mATErIALS INCLudEd IN ThIS pACkAGE

1
4
6
9
MVGP1(Optional)
2 3
5
7 8
10 11
or
WM1(Optional)
1.6M/4.0M HDMI Cable(Optional)
1. 12.1" TFT LCD Overhead Monitor with DVD Player
2. Hardware Package (P/N: 540-022)
M3 x 8mm Phillips Screws
#4.3 x 10mm Self Drilling Screws
#2.6 x 6mm Self Tapping Screws*
(*Note: For Installation of MVGP1 or WM1)
M5 x 10mm Phillips Screws
M5 x 20mm Phillips Screws
M5 x 40mm Phillips Screws
Pry Tool and Slide Knob for Dome Light Switch(P/N: 540-023) - (1 pc)
CAUtIoN: The 10mm, 20mm and 40mm screws in the hardware kit are
provided to facilitate installation. Use extreme caution when using these
screws to avoid damage to vehicle roof or other components, wiring, etc.
3. Remote Control w/ Battery (P/N: 500-003)
4. Mounting Bracket (P/N: 201-418)
5. 6 Pin Power/Dome Light Harness (P/N: 112-4270)
6. 5 Pin AV input Harness (P/N: 112-4259)
7. 5 Pin AV output Harness (P/N: 112-4260)
8. Trim Ring - Shale (P/N: 306-260)
- Pewter (P/N: 306-261)
- Black (P/N: 306-262)
9. Snap On Cover (Screen Back) - Shale (P/N: 306-266)
10. Snap On Cover (Shroud) - Shale (P/N: 306-263)
11. Wireless Headphones w/ Batteries (P/N: 136-5301)
12. Installation Guide & Owner's Manual (Not Shown)
Optional Accessories
• Game Module Package (P/N: MVGP1) See Appendix C for installation
• Smart Stream(P/N: WM1) See Appendix D for installation
• 1.6M HDMI Cable (P/N: 103-659)
• 4.0M HDMI Cable (P/N: 103-660)
4
- Pewter (P/N: 306-267)
- Black (P/N: 306-268)
- Pewter (P/N: 306-264)
- Black (P/N: 306-265)
- (1 pc)
- (1 pkg)
- (10 pcs)
- (4 pcs)
- (2 pcs)
- (4 pcs)
- (4 pcs)
- (4 pcs)
- (1 pc)
- (1 pc)
- (1 pc)
- (1 pc)
- (1 pc)
- (1 pc)
- (1 pc)
- (1 pc)
- (1 pc)
- (1 pc)
- (1 pc)
- (1 pc)
- (1 pc)
- (1 pc)
- (2 pcs)
- (1 of each)
