E2S AlertAlight AL112NXDC012 Instructions/Service Manual page 4

Construction Product Regulation
•
AL112NXDC024 & AL112NXDC048 are compliant to EN54-3:2001+A1+A2 & EN54-23:2010
•
VAD for use in fire detection and fire alarm systems installed in and around buildings
• Type 4 / 4X / 3R / 13, IP66, Independently tested to EN60529:1991, (IP33C Compliant to
EN54-3)
•
Type B Product, For Indoor & Outdoor use
•
Observe Precautions for handling electrostatic devices
•
-25°C to +55°C compliant to EN54-3
•
Cable Glands must be suitably sealed and meet minimum IP33 for EN54-3 applications
•
Storage Temperature: -40°C to +70°C
• Maintenance – None
• Mounting - Units can be mounted using the 2-off ø9mm holes in the mounting lugs or
through the back of the housing using the supplied gasket seal.
Approved Tones for EN54-3 Applications:
•(Alternating Tone) 800/1000Hz @ 2Hz Alternating Tone 44
•(Rising Tone) 500/1200Hz @ 0.26Hz (3.3s on, 0.5s off) Tone 8
•(Fainting Tone) 1200/500Hz @ 1Hz Tone 2
•(Continuous Tone) 800Hz Tone 21
•(Pulsed Tone) 660Hz (150mS on, 150mS off) Tone 31
•(Alternating Tone) 544Hz(100mS)/440Hz (400mS) Tone 5
Horizontal Sound Output Max Voltage (54 Vdc) LAFmax,T dB(A)
Angle Tone 44 Tone 8
15° 106.1 105.8
45° 105.2 107.2
75° 112.1 112.6
105° 111.9 112.5
135° 104.8 107.4
165° 105.2 105.8
Vertical Sound Output Max Voltage (54 Vdc) LAFmax,T dB(A)
Angle Tone 44 Tone 8
15° 107.2 107.1
45° 106 109.3
75° 113.2 113.3
105° 112.9 113.1
135° 105.5 109.3
165° 107 106.5
Horizontal Sound Output Max Voltage (54 Vdc) LAFmax,T dB(A)
Angle Tone 44 Tone 8
15° 103.3 103.7
45° 103.4 104.8
75° 109.1 110.4
105° 109.9 110.2
135° 103.4 104.8
165° 103.4 103.5
Vertical Sound Output Max Voltage (54 Vdc) LAFmax,T dB(A)
Angle Tone 44 Tone 8
15° 104.1 104.1
45° 103.4 106.4
75° 109.8 110.1
105° 109.1 109.9
135° 101.1 106.4
165° 103.6 103.1
E2S Warning Signals Impress House, Mansell Road, Acton, London W3 7QH
AL112NXDC024 / AL112NXDC048 (P2) @ 1m
Tone 2 Tone 21 Tone 31
105.1 105.4 105.2
106.3 104.1 98.7
111.9 111.7 110.1
111.7 111.7 110.2
106.4 103.8 99.2
105.2 105.3 105.1
Tone 2 Tone 21 Tone 31
105.9 107.4 105.5
107.9 104.6 100.5
112.9 113 110.8
112.7 112.8 111.4
107.7 104.7 100.3
105.9 106.4 105.3
AL112NXDC024 (P1) @ 1m
Tone 2 Tone 21 Tone 31
103.1 103.3 103.2
104.2 101.6 96.3
109.7 109.6 108.3
109.6 109.7 108.6
104 101.8 96.5
103 103.3 103
Tone 2 Tone 21 Tone 31
103.2 104.1 102.3
105.2 101.9 96.3
109.8 110.4 108.3
109.5 110 108.3
104.7 101.8 96.6
102.8 103.6 102.8
Horizontal Sound Output Min Voltage (11.5 Vdc) LAFmax,T dB(A)
Tone 5 Tone 44 Tone 8
93.9 101.2 101.6
101.6 101.3 102.9
104.8 108.1 108.5
104.8 107.9 108.4
101.6 101.1 103.2
93.8 100.8 101.5
Vertical Sound Output Min Voltage (11.5 Vdc) LAFmax,T dB(A)
Tone 5 Tone 44 Tone 8
95.5 103.1 102.8
103.7 102.2 105.4
106.1 109.2 109.3
106.1 109 108.9
104.3 101.4 105.3
95 102.6 102.1
Horizontal Sound Output Min Voltage (11.5 Vdc) LAFmax,T dB(A)
Tone 5 Tone 44 Tone 8
91.5 101 101.5
99.4 101.5 102.7
103.2 107.1 108.2
103 107.7 108.1
99.4 101.1 102.8
91.6 101 101.4
Vertical Sound Output Min Voltage (11.5 Vdc) LAFmax,T dB(A)
Tone 5 Tone 44 Tone 8
92.3 101.8 101.8
100.2 101.3 104.3
103.2 107.7 107.8
102.9 106.9 107.7
101 100.6 104.1
91.8 101.2 100.9
sales@e2s.com e2s.com
Order Code: AL112NXDC024
Voltage Range: 20-28Vdc
Nominal Voltage: 24Vdc
Max Sounder Current: P1: 280mA @
20Vdc; P2: 430mA @24Vdc
Max Beacon Current: 271mA @ 20Vdc
DP-2821-CPR-0110
S36282
Order Code: AL112NXDC048
Voltage Range: 42-52Vdc
Nominal Voltage: 48Vdc
Max Sounder Current: P1: 280mA @42Vdc;
P2: 430mA @42Vdc
Max Beacon Current: 160mA @ 42Vdc
DP-2821-CPR-0110
S36282
Tone 2 Tone 21 Tone 31
101.1 101
102.1 100.2
107.7 108.1
107.6 108.1
102.1 99.8
100.8 100.9
Tone 2 Tone 21 Tone 31
101.5 103.1
103.8 100.4
108.7 109.1
108.5 108.9
103.5 100.7
101.5 102.2
Tone 2 Tone 21 Tone 31
100.9 101
101.8 99.6
107.4 107.7
107.4 107.6
101.7 99.6
100.8 101.1
Tone 2 Tone 21 Tone 31
100.8 101.8
103.1 99.7
107.7 108.4
107.1 107.6
102.3 99.6
100.7 101.4
D221-00-201-IS Issue 3 30/06/2022
21
2821
21
2821
Tone 5
101.2 91
94.7 99
106.5 103
106.4 103
95.5 99
102 90.8
Tone 5
101.5 91.8
96.6 99.9
107.1 103
107.7 103.1
96.5 100.7
101.1 91.2
Tone 5
100.3 89.4
94.3 97.4
105.9 101.4
105.9 101.6
94.5 97.4
100.2 89.4
Tone 5
100 90.4
94.1 98.2
106.2 101.4
105.7 101.3
94.5 99.1
99.8 89.8
