HOME THEATER Control Panel

Service Manual

TABLE OF CONTENTS

Mechanical Instructions .............................................................

Electrical diagrams ...................................................................

Mainboard component layout ...................................................

Mechanical & Electrical Parts list ..............................................

Mechanical Instructions - Docking station .................................

Electrical diagrams - Docking station ........................................

Charge board component layout ...............................................

Mechanical & Electrical Parts list - Docking station ..................

Mechanical Instructions RX-77 ..................................................

Electrical diagrams RX-77 ........................................................... 10

RX-77boards component layout ................................................. 11

Mechanical & Electrical Parts list RX-77 ..................................... 12

Published by MD 0311 Service RCS

Subject to modification

RC9200

/N1M /T1M /U1G

Page

marantz

TS9200

TS9201

DS9200

RX-77

3104 205 5008-2

Need help?

Do you have a question about the TS9200 and is the answer not in the manual?

Questions and answers

Summary of Contents for Marantz TS9200

Page 1 HOME THEATER Control Panel RC9200 /N1M /T1M /U1G TS9200 TS9201 DS9200 RX-77 Service Manual TABLE OF CONTENTS Page Mechanical Instructions ............. Electrical diagrams ..............Mainboard component layout ........... Mechanical & Electrical Parts list ..........Mechanical Instructions - Docking station .........
Page 2 MECHANICAL INSTRUCTIONS - TS9201 Set Disassembly 1. Remove battery lid 2. Remove battery 3. Remove 2 x screw (Torx screw 2x6) see picture - arrows 6. Put a sharp knife between toppart and bottompart and use this as lever to separate the two parts. see picture Overview snapholes...
Page 3 MECHANICAL INSTRUCTIONS - TS9201 Disassembly LCD & Buttons 1. Remove 5 x screw (Torx screw 2x6 ). see picture - arrows 2. Remove the printboard assy from the toppart assy Disassembly LCD & Mainboard 1a. Desolder the 2 fixation points, bend the lips straight. - arrows B 2a.
Page 4 MECHANICAL INSTRUCTIONS - TS9201 Set Reassembly 1. Put Toppart (*item1) and IR-wind assy (*item 4) together. 2. Place Toppart assy (item1 & item4) upside down. 3. Place upper keymat assy. (*item8) 4. Place LCD keymat assy. (*item9) Reassembly LCD & Mainboard 1a.
Page 5 1001 E3 1020 B2 2001 F2 Micro-Controller 2002 F3 2003 F3 CLKO 2004 H2 BTN_EN2 2005 H3 -IR_VCC 2006 H3 BTN_LGT -DISP_EN 2007 H4 -EL_EN 2008 H4 LCD_VCC A(1:22) 2009 H4 2010 H5 -RESET 2011 H5 -LDS 2031 B3 -UDS 3001 E3 VCC_D1 3002 C10...
Page 6 1002 E11 2067 B9 2068 H2 Color LCD Controller 2069 H3 2070 H3 2071 H3 LCD_VCC VBAT 2072 H4 A(1:22) -LDS 2073 H4 CLKO 2074 H4 -RESET F146 2091 B10 -CSD0 VCC_D2 7066 LT1761 2097 B10 5018 -UDS 2098 B10 Ferrit Bead 3118 E2 D(0:15)
Page 7 2023 B11 2024 B11 2025 A7 Memory 2026 C12 2075 A4 D(0:15) 3104 E8 3105 E8 A(1:22) VCC_C 3116 E5 7067-B 3117 E5 VCC_D5 74LV08PW 3906 E10 FLASH Memory Color VCC_D3 3907 E10 AM29LV641DL or equivallent 8MB FLASH 1 3915 D4 Software Assy A 7006 3916 E4...
Page 8 1003 G5 1026 F12 2027 C12 IR- & Piezo-Circuit 2028 H2 2029 H2 2030 H3 VCC_C 2050 B3 7009-A VCC_C 2099 H3 74HCT153PW 2100 H2 MUX_SELA 2105 G9 2116 E4 MUX_SELB -IRQ7 2118 F12 TOUT1 TIN1 2119 F10 EN MUX 2120 C10 2121 C10 3009 E4...
Page 9 1004 C11 2033 C9 2034 C9 2035 D4 RS232 Interface 2036 D4 2053 C4 2054 D4 2124 E6 3019 B3 3020 B5 3021 C4 3022 C4 3023 D5 VCC_C 3025 D5 3027 D7 3028 E6 VBAT 3029 E5 3030 E9 3031 F9 CONN_GND CONN_RX...
