SENSOR Board
CK-1P8
Power Cube
Promotion-On-Hold
CK-1P8
Module
Box
For the Panasonic KX-TG9471
telephone
03/14/12
Audio Cord
Introduction
with Adapter
Flat Cable
Thank you for purchasing the
Skutch CK-1P8 Promotion-On-Hold
Module for the Panasonic KX-
TG9471 two line expanded phone
system. This unit ONLY works with
this phone model. The CK-1P8 is a
true plug and play device. This unit
requires an external sound source
such as a CD or Digital Player to
provide the Promotion-On-Hold
audio. When a call is placed ON
HOLD or TRANSFERRED to
another phone, from the base or any
cordless phone, the ON HOLD caller
will hear the Promotion-On-Hold
audio. When the line is re-answered,
CK-1P8 Installed on KX-TG9471
the audio automatically stops. It's
that simple!
Installation
The SENSOR Board MUST be attached to the phone or this unit will not function. The
Sensor board MUST completely cover the LINE 1 and LINE 2 buttons on the phone.
1- Make sure that the surface on the telephone is clean and free of dust and/or oil.
2- Peel the paper protector off back side of the "SENSOR BOARD" . Carefully align as
shown in Fig. 2. The Sensor Board MUST completely cover the line selector buttons on
