be utilized for installation and start-up.
- Page 3 Single wire systems utilize one POWER LEAD WIRING energizing conductor, and the pump casing and HOMA CH Series pumps may be provided with neutral lead as the ground or return portion of 1 or more cables, depending on motor the circuit.
- Page 4 If this is not possible, ensure all debris is upright (horizontal) position. removed from wet well. For Flanged Discharge CH Series pumps, attach Make sure to use lifting equipment that has the guide claw flange to the pump discharge...
- Page 5 CH Series INSTALLATION OF PUMPS WITH For three phase motors, if the starting jerk is in RING STANDS: the clockwise direction, open the circuit breaker to isolate power and interchange two of the three The ring stand design allows for simple phase leads inside the control panel.
- Page 6 Short to ground in cable or motor winding. or performance difficulties. Control panel circuit breaker open. Actual system head is higher than All HOMA pumps are factory tested, yet calculated or specified. startup difficulties can occur with any Incorrect impeller rotation direction.
- Page 7 Authentic Homa Pump Note: Explosion Proof cables are sealed with a Technology parts shall be used to maintain Factory Mutual Approved potting compound.
- Page 8 CH Series CH Series CH Series (1.6 or 2.4 motors) 1 Phase Connection Diagram Note: CH Pumps ( except XP) pumps have internally Ground Lug - For auxiliary wired thermal switches. These pumps use 4 conductor cable. grounding to earth or grounding grid.
- Page 9 CH Series CH Series 3 Phase Connection Diagram Note: CH Series pumps( except XP) pumps that have internally Ground Lug - For auxiliary wired thermal switches use 4 conductor cable. grounding to earth or grounding grid. 4 Conductor Cable 7 Conductor Cable Seal Probe Connections Pg.
-
Page 10: Start-Up Report
START-UP REPORT This report is designed to insure the customer that customer service and a quality product are the number one priority with Homa Pump Technology Inc. Please answer the following questions completely and as accurately as possible. Mail this form to: HOMA PUMP TECHNOLOGY INC. - Page 11 Flow: Does Station Appear To Operate At Proper Rate__________________________________ Vibration Level :Measured ______________________ Observed__________________________ COMMENTS:___________________________________________________________________ Equipment Difficulties During Start-Up:_______________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ I Certify this Report to be accurate. Authorized Homa Service Representative ______________________________________________________________________________ (Signature) DATE_______________________ Pump Station Owner/ Operator ___________________________________________________________________________ (Signature) DATE _______________________ Pg.
