0x20
0x10
0x08
0x04
0x02
0x01
Command 48 Byte Data
Byte Description
0-5 Device Specific Status
6 Extended Device Status
7 Device Operating Mode
8 Standard Status 0
"Not used" bits are always set to 0.
Device does not support extended device status, all device status activity is included in the device status byte.

UNIVERSAL COMMANDS

All Universal Commands are supported as specified in the HART Universal Command Specification.
EX-MANUAL-032321
Undefined
Undefined
Undefined
Undefined
High Alarm
Low alarm
NA
NA
NA
NA
High Alarm is active if set
Low Alarm is active if set
Data
Only Byte 0 is used
Bit 1 will be set when an alarm
condition is active.
0
Not used
