  • Page 1 Products Solutions Services BA00428G/00/EN/03.18 71427110 2018-12-28 Operating Instructions TMD1000 TMD1 Digital Transmitter Module Setting and Adjustment...
  • Page 2 TMD1000 TMD1 Order code: XXXXX-XXXXXX Ser. no.: XXXXXXXXXXXX Ext. ord. cd.: XXX.XXXX.XX Serial number www.endress.com/deviceviewer Endress+Hauser Operations App A0023555 Endress+Hauser...

  • Page 3: Table Of Contents

    TMD1000 TMD1 Table of contents Table of contents About this document ....4 Document function .....

  • Page 4: About This Document

    About this document TMD1000 TMD1 About this document Document function These Operating Instructions contain all the information that is required during various phases of the life cycle of the device: from product identification, incoming acceptance and storage, to mounting, connection, operation and commissioning through to troubleshooting, maintenance and disposal.
  • Page 5 TMD1000 TMD1 About this document Symbol Meaning Phillips screwdriver A0011219 Allen key A0011221 Open-ended wrench A0011222 1.2.4 Symbols for certain types of information Symbol Meaning Permitted Procedures, processes or actions that are permitted Preferred Procedures, processes or actions that are preferred...
  • Page 6 About this document TMD1000 TMD1 Symbol Meaning Hazardous area Indicates the hazardous area Safe area (non-hazardous area) Indicates the non-hazardous area 1.2.6 Device symbol Symbol Meaning Safety instructions Observe the safety instructions contained in the associated Operating Instructions. Temperature resistance of the connection cables Specifies the minimum value of the temperature resistance of the connection cables.

  • Page 7: Documentation

    • The W@M Device Viewer: Enter the serial number from the nameplate (www.endress.com/deviceviewer). • The Endress+Hauser Operations App: Enter the serial number from the nameplate. 1.3.1 Technical Information The Technical Information contains all the technical data on the device and provides an overview of the accessories and other products that can be ordered for the device.

  • Page 8: Basic Safety Instructions

    Basic safety instructions TMD1000 TMD1 Basic safety instructions Requirements for personnel The personnel for installation, commissioning, diagnostics and maintenance must fulfill the following requirements: ‣ Be specialists who are trained and have a relevant qualification for this specific function and task.

  • Page 9: Operational Safety

    Modifications to the device Unauthorized modifications to the device are not permitted and can lead to unforeseeable dangers: ‣ If modifications are nevertheless required, contact your Endress+Hauser Sales Center. Repair To ensure continued operational safety and reliability: ‣ Carry out repairs on the device only if they are expressly permitted.

  • Page 10: Product Description

    Product description TMD1000 TMD1 Product description Product design 3.1.1 Module types The following table lists the types of modules and the description of each of them. Name Functions Size Number of Remarks terminals for standard use Main CPU - B CPU module Be sure to install one module.
  • Page 11 TMD1000 TMD1 Product description 3.1.2 Motherboard Each module size A, B, and C indicates the maximum size to be installed. Modules in size A, B, and C can be installed in the size A slot. A0038064  1 Configuration of the motherboard...
  • Page 12 Product description TMD1000 TMD1 A0038065  2 Sample of module installation Size B Size A Size C 3.1.3 Combining modules A maximum of five option modules can be installed. The total number of module terminal lines and limitations due to module size are as described above.
  • Page 13 TMD1000 TMD1 Product description 3.1.5 Main CPU-B Main CPU-B is an essential component that governs TMD1' s control and calculation, and therefore it is a necessity. It also has HART input and output functions. Settings are as follows: HART operation mode...
  • Page 14 Product description TMD1000 TMD1 Operation check by LED LED1 and LED 2 have different meanings. Color Descriptions LED1 Green Flashing while CPU is operating. LED2 Orange Flashing while CPU is resetting. LED3 and LED4 have different meanings depending on how they are combined.

  • Page 15: Installation

    TMD1000 TMD1 Installation Installation Module installation Installation procedure 1. Turn off the main power, then open the electrical compartment lid. 2. Remove the module bracket. 3. Insert the module in the slot. 4. Install the module bracket. 5. Follow the terminal table to connect assigned connectors to modules.

