Installation Instructions
Step 8: Plug the 16 pin connector on the supplied Vehicle Specific Harness (Part # NT-PEREXODNIC) into the
supplied board (Part # NT-MBCIRC-BOARD-KIT).
Step 9: Connect the 10 pin connector on Vehicle Specific Harness (Part # NT-PEREXODNIC) to the 10 pin
connector on the supplied Interface harness (Part # NT-WHNT6).
Step 10: Connect the 4 pin connector on Vehicle Specific Harness (Part # NT-PEREXODNIC) to the 4 pin
connector on the supplied interface harness (Part # NT-WHNT6).
Step 11: Cut off the Red (+12 Volts ACC) and Black (Ground) wires off of the 6-pin plug on the interface
harness.
Step 12: Connect the Red wire (+12 Volts ACC) to the Vehicle's factory accessory wire. (Fuse Box)
Step 13: Connect the Black wire (Ground) to the Vehicle's factory ground. (Radio Ground)
Step 14: Connect the Orange wire (+12 Volt Reverse Input) to the Vehicle's factory reverse wire. (Rev. Light)
Step 15: Connect one wire of the push button to +12 Volt ACC power in the vehicle and the other wire to the
white manual activation wire on the interface harness. (Not required for installations with reverse camera only)
Step 16: Connect your aftermarket cameras/video inputs to Rear Camera Input/Video Input 1 and Front
Camera Input/Video Input 2 on the interface harness.
Step 17: Make sure both dip switches on the interface are facing UP in the OFF Position. Plug the interface
harness into the interface.
See Next Page for Quick Connection Diagram >
