OWNER'S MANUAL
PRO-ZT69
MANUAL DEL USUARIO
6X9'' COAXIAL MID-RANGE LOUDSPEAKER
WITH 1'' VC BULLET TWEETER AND
WATER-RESISTANT CONE
ALTAVOZ MEDIO RANGO COAXIAL DE 6X9"
CON TWEETER TIPO BALA CON BOBINA DE
VOZ DE 1" Y CONO RESISTENTE AL AGUA
GRILLE INCLUDED
WITH CLOTH SHADE
REJILLA INCLUIDA
CON SOMBRA DE TELA
BUILT-IN TWEETER
TWEETER INTEGRADO
ENGLISH | ESPAÑOL

Advertisement

loading
Need help?

Need help?

Do you have a question about the PRO-ZT69 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DS18 PRO-ZT69

Summary of Contents for DS18 PRO-ZT69

  • Page 1 OWNER’S MANUAL PRO-ZT69 MANUAL DEL USUARIO 6X9'' COAXIAL MID-RANGE LOUDSPEAKER WITH 1'' VC BULLET TWEETER AND WATER-RESISTANT CONE ALTAVOZ MEDIO RANGO COAXIAL DE 6X9” CON TWEETER TIPO BALA CON BOBINA DE VOZ DE 1” Y CONO RESISTENTE AL AGUA GRILLE INCLUDED...
  • Page 2 PRO-ZT69 PRO-ZT69 SPECIFICATIONS / ESPECIFICACIONES Nominal Diameter / Diámetro nominal..............6x9” / 152.4 x 228.6mm Nominal Impedance / nominal..................4 Ohms Impedancia RMS Power Handling / .................. 275W Manejo de potencia RMS MAX Power Handling / Manejo de potencia MAX .................. 550W Sensitivity (1w/1m) / ....................98 dB...
  • Page 3 Overall Depth (With Grille) / rejilla)............4" / 102mm Profundidad total (con Front Mount Baffle Cutout / Corte del orificio de montaje........5.9x8.6” / 150x219mm Mounting Depth / ................3.35” / 85mm Profundidad de montaje Motor Diameter / Diámetro del motor..................4.53" / 115mm PRO-ZT69...
  • Page 4 PRO-ZT69 SPL vs Freq dBSPL 20 Hz MEASUREMENTS WITH GRILLE / MEDIDAS CON REJILLA 6.57” / 167mm 10" / 260mm...
  • Page 5 Ø4.53” / 115mm 8.6" / 219mm 5.9" / 150mm...
  • Page 6 PRO-ZT69 MEASUREMENTS WITHOUT GRILLE / MEDIDAS SIN REJILLA 6.57” / 167mm 9.27” / 235.5mm Ø4.53" / 115mm 8.6" / 219mm...

  • Page 7: Warranty

    5.9" / 150mm WARRANTY GARANTÍA Please visit our website DS18.com for more information Visite nuestra página web DS18.com para obtener más on our warranty policy. información sobre nuestra garantía. We reserve the right to change products and specifications Nos reservamos el derecho de cambiar productos y at any time without notice.
  • Page 8 FOR MORE INFORMATION PLEASE VISIT DS18.COM We LIKE IT LOUD...