  • Page 16: Adjustment And Setting

    Endress+Hauser Sales Center. Contact Input (Status) This is used when transmitting status signals around a device to a receiver via 2-way communication. If 5 points or more are needed, contact your Endress+Hauser Sales Center. 5.1.2 Module configuration and names...
  • Page 17 TMD1000 TMD1 Adjustment and setting 5.1.3 Module setting Exp-A is installed in slot 1 and connected to Main CPU-B with a connector. 5.1.4 2-way communication setting Switch to direct access mode in a receiver and adjust Exp-A so that it can access only the correct slave devices.
  • Page 18 Adjustment and setting TMD1000 TMD1 5.1.5 Operation check by LED Color Descriptions LED2 Orange Flashes when transmitting data LED3 Green Flashing when receiving data 5.1.6 Adjustment and operation confirmation of contact output (alarm) For details, refer to "5.5 Contact output (Alarm) Exp-A."...
  • Page 19 TMD1000 TMD1 Adjustment and setting HHT2 Operation HHT2 Status SELECT DEVICE E : I/F NEXT SELECT DEVICE E:TGM/TM NEXT PUSH MODE HHT2 ROM V5.8 MODE: NO.01 TGM MODE OPERATION ? MODE: NO.00 TGM TGM/TM DATA ? ITEM NO.01 NO. ? ITEM NO.17...
  • Page 20 Adjustment and setting TMD1000 TMD1 5.1.8 Troubleshooting 2-way communication If there is a communication error, diagnose the problem by referring to the following check points and the attached flowchart. Perform this work by displaying the data and error on the receiver as well as checking TMD1' s operation.
  • Page 21 TMD1000 TMD1 Adjustment and setting Communication error arose. Abnormal status in transmitter All tanks show All tanks Trouble in transmitter abnormal status. Refer to “Troubleshooting”. TMD opration input Selecting tank is O.K. Improper remote Tanks not work at all. is not set to “Operation”.

  • Page 22: Temperature System Thermo-A Module

    Adjustment and setting TMD1000 TMD1 Module is Install connector connected properly. to recover TMD. TMD functions properly. No module damage Replace module. TMD functions properly. Repair or replace No cable breakage cable. TMD functions properly. Cable resistance is Replace cable.
  • Page 23 TMD1000 TMD1 Adjustment and setting 5.2.2 Module configuration and names LED3 LED2LED1 MLT12 ↔ SPT4 R1 R2 R11 R12 7 10 R6R7R8 AGND3 +3V-A U5 B FET1 R24 R25 R18R19R20 C37 U19 U20 R41 U21 C38 U22 C39 U23 C17C18...
  • Page 24 Adjustment and setting TMD1000 TMD1 4. Configure a standard resistor to alternate between 0 °C resistance and 200 °C resistance, and then correct MODE: 07, ITEM: 02 so that the net temperature of MODE: 07, ITEM: 01 is ±0.1 °C.
  • Page 25 TMD1000 TMD1 Adjustment and setting 4. Select the interval of element positions (equal or unequal).  If the element position is equal, select "0" in MODE: 09, ITEM: 06. If the element position is unequal, select "1" in MODE: 09, ITEM: 06.

  • Page 26: To 20 Ma Output Dac-1

    Adjustment and setting TMD1000 TMD1 5.2.7 Operation check by LED Color Descriptions LED1 Green Flashing while CPU is operating. LED2 Flashing when CPU is reset. LED3 Flashing when an error is generated. 4 to 20 mA Output DAC-1 5.3.1 Overview This module is used to output level or temperature data as a4 to 20 mA analog signal.
  • Page 27 TMD1000 TMD1 Adjustment and setting 5.3.3 Module setting Refer to "3 Module Installation" for details on installation. When two modules are installed simultaneously in the main unit, the ID number for each modulemust be changed. Setting procedure 1. Set the first module' s ID No. to [5]. (No change is required, as this is the standard setting.)
  • Page 28 Adjustment and setting TMD1000 TMD1 5.3.4 Adjustment and operation confirmation Start Adjustment when output error is arising. Module #2 Module #1 Start Use MODE 11 Use MODE 12 Module #2 Module #1 for Adjustment. for Adjustment. Select output. ITEM 02...
  • Page 29 TMD1000 TMD1 Adjustment and setting 5.3.5 Adjustment and confirmation procedure The following procedure is described only for the first module. When there is only one module, follow the steps below to adjust the module. When installing two modules, use the same steps as follows after overwriting to MODE: 12 for the second module. (If outputting 0 to 20 mA, adjust 4 mA as 0 mA.)

  • Page 30: Parallel Output Out-3 And Out-4 Module

    Adjustment and setting TMD1000 TMD1 Parallel output OUT-3 and OUT-4 module The three specifications of output data are as follows: Spec. Descriptions LEVEL - BCD Output level value in BCD code LEVEL - SIG Output level value in SAKURA code...
  • Page 31 TMD1000 TMD1 Adjustment and setting 5.4.2 Module configuration and names PC10 PC11 PC12 PC13 PC14 PC15 PC16 PC17 PC18 PC19 PC20 PC21 PC22 PC23 PC24 OUT-4-1 A0038077  10 Output OUT-3 and OUT-4 module J2 connector for parallel output J1 motherboard connector The component layout is identical in OUT-3.
  • Page 32 Adjustment and setting TMD1000 TMD1 Setting procedure 1. Set a 6-digit output code (xxxxxx) in MODE: 05, ITEM: 04 of HHT2.  　0 through F can be used to set the data for each digit. 2. Set output code in ITEM: 04 for level A/D error.

