- Page 1 TINED WEEDER AS 300 M1, AS 600 M1, AS 900 M1, AS 1200 M1 OPERATING MANUAL PLEASE READ CAREFULLY BEFORE START-UP! Translation of the original operating manual Version: 2.0 EN-US; item number: 00602-3-617...
-
Page 2: Table Of Contents
SAFETY SIGNS ..........................10 OPERATING MANUAL ......................... 12 Implement description ......................12 8.1.1 Instructions for the AS 300 M1 ................... 12 Attachment on the tractor ....................12 Safe parking AS 300 M1 ....................12 Safe parking AS 600 M1 / AS 900 M1 rigid ................ 12 Safe parking AS 900 M1 scissors folding / AS 1200 M1 ............. - Page 3 CROP CULTIVATION TIPS FOR USING THE TINED WEEDER..........25 INFORMATION ON NATURE CONSERVATION AND ENVIRONMENTAL PROTECTION ..26 16.1 Reduction of noise exposure in use ................... 26 16.2 Energy-efficient use ......................26 16.3 Recyclable raw materials and disposal ................26 ACCESSORIES ..........................
-
Page 4: Ec Declaration Of Conformity
If the mounted implements are modified without prior consultation with APV-Technische Produkte this declaration shall lose its validity. -
Page 5: Conformity Assessed
If the mounted implements are modified without prior consultation with APV-Technische Produkte this declaration shall lose its validity. -
Page 6: Identification Of The Implement
For spare parts orders. To commission service and maintenance tasks Service address: APV - Technische Produkte GmbH Telephone: +43 2913 8001-5500 Zentrale: Dallein 15 Fax: +43 2913 8002 3753 Hötzelsdorf Email: service@apv.at AUSTRIA... -
Page 7: Warranty
To activate the warranty for your implement, simply scan the QR code with your smartphone – you will then be taken directly to the Service area of our website. Of course, you can also activate the warranty through our website www.apv.at in the Service area. -
Page 8: General Safety Information And Accident Prevention Regulations
The implement is intended for outdoor operation in dry weather, within a temperature range from +5 °C to 40 °C. Water ingress must be prevented. Do not use the implement in rainy conditions! GENERAL SAFETY INFORMATION AND ACCIDENT PREVENTION REGULATIONS ... -
Page 9: Risks Involved With Use (Mounted Implements)
Lock the track marker in transport position! The view of the attached Tined Weeder and of the dangerous movement zone must be ensured (to monitor the process). We recommend a cleaning in accordance with the maintenance instructions. The procedures in the maintenance manual must be complied and personal protective equipment must be used. -
Page 10: Risks When Performing Maintenance (Service, Tires)
Before tasks on the hydraulic system, set down the implement, depressurize the system, and turn off the engine! Only detach the securing chains after they have been slackened! (The cylinder must be filled with oil) RISKS WHEN PERFORMING MAINTENANCE (SERVICE, TIRES) ... - Page 11 Loading hook Fasten the cable or chains here when loading the implement! Lift the implement off of the ground and only Be careful if high- Nobody is allowed fold it in or fold it out pressure fluid escapes! between the machines slowly.
-
Page 12: Operating Manual
IMPLEMENT DESCRIPTION The Tined Weeder AS 300 M1 | AS 600 M1 | AS 900 M1 | AS 900 M1 scissors folding | AS 1200 M1 is a soil tillage implement that can be attached to a towing vehicle by means of the three-point hitch. -
Page 13: Safe Parking As 900 M1 Scissors Folding / As 1200 M1
Figure 4: AS 600 M1 Figure 5: AS 900 M1 rigid For hydraulic folding, the securing chains must be hooked into the side wings, and in addition the shut-off valve (if present) that is located on the folding cylinder must be closed. Thereafter the hydraulic hoses to the tractor must be depressurized. -
Page 14: Tined Weeder Trial Folding (For Hydraulic Folding)
Figure 8 Figure 9 TINED WEEDER TRIAL FOLDING (FOR HYDRAULIC FOLDING) CAUTION! Ensure that no one is standing in the danger area! CAUTION! Fold the implement only when it is lifted off the ground. Proceed as follows for the test folding (unfolding and folding): 1) Couple the hydraulic line connectors. -
Page 15: Working Position And Setting The Working Depth
WORKING POSITION AND SETTING THE WORKING DEPTH The working speed has a significant determining influence on the intensity of the weeding. The normal speed range is between 4 and 12 km/h, depending on crop sensitivity and growth stage. Optimum results are achieved starting at a speed of 6 km/h. -
Page 16: Hydraulic Tine Adjustment
