BendPak RBJ25000 Service Manual

Rolling bridge jack
Hide thumbs Also See for RBJ25000:

Advertisement

Quick Links

Download this manual
Service Manual
SERVICE PARTS & DIAGRAMS
BENDPAK
RBJ25000
PRODUCT SKU
5175033
DRAWING Nº
5260544
CATEGORY
Rolling Bridge Jack
REV
Version V
DATE
12.15.2022
This guide is a troubleshooting reference used for maintaining and
servicing your Bend Pak product. It provides comprehensive information
on identifying serviceable parts and components and assists in
troubleshooting problems and performing assembly /disassembly
procedures.
BendPak, Inc. Corporate Office
1645 Lemonwood Drive
Santa Paula, CA 93060 USA
Toll Free US/Canada: 1-800-253-2363
Fax: 1-805-933-9160
info@bendpak.com
Customer Service Desk / Warranty
Customer Service Representatives
Office Tel: 1-805-933-9970
Toll Free US/Canada: 1-800-253-2363
Fax: 1-805-933-9160
customerservice@bendpak.com
Parts Orders
Customer Service Representatives
Office Tel: 1-805-933-9970
Toll Free US/Canada: 1-800-253-2363
Fax: 1-805-933-9160
parts@bendpak.com
Domestic Sales & Service
USA Sales Representatives
Office Tel: 1-805-933-9970
Toll Free US/Canada: 1-800-253-2363
Fax: 1-805-933-9160
sales@bendpak.com
International Sales & Service
Office Tel: 1-805-933-9970
Exports Dept: 1-805-933-9970 EXT. 192
Ext. Toll Free US/Canada: 1-800-253-2363
Fax: 1-805-933-9160
bpkexports@bendpak.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the RBJ25000 and is the answer not in the manual?

Questions and answers

Related Manuals for BendPak RBJ25000

Summary of Contents for BendPak RBJ25000

  • Page 1 Bend Pak product. It provides comprehensive information on identifying serviceable parts and components and assists in troubleshooting problems and performing assembly /disassembly procedures. BendPak, Inc. Corporate Office Customer Service Desk / Warranty Parts Orders Domestic Sales & Service International Sales &...
  • Page 2 PROPRIETARY AND CONFIDENTIAL APPLY LIQUID THREAD SEALANT TO FITTINGS PRIOR TO ASSEMBLY. THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF BENDPAK INC. ANY SEE BP SPECIFICATION FORM 5580012 REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: 1:10 THE WRITTEN PERMISSION OF BENDPAK INC.
  • Page 3 5205006 AIR HYDRAULIC PUMP MUST BE INSTALLED USING THE PROPRIETARY AND CONFIDENTIAL THE INFORMATION CONTAINED IN THIS DRAWING IS 5260279 THE SOLE PROPERTY OF BENDPAK INC. ANY INCLUDED BOLTS REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: 1:12 THE WRITTEN PERMISSION OF BENDPAK INC. IS...
  • Page 4 DETAIL A SCALE 1 : 4 1645 LEMONWOOD DR. SANTA PAULA, CA 93060 TITLE: RBJ18000/25000 LIFT SUPERSTRUCTURE SIZE DWG. NO. 5205006 SCALE: 1:12 SHEET 2 OF 2...
  • Page 5 5250117 PROPRIETARY AND CONFIDENTIAL THE INFORMATION CONTAINED IN THIS DRAWING IS 5260279 THE SOLE PROPERTY OF BENDPAK INC. ANY SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: THE WRITTEN PERMISSION OF BENDPAK INC. IS...
  • Page 6 5215180 UNLESS OTHERWISE SPECIFIED PROPRIETARY AND CONFIDENTIAL NEXT ASSEMBLY THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF BENDPAK INC. ANY ASSEMBLE ITEMS AS SHOWN REPRODUCTION IN PART OR AS A WHOLE WITHOUT 5205006 SCALE: THE WRITTEN PERMISSION OF BENDPAK INC. IS SHEET 1 OF 1 PROHIBITED.
  • Page 7 NOTE: UNLESS OTHERWISE SPECIFIED. 5215456 PROPRIETARY AND CONFIDENTIAL NEXT ASSEMBLY THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF BENDPAK INC. ANY ASSEMBLE ITEMS AS SHOWN REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: 5205006 THE WRITTEN PERMISSION OF BENDPAK INC. IS SHEET 1 OF 1 PROHIBITED.
  • Page 8 PROPRIETARY AND CONFIDENTIAL 10,000 PSI / 700 BAR WORKING PRESSURE THE INFORMATION CONTAINED IN THIS DRAWING IS 5205012 THE SOLE PROPERTY OF BENDPAK INC. ANY 40,000 PSI / 2800 BAR MIN. BURST PRESSURE REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: 5205013 THE WRITTEN PERMISSION OF BENDPAK INC.
  • Page 9 PROPRIETARY AND CONFIDENTIAL DIMENSIONS SHOWN ARE AFTER PAINTING THE INFORMATION CONTAINED IN THIS DRAWING IS NEXT ASSEMBLY THE SOLE PROPERTY OF BENDPAK INC. ANY PAINT BENDPAK BLACK (RAL-9017) 20% GLOSS REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: THE WRITTEN PERMISSION OF BENDPAK INC. IS...
  • Page 10 REMOVE ALL WELD SPLATTER PROPRIETARY AND CONFIDENTIAL THE INFORMATION CONTAINED IN THIS DRAWING IS NEXT ASSEMBLY THE SOLE PROPERTY OF BENDPAK INC. ANY 5746625 MUST TURN FREELY REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: THE WRITTEN PERMISSION OF BENDPAK INC. IS...
  • Page 11 Date: 10/27/2020 ECO : 1. Engineering Specification Application: INSTALLATION MANUAL Detailed Description: Print Settings for BendPak Manuals Unless otherwise specified, use these settings for printing BendPak manuals:  Color: Black and white.  Size: A4 (210 to 297 mm), 8.5 by 11 inches (216 to 279 mm), or between ...
  • Page 12 RBJ Series (15, 18, 25) Product Decal Positioning WARNING SERVICE REQUIREMENT purpose lithium based grease, penetrating oil or jack unit and pump unit. If you choose to have 90-wt gear oil. Use enough lubrication to prop- this equipment serviced by a service technician, EVERY 30-DAYS erly maintain all moving parts, but avoid over always perform a personal inspection of all points...
