ASSEMBLY INSTRUCTIONS
Quadro Loop
Need help!
Boardroom table
Call us on
1300 527 665
Size: 1800mm x 1100mm
F
STEP 04
TOP VIEW
STEP 05
F
Attach beam (D) to legs (B) using nut insert in legs.
Frame looks like this. Using Allen Key, attach beam (D) with Socket (F)
See point attached
Page 5 of 6
