INSTALLATION AND OPERATION MANUAL
COMMERCIAL GRADE
ROLLING BRIDGE JACKS
MODELS:
RJ-45; RJ-45S; RJ-6;
RJ-7: RJ-9; RJ-12;
RJ-15; RJ-18; RJ-25.
Keep this operation manual near the
machine at all times. Make sure that
ALL USERS read this manual.
SHIPPING DAMAGE CLAIMS
When this equipment is shipped, title passes to the
purchaser
upon
Consequently, claims for the material damaged in
shipment must be made by the purchaser against the
transportation company at the time shipment is received.
PLEASE READ THE ENTIRE CONTENTS OF THIS MANUAL PRIOR TO
INSTALLATION AND OPERATION. BY PROCEEDING YOU AGREE THAT
YOU FULLY UNDERSTAND AND COMPREHEND THE FULL CONTENTS OF
THIS MANUAL. FORWARD THIS MANUAL TO ALL OPERATORS. FAILURE TO
OPERATE THIS EQUIPMENT AS DIRECTED MAY CAUSE INJURY OR DEATH.
receipt
from
the
BE SAFE
Your new lift was designed and built with safety in
carrier.
mind. However, your overall safety can be increased by
proper training and thoughtful operation on the part of the
operator.
equipment
the
important safety instructions shown inside.
RJ-6 shown
DO
NOT
operate
without
reading
this
1645 Lemonwood Dr.
Santa Paula, CA. 93060, USA
Toll Free 1-800-253-2363
Tel: 1-805-933-9970
Fax: 1-805-933-9160
REV D 05-16-10
p/n 5900034
or
repair
this
manual
and
www.bendpak.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for BendPak RJ-45
Summary of Contents for BendPak RJ-45
- Page 1 REV D 05-16-10 p/n 5900034 INSTALLATION AND OPERATION MANUAL COMMERCIAL GRADE ROLLING BRIDGE JACKS MODELS: RJ-45; RJ-45S; RJ-6; RJ-7: RJ-9; RJ-12; RJ-15; RJ-18; RJ-25. RJ-6 shown Keep this operation manual near the machine at all times. Make sure that ALL USERS read this manual.