  • Page 33: Contact Output (Alarm) Exp-A Module

    TMD1000 TMD1 Adjustment and setting Contact output (Alarm) Exp-A module 5.5.1 Setting flowchart Each data is set in MODE: 06 of HHT2. Start MODE: 06 Alarm 1 Alarm 1 ITEM ITEM Level Setting Temp. Setting 01-04 33-36 Alarm 2 Alarm 2...
  • Page 34 Adjustment and setting TMD1000 TMD1 3. Set the hysteresis operation range, and use (mm) unit for level and 0.1 ℃ unit for temperature. 4. Set the normal open or normal close. This completes the setting procedure. • If contact output (alarm) is not necessary, select NON (no alarm) for both level and temperature data.

  • Page 35: To 20 Ma Input Adc-2

    TMD1000 TMD1 Adjustment and setting r (Ω) 1.2V r (Ω) A0038080  11 Permissible load impedance of TMD1 and contact output circuit Max. 30 mA Load R (Ω) / Operating current Is DC current E (V) Determine E and R in order to satisfy the following equation.
  • Page 36 Adjustment and setting TMD1000 TMD1 5.6.2 Module configuration and names 2 C 1 ADC-2 A0038082  12 ADC-2 module Power supply switching jumper J2 connector for 4 to 20 mA output Trimmer for VR1 adjustment J1 motherboard connector 5.6.3 Module setting Refer to "4 Module Installation"...

  • Page 37: Optical Communication Odc-1 Module

    TMD1000 TMD1 Adjustment and setting Optical communication ODC-1 module NOTICE Optic fiber transmit module ODC-1 uses precision optical parts. Pay particular attention to the following: Risk of damage ‣ Do not subject the module to strong impact. ‣ Put a protection cap on the optical connector if the connector is not being used.
  • Page 38 Adjustment and setting TMD1000 TMD1 5.7.4 Module adjustment Check the transmission loss of optical fiber before conducting optical communication, and confirm that the loss is within permitted range. Set the following items using HHT2 for optical communication operation: • Select code setting •...
  • Page 39 TMD1000 TMD1 Adjustment and setting MODE NO.15 MODE OPT TRANS? ITEM NO.4 FFI LEVEL FRAG? FFI LEVEL FRAG? 0; FFI, 1; SAKURA? FFI LEVEL FRAG 0 0; FFI, 1; SAKURA? A0038085  15 Example of select code 02 setting HHT2 operation...

  • Page 40: Contact Input (Status) Exp-A Module

    Adjustment and setting TMD1000 TMD1 Operation diagnosis flowchart Communication error arose. Trunk line of fiber error All tanks show All tanks Check main fiber, distribute abnormal status. repeat, star couper Refer to TMD1 Is TMD1 operation normal? Is TMD1 operation normal? troubleshooting.

  • Page 41: Drm9700 Communication Drmm-A

    TMD1000 TMD1 Adjustment and setting 5.8.2 Operation confirmation The input signal is set as contact OFF (open) and valid signal (logic "1"). Confirm that the signal can be transmitted properly to a receiver corresponding to SHORT or OPEN at signal input terminal.

  • Page 42: Output For External Device Operation Cnt-2

    Adjustment and setting TMD1000 TMD1 5.9.4 Operation check by LED Color Descriptions LED1 Green Lit while TMD1 is operating. LED2 Flashing when CPU is reset. LED3 Flashing when receiving data from motherboard. 5.10 Output for external device operation CNT-2 module Unless stipulated by law, etc., do not open the lid in energized state in hazardous locations.

  • Page 43: Level A/D Conversion Mif4 Module

    TMD1000 TMD1 Adjustment and setting 5.11 Level A/D conversion MIF4 module 5.11.1 Overview MIF4 module is used for level A/D conversion. This circuit board reads the encoder and counter values, and after converting their values, it transmits the level value to CPU board.

  • Page 44: Alarm Contact Output Cd-688 Module

    Adjustment and setting TMD1000 TMD1 5.11.4 Operation check by LED Color Descriptions LED1 Green Flashing while CPU is operating. LED2 Lit when there is a counter error (once it occurs, it will last until the main power is cut) LED3...

  • Page 45: Index

    TMD1000 TMD1 Index Index Symbols Application ....... . . 8 Safety Instructions Basic .
