This mode can be selected by pulling the pin 28(Semi/Auto) low and selecting auto mode from the front
panel. The Auto LED will blink indicating that the unit is in Semi-Auto Mode. In this mode the unit does
not automatically starts the engine after the mains has failed and mains supervision timer has expired but
waits for an external start signal pin 29(Remote Start/Stop). Once the start signal is given the unit now
functions like auto mode with 3 crank attempts.
The unit can be stopped by pulling low Pin 29(Remote Stop). Both Remote start and remote stop are one
touch and hence should not be continuously activated. These pins shall only function during semi auto
mode.
Please note: Operating Mode cannot be changed if the unit has stopped on a fault condition or the
engine is cranking.
Auto, Man., is Radio buttons and only one can be active at a time.
11.0

Setting Procedure

How to Enter in Parameter Mode
Press Next & Reset switches simultaneously. The LCD shall display, "System Parameter"
To enter System Parameter setting mode,
default password is 123 then press Next Switch. For any change in value, press
Stop switch. For next parameter,press Next Switch.
To go to next menu press Start Switch the LCD shall display "Generator Parameter"
To enter Generator Parameter setting mode press Next Switch.For any change in value, press Start
switch and
To go to next menu press Start Switch the LCD shall display "AMF Parameter"
To enter AMF Parameter setting mode press Next Switch. For any change in value, press Start
Stop switch.For next parameter,press Next Switch.
To go to next menu press Start Switch the LCD shall display "Protection Parameter"
To go to next menu press Start Switch the LCD shall display "Display History"
To View Display History mode press
To go to next menu press Start Switch the LCD shall display "Display Event"
To View Display Event mode press
To go to next menu press Start Switch the LCD shall display "Display Start/Stop"
To View Display Start/Stop mode press
To go to next menu press Start Switch the LCD shall display "Reset Service Alarm"
To enter Reset Service Alarm mode press Next Switch. The LCD shall display
"Press START to Reset
Press STOP to ESC"
The unit shall ask for confirmation to reset the service hours pressing desired Switch.
To go to next menu press Start Key the LCD shall display "Adjust Clock"
To enter Adjust Clock setting mode press Next Key. For settng up of the time, press
Stop switch.
Press Next Key the LCD shall display DD/MM/YYYY.For settng up of the date, press
and Stop switch.
To go to next menu press Start Key the LCD shall display "Reset Password"
To enter Reset Password setting mode
Press Next Key "Enter Password"
Press Next Key "Change Password"
Press Next Key the LCD shall display
Cat_ECON-06-15 -Ver1.0.
press Next Switch,the LCD shall display, "Enter Password" and
Stop switch.For next parameter,press Next Switch.
Next Switch.
Next Switch.
Next Switch.
Start switch and
switch and
Start switch
Start switch and
switch
