DS18 PRO-FR6NEORGB Owner's Manual

6.5" full-range loudspeaker with rgb led bullet and neodymium mangnet

Advertisement

Available languages

Available languages

Quick Links

PRO-FR6NEORGB
OWNER'S MANUAL
MANUAL DE USUARIO
6.5" FULL-RANGE LOUDSPEAKER WITH
RGB LED BULLET AND NEODYMIUM MANGNET
ALTAVOZ DE RANGO COMPLETO DE 6.5"
CON BALA LED RGB Y MAGNETO DE NEODIMIO
LC-RGB
REQUIRED
DOWNLOAD
APP
ENGLISH | ESPAÑOL

Advertisement

loading
Need help?

Need help?

Do you have a question about the PRO-FR6NEORGB and is the answer not in the manual?

Questions and answers

Summary of Contents for DS18 PRO-FR6NEORGB

  • Page 1 PRO-FR6NEORGB OWNER'S MANUAL MANUAL DE USUARIO 6.5" FULL-RANGE LOUDSPEAKER WITH RGB LED BULLET AND NEODYMIUM MANGNET ALTAVOZ DE RANGO COMPLETO DE 6.5" CON BALA LED RGB Y MAGNETO DE NEODIMIO LC-RGB REQUIRED DOWNLOAD ENGLISH | ESPAÑOL...
  • Page 2 PRO-FR6NEORGB WITH RGB MODULE / CON MÓDULO RGB: LC-RGB (not included) (no incluido) BATTERY BATERÍA ACCESSORY SWITCH (+12V) INTERRUPTOR DE ACCESORIO (+12V) WITH RGB MODULE / CON MÓDULO RGB: Blue LED (-) / LED Azul (-) Black GROUND (-) / Negro Tierra (-)
  • Page 3 Android and iPhone. Módulo de control LED BT (LC-RGB) para Descarga la APP DS18 LC compatible con el iluminación LED RGB multifuncional (se módulo DS18 LC-RGB. Esta aplicación vende por separado). Las aplicaciones para funciona tanto con Android como con iPhone.
  • Page 4 PRO-FR6NEORGB SPECIFICATIONS / ESPECIFICACIONES: Nominal Diameter / Diámetro nominal..............6.5" / 165mm Nominal Impedance / Impedancia nominal..............4 ohms RMS Power Handling / Manejo de Potencia RMS ............225W MAX Power Handling / Manejo de Potencia MAX ............450W Sensitivity (1w/1m) / Sensibilidad (1w/1m) ..............96dB Frequency Response / Respuesta de frecuencia..........120Hz - 16KHz...
  • Page 5 Electrical Factor / Factor eléctrico ..........Qes ........0.409 Total Factor / Factor total ............Qts ........0.362 Mechanical Mass / Masa mecánica........Mms ......11.31g Mechanical Compliance / Cumplimiento mecánico....Cms ......0.08mm/N BL Factor / Factor BL ..............BL........9.79 Voice Coil Inductance / Inductancia de la bobina de voz..Le .......0.472mH Cone Area / Área del cono ............Sd......
  • Page 6: Warranty

    MEASUREMENTS / MEDIDAS: Ø3.54"/90mm Ø 5.7"/145mm WARRANTY GARANTÍA Please visit our website DS18.com for more information Visite nuestra página web DS18.com para obtener más on our warranty policy. información sobre nuestra garantía. We reserve the right to change products and specifications Nos reservamos el derecho de cambiar productos y at any time without notice.
  • Page 7 FOR MORE INFORMATION PLEASE VISIT DS18.COM We LIKE IT LOUD...
