TABLE OF CONTENTS IMPORTANT NOTICES �������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������2 GENERAL SYSTEM CONFIGURATIONS (IR TRANSMIT AND RECEIVE MODES M1 OR M2) ���������������������������������������������������������������������������������������������3 MATERIALS INCLUDED IN THIS PACKAGE ��������������������������������������������������������������������������������������������������������������������������������������������������������������������������������4 INSTALLING THE UNIT IN A VEHICLE �����������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������5 INSTALLING THE SNAP-ON SHROUD AND SCREEN COVER �������������������������������������������������������������������������������������������������������������������������������������������������6 INSTALLING THE TRIM RING ��������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������7 GENERAL VEHICLE INSTALLATION APPROACH ����������������������������������������������������������������������������������������������������������������������������������������������������������������������8 VEHICLE PREPARATION ����������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������9 CONNECTING THE DOME LIGHTS �������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������...
System adjustments can be accomplished using the driver seat where it will not be visible, directly or indirectly, to the remote control, while seat-belts remain fastened. Enjoy your ADVENT operator of the motor vehicle. entertainment system but remember that the safety of all passengers *** Important Notices*** remains the number one priority.
GENERAL SYSTEM CONFIGURATIONS (IR TRANSMIT AND RECEIVE MODES M1 OR M2) The following is intended to provide some of the system configurations that are possible with the ADVEXL10 A Overhead LED Backlit LCD Monitor with DVD Player: The ADVEXL10 A has an option that allows the user to select from two IR transmit and receive codes (M1 or M2). This feature can be used when using two ADVEXL10 A units in the same installation or if the vehicle has an RSA (Rear Seat Audio) that uses an “A”...
INSTALLING THE UNIT IN A VEHICLE Tools Required #2 Phillips Screwdriver Multimeter to verify 12 volt DC and continuity (Do not use a test light or logic probe) #1 Phillips Screwdriver Marker pen – to mark headliner, to mark trim ring if used Utility or Razor Knife 10.
INSTALLING THE SNAP-ON SHROUD AND SCREEN COVER Installing the Shroud *NOTE: Work on a soft surface to avoid damaging the plastic. Remove the double sided tape backing from the two strips on the center section of the shroud. Hook the shroud over the dome light and align the shroud tabs 1 with the eight openings around the rim of DVD player 2 .
INSTALLING THE TRIM RING The trim ring is attached to the video monitor using the perimeter screw bosses. It is important that the screws used in this installation are not over tightened, and that the video monitor and trim ring are mounted in such a way that the assembly does not distort (or bend) when the mounting screws are tightened.
GENERAL VEHICLE INSTALLATION APPROACH Decide upon system configuration and options that will be installed (i.e.: what components, Video Game, external amp). Review all manuals to become familiar with electrical requirements and connections. Decide upon mounting locations of all components and method of mounting. Prep the vehicle by removing any interior trim necessary to gain access to vehicle’s wiring as well as all areas where interconnecting wire harnesses will need to be located.
VEHICLE PREPARATION Locate an accessory +12v power source with a good ground. These wires can be found at the ignition switch or fuse-box. Power Source • +12v when the key is in the ACC and run positions. • 0v when the key is OFF. NOTE: Always fuse the ACC +12V at the source where it is connected to the vehicle.
CONNECTING THE DOME LIGHTS The dome lights in the video monitor require three connections to the vehicle’s wiring. There are two common types of dome light circuits used, positive switched systems or negative switched systems. Positive switched systems supply voltage to the interior lights to turn ON; negative switched systems apply ground to illuminate the bulbs.
Page 13
CONNECTING THE DOME LIGHTS Positive Switched Dome Lighting Negative Switched Dome Lighting Red/Black-Lamp on To 3 pin Red/Black-Lamp ON To 3 pin Black/Red-Lamp common connector connector constant Black/Red-Lamp Common Purple/Brown-Lamp Auto on Monitor +12 VDC Purple/Brown-Lamp Auto Fused constant +12 VDC Fused Factory Dome Light Circuit constant...
INSTALLING THE MOUNTING BRACKET Installing the Mounting Bracket NOTE: The headliner may need to be cut to install the bracket. When Once all the pre-wiring is complete, locate: • Mounting Bracket cutting the headliner, make sure no wires above the headliner are cut. • (4) #8 x 3/8”...
INSTALLING THE ADVEXL10 A VIDEO SYSTEM - WIRING DIAGRAM Connect the dome light wires as shown on pages 10 and 11 of this If connecting to an external source, plug in the 12 pin AV Input install manual. Harness (P/N 112-4094) in the location shown. Connect RCA cables (not supplied) to the external source’s AV Output.
INSTALLING ADVEXL10 A VIDEO SYSTEM - MOUNTING THE UNIT Installing the ADVEXL10 A System Make all electrical connections. Attach the ADVEXL10 A unit to the mounting bracket using four M5 screws. CAUTION: The M5 screws are supplied in three different lengths (10mm, 20mm and 40mm) to facilitate proper installation. Use extreme caution when using these screws to avoid damage to vehicle roof or other components, wiring, etc.
APPENDIX A REMOVING THE TRIM RING, SNAP-ON SHROUD AND SCREEN COVER This section is intended for situations where the color of the Shroud, Screen Cover and Trim Ring need to be changed after the unit is setup for installation. NOTE: Work on a soft surface to avoid damaging the plastic. Removing the Screen Back Cover Starting from the back of the unit, carefully insert the supplied pry tool between the Housing and Screen Back Cover...
APPENDIX B INSTALLING THE OPTIONAL THICK TRIM RING This section covers only special installation considerations for the optional thick trim ring installation. If the video monitor is to be installed in a vehicle with the thick trim ring, it may need to be trimmed to fit the contour of the vehicle Headliner. Important NOTES before installing the thick trim ring: • There should be a gap between the headliner and the outer flange of the video monitor.
APPENDIX C INSTALLING THE OPTIONAL GAME MODULE (MVGP1) This section is intended as an installation guide to connect the MVGP1 Game Module to the ADVEXL10 A video system. NOTE: The MVGP1 Game Module is sold separately and is supplied with its own instruction manual. Installing the MVGP1 Game Module Turn the DVD Player over on a surface with protective covering to prevent scratches.
TROUBLESHOOTING SYMPTOM: REMEDY: No power at video monitor • Verify +12 VDC on the Red wire at 6 Pin Power/Dome Light Harness behind the video monitor. Verify a ground connection with a continuity test from a known good ground to the black wire. Power but no video or sound • Verify that the correct source is selected (DVD, USB, HDMI1, HDMI2, Media, AV, AUX, DTV, Game).
Page 21
TROUBLESHOOTING SYMPTOM: REMEDY: FM Modulator does not work • Check if radio is ON and in FM mode. • Check that radio is tuned to the same frequency as the unit is set to. • Select another FM channel. • Reposition the ADVEXL10 A Wireless FM antenna for better reception. • Install an FMDIRB (ordered separately).
