ASSEMBLY INSTRUCTIONS
Quadro Loop
Boardroom table
Size: 1800mm x 1100mm
STEP 01
Using Allen Key provided, attach 2 plastic brackets per leg (E)
(as per picture above) using M6x20MM (H) Socket head screw.
Connect Loop Legs (C) to Bottom of Quadro Legs (B) by using 4
bolts per leg.
www.jasonl.com.au
Need help!
Call us on
1300 527 665
STEP 02
H
Using Allen Key provided, attach M8x20MM Socket head (G)-
screw socket half way into leg for both legs (B)
G
Page 3 of 6
