Summary of Contents for DS18 PRO-TW2L
- Page 1 PRO- TW2L OWNER'S MANUAL 4 OHMS 400W MAX 200W RMS...
- Page 2 DIMENSIONS INSTALLATION & CONNECTION OPTIONS: BATTERY BATTERY Blue LED (-) Red LED (-) Green LED (-) LED-BTC 12V DC (+)
- Page 3 To connect without LED Control Module (LED-BTC), Connect as Shown in the Following Diagram: Black wire “BK” Connected to Battery Positive (+) 12V White Color Light “R” ; “B” and “G” Connected to Battery Negative (-) Green Color Light “G” Connected to Battery Negative (-) Red Color Light “R”...
- Page 4 ’ ALUMINUM SUPER BULLET TWEETER TRANSPARENT POLYCARBONATE BODY AND BULLET FREQUENCY RESPONSE 3.5KHz-20KHz SURFACE RING BRUSHED SILVER FILM HOT STAMP CAPACITOR CROSSOVER INCLUDED 8 OZ Y30 FERRITE MAGNET ZINC PLATED TOP AND BACK PLATE 1”HIGH TEMPERATURE KAPTON VOICE COIL 1 METER RGB LED INPUT WIRE RGB LED BUILT IN BODY 200 WATTS RMS POWER 400 WATTS MAX POWER...