CAUTION! Avoid cornering. However, should it be necessary, then these curves must be driven in a very large radius. HYDRAULIC TINE ADJUSTMENT With the hydraulic tine adjustment (can be retrofitted for AS 600 M1 to AS 1200 M1), a double-acting hydraulic cylinder is installed on each tine section. -
Page 17: Calculation Of The Weight Ratios Of Axle Loads On The Tractor Unit And Ballasting
CALCULATION OF THE WEIGHT RATIOS OF AXLE LOADS ON THE TRACTOR UNIT AND BALLASTING Implements with a 3-point mounting change the total weight and the axle loads of the tractor unit. These values must not exceed the permissible dimension. In this regard, also comply with the load-bearing capacity of the tires. -
Page 18: Table Of Weight Ratios
The manufacturer is not liable for any unauthorized modifications to the implement or for the use of components or attachments on the implements that were not purchased from APV. When replacing the hydraulic hose lines, original spare parts must be used that meet the technical requirements specified by the implement manufacturer. -
Page 19: Regular Maintenance Tasks
Lubricate all lubrication points after cleaning, and uniformly distribute the lubricant in the bearing points (e.g. perform a brief test run). Do not use a high-pressure cleaner to clean bearing parts and hydraulic parts. Cleaning with excessive pressure can damage the paint. ... -
Page 20: Technical Data
TECHNICAL DATA AS 900 M1 Type designation: AS 300 M1 AS 600 M1 AS 900 M1 scissors AS 1200 M1 folding 6 rows of round spring tines loosen the soil by lightly throwing up the soil in Mode of operation::... -
Page 21: Possible Combinations For The Tined Weeder With Pneumatic Seeder
11.1 POSSIBLE COMBINATIONS FOR THE TINED WEEDER WITH PNEUMATIC SEEDER PS 120 E PS 200 E PS 200 H PS 300 E PS 300 H PS 500 E PS 500 H Dimensions for 90x60x80 100x70x90 100x70x110 110x80x100 110x80x115 125x80x120 125x80x125 PS HxWxD [cm] Weight [kg] Combined state: dimensions HxWxD [cm] and weight [kg]... -
Page 22: Hydraulic System Diagram
HYDRAULIC SYSTEM DIAGRAM 12.1 AS 600 M1, AS 900 M1 RIGID Figure 17 Implement side Coupling connector BG 2 Tractor side Throttle plate Control unit 2/2-way ball valve Coupling sleeve BG 2 Double-acting hydraulic cylinder for folding... -
Page 23: As 900 M1 Scissors Folding, As 1200 M1
12.2 AS 900 M1 SCISSORS FOLDING, AS 1200 M1 Implement side T-threaded connection Tractor side Shut-off unit Control unit Throttle plate Coupling sleeve BG 2 Double-acting hydraulic cylinder for folding Coupling connector BG 2... -
Page 24: Lighting Circuit Diagram
LIGHTING CIRCUIT DIAGRAM Legend: Right Connector, 12 V, 7-pin Right tail light Turn signal Tail light Brake light Left Left tail light Brake light Tail light Turn signal Connector and cable pin assignment: Color Function Yellow Left turn signal 54 g White Ground Green... -
Page 25: Disposal
14.3 DISPOSAL The implement must be disposed of in accordance with local waste disposal regulations for machines. CROP CULTIVATION TIPS FOR USING THE TINED WEEDER The harrow's effect is mainly based on burying, tearing out the weeds, and crumbling the soil surface. Moreover, it also stimulates tillering in cereals. -
Page 26: Information On Nature Conservation And Environmental Protection
Tined Weeder. These signs are required when you want to drive with the Tined Weeder on public roads. Order number: 07016-2-057 (AS 300 M1, AS 600 M1, AS 900 M1) 07015-2-140 (AS 1200 M1) Figure 19 17.2 ACCESSORIES KIT AS 600 TO AS 900 With this accessories kit, the AS 600 M1 can be extended to an AS 900 M1. -
Page 27: Accessories Kit For Ps 120 - 300
17.5 ACCESSORIES KIT FOR ES AND MDP Used to mount a Single Disk Spreader ES or an MDP Multi- Metering System on the AS 300 M1 Tined Weeder. Please note that it must be mounted in compliance with the standards. -
Page 28: Hydraulic Tine Adjustment
Please note that it must be mounted in compliance with the standards. Order number: For accessories kit PS without headstock (see item 17.4): 07016-2-052 (AS 300 M1, AS 600 M1, AS 900 M1) Figure 28: Illustration, platform Figure 27: Platform kit For accessories kit PS with headstock (see item 17.6):... -
Page 29: Index
19 INDEX Accessories ............ 26 Nature conservation environmental Attached implements ........9 protection ............ 26 Attachment on the tractor ....... 12 Operating instructions ........11 Calculating the weight ratios ......16 Parking ............. 12, 13 Combination possibilities ........ 21 Repair and maintenance ......... 19 Conformity ............ - Page 30 NOTES...
- Page 31 NOTES...
- Page 32 APV – Technische Produkte GmbH Zentrale: Dallein 15 3753 Hötzelsdorf, Austria Tel.: +43 2913 8001 office@apv.at www.apv.at...
