Marantz RC1400 Specifications

Control Your World !
Designed for easy-to-use, intuitive control, Marantz offers a complete line of programmable system remotes.
Want to control an entire entertainment system at the touch of a button? With a Marantz programmable remote,
it's no problem. From the brand new RC1400 (Son of the world famous RC2000mkii "Remote of the Gods"),
to the color touch panel display of the highly renowned RC9200, all of our remotes feature one button "macro"
operation. Each remote is also pre-programmed to operate an entire Marantz audio video system right out of
the box. If that isn't enough, each remote provides powerful learning and program capabilities to meet and
exceed your systems requirements. Our touch screen remotes provide many enhanced features. The RC9200
includes a large, full-color display (the RC5400 and RC3200 include a B & W display), with an adjustable
contrast dial for personal preference. All of our remotes can be turned on with the manual backlighting button.
The RC9200 displays 256 breathtaking, high-resolution colors and has 8 MB of non-volatile, flash memory
(RC5400 is B&W). The RC3200 features a blue EL backlighting for the LCD, intuitive hard buttons and displays
a resolution of 160 x 100 pixels. The hard buttons are intuitively placed to provide instant access to the most used functions as well as instant
navigation between screens. Each touch screen panel is treated with an excellent anti-glare coating for significantly reduced reflection and optimized
readability under different viewing angles. Want more control? With Windows compatible software from Marantz and your PC, you can incorporate
custom animation, channel icons, custom graphics and even your own photos into the remote.
The family of Marantz remote controls are versatile and expandable. Look for new
and innovative downloads @ www.marantz.com
RC9200 C L
OLOR EARNING
U R C
NIVERSAL EMOTE ONTROL
RX-77 RF E
WITH XTENDER
• Pre-Programmed with Marantz
Codes
• High Resolution (320 x 240) Pixels
LCD Display
• Color Touch Panel
• 8 Mb Memory
• Editable Macros (255 Commands
per Macro)
• Limitless Number of Devices,
Macros, Panels and Button
• Adjustable Brightness
• Large Touch Screen
• Setup Protection
• IR/RF Transmission Capability
• Adjustable Timer for Sleep Mode
• 14 Programmable Direct-Access
Buttons
• Backlighting for LCD and Direct
Access Buttons
• Independent, Adjustable Back
Light Timer for Hard Buttons and
Screen
• IR Sending and Learning Eyes
• Mode, Macro and Device Icons
Can Be Activated/ Deactivated
• 3-Wire (RS232) Serial Port
Connector
• Includes Docking Station and
Rechargeable Batteries
• Includes RX-77 RF Extender
• Learns Codes Via Computer or
Directly Into RC9200 Through IR
Receiving Port
RC9200/RC5400/RC3200/RC1400
RC5400 U
NIVERSAL
R C
EMOTE ONTROL
• Back-lit LCD Touch-screen Display
Wakes up Automatically at the Touch
of a Button
• High Res. (320 x 240) LCD Display
• User Interface is Supplied with Built-
in Templates That can be Easily
Customized Using Edit Software or
by Downloading Designs from the
Internet
• Supplied with Serial Cable, Battery
Pack and Docking Station
• Pre-programmed for all Marantz
Codes. Codes for Virtually all Other
Hi-Fi and AV Products are Easily
Entered
• "Hard" Buttons for Main Functions
• Controls Unlimited Number of
Devices
• Personalized Macros, That Allow
Command Sequences to be
Activated by the Touch of a Single
Button.
• Easily Create and Edit Macros
• Operation via RF (When used with
the Optional RX-77). This Allows for
Operation of Components that are in
a Different Room or not in Line-of-
Sight
• Flash Memory Preserves
Configuration Even Without Batteries
• 8 Mb Memory
RC3200 P
L
EARNING ROGRAMMABLE
T
OUCHSCREEN
R C
EMOTE ONTROL
• Monochrome Touch Screen LCD
• 160 x 100 Pixel Resolution
• 4 Gray Scale Levels
• Digital Contrast Control
• Blue EL Backlighting for LCD and
Hard Buttons
• Pre-Programmed Marantz IR Codes
• 3-Wire (RS-232C)
Connector
• IR Sending LED and Learning Eye
• Learning Frequency up to 56 kHz
and 455 kHz
• 1 MB Non-volatile Flash Memory
Macro, Beep and Timer Function
• Two-way Communication
Capability with Marantz
SR9300V/SR9300/SR9200/SR8300/
SR8200 Home Theater Receivers
RX-77 RF Extender
• Operation via RF. This Allows for Control of Components
that are in a Different Room or not in Line-of-sight
• Supplied with RF to IR Blaster
• Included with the RC9200
• Optional with the RC5400
RC1400 U
L
L
EARNING EARNING
C
ONTROL
• Easy-to-Read LCD Display with
Adjustable Contrast
• Illumination Feature for LCD and
Buttons
• Simplified Programming, Naming
& Control Functions
• Separate Channel Up/Down Keys
Located for Easy, Comfortable
Serial Port
Access
• Large Memory Capacity
• Non-volatile Memory Assures
Programmed Commands will not
be Erased from Memory
• Macro Capability
• Re-naming Feature to Customize
the LCD Labels
• Built-in Commands for Marantz
A/V Components and Other
Major Manufacturers Products
NIVERSAL
R
EMOTE
15