Page 10 1005 A4 1006 B4 1007 B4 Keys & KeyBacklighting 1008 B4 1009 B4 1010 C4 1011 C4 PD(0:7) 1012 C4 1014 G3 1021 C6 1005 1032 1022 C6 MENU Volume Up 1027 C6 PD(0) 1028 B6 1006 1031 HOME Volume Down 1029 B6 1030 B6 PD(1)
Page 11 1018 F2 1019 F11 2042 C3 2065 F3 2078 G3 Power Circuit 2079 E10 2086 D4 2092 G4 2093 D3 2094 E2 2103 B7 2104 B8 2115 B8 VBAT VCC_C 2117 B8 7074 2122 B6 LT1761 F119 2123 B9 3026 B3 3042 B4 SHDN_ 3043 B3...
Page 12 0001 F10 0002 F11 0003 G10 CCFL Backlight Driver 1023 B8 1024 A4 2080 G6 2081 E6 2082 C6 1024 2083 G6 2085 2084 C8 LCD BACKLIGHT CONTACTS 2085 A6 2095 C6 1023 2101 D7 CLQ143 2102 F8 3128 F5 3129 E5 3130 F5 3131 E5...
Page 13 B&W LCD & 23V Step-Up LCD_CONTRAST LCD_VCC 3138 3139 3065 3104 207 5003 bl130-9 dd 19-11-02 2016 B5 2019 D7 2020 D7 Touchscreen DAC 2021 D6 3007 D8 3008 C7 3062 F6 3099 E5 3103 C7 3140 C8 3144 E4 3909 E5 VCC_C 5011 B5...
Page 14 MAIN BOARD - SIDE-A VIEW MAIN BOARD - SIDE-B VIEW 3104 207 5003 3104 207 5003 bl132-2 dd19-11-02 bl132-1 dd19-11-02...
Page 15 (3104 207 13270) (RFTX2 board included) 3104 207 79600 BATTERYLID ASSY TS9201 3104 207 14380 MAINBOARD TS9200 3104 207 79050 BATTERYLID ASSY TS9200 (3104 207 12680) (RFTX2 board included) 3104 207 79060 IR-WIND.+BEZEL SUB ASSY 3104 207 79070 BACKLIGHT BUTT.ASSY...
Page 16 ELECTRICAL PARTS LIST - TS9201 - TS9200 CAPACITORS MISCELLANEOUS 2082 2022 009 00686 TANCAP SM 16V 100U PM20 1001 2422 543 00937 RES XTL SM 32K76 2083 2238 586 15636 CER2 0603 X7R 50V 10N PM10 1002 2422 025 16177 CON H 24P F 0.50 SM...
Page 17 ELECTRICAL PARTS LIST - TS9201 - TS9200 RESISTORS DIODES 3043 2322 702 60224 RST SM 0603C21 220K PM5 6001 9332 153 70215 DIO SIG SM BAV99 3046 2322 702 60153 RST SM 0603C21 15K PM5 6002 9332 153 70215 DIO SIG SM BAV99...
Page 18 RFTX2 BOARD ASSY: TRANSITORS & IC’S 3104 207 11300 - 434MHz used in TS9201 7063 9322 157 52668 TRA POW SM 2SC5001 3104 207 11290 - 418MHz used in TS9200 7064 9336 286 30215 TRA SIG SM BC817-25 7066 9322 171 42685 IC SM LT1761ES5-3.3...
Page 19 DOCKING STATION DS9200...
Page 20 MECHANICAL INSTRUCTIONS Set Disassembly - Docking station 1. Remove the four rubber feet 2. Remove 4 x screw see picture - arrows Overview snapholes 3. Put a sharp knife between toppart and bottompart and use this as lever to separate the two parts. For the correct position of the knife see snapholes in picture Overview disassembled parts - DS9200...
Page 21 CHARGER DIAGRAM BATPLUS 3004 3002 220K 680K BAS16 6012 POWER 330p 3020 3013 2004 7001 TEA1103T Vbat Vstb Rref fast standby load BATPLUS charge current PROTECTION current BD830 1.25/Rref 10uA 40uA 7002 4.25V CHARGE CONTROL 6001 5001 5002 OUTPUT DRIVERS 3021 7003 150u...
Page 22 CHARGER DIAGRAM Vbat 1005 HEC0470 7005 MC34063AD DCOL 8V25 5003 6006 POWER 150u 2007 1002 BYV27-100 TIMC HEC0470 1004 MMBZ15VAL REFERENCE REGULATOR 6011 750mA CIN- 1V25 GND_PRONTO1 GND_PRONTO1 3901 6011 & 2014 2012 & 2010 Close to 1004 Close to 7005 7007 GND_PRONTO1 BC857B...
Page 23 CHARGE BOARD - Component Layout 3104 207 11520 bl132 dd 14-03-02...
Page 24 MECHANICAL & ELECTRICAL PARTS LIST - Docking Station - DS9200 ELECTRICAL PARTS 1004 2422 086 11074 FUSE 750mA 125V UL 3104 207 14340 DOCKING STATION (3104 207 12690) DOCKING STATION Note: Only the parts mentioned in this list are normal service parts For more information: E-mail: erik.gybels@philips.com Overview disassembled parts...
Page 25 ELECTRICAL PARTS LIST- Docking Station - DS9200 RESISTORS MECHANICAL PARTS 3033 2322 730 61362 RST SM 0805 RC11 3K6 3104 207 79240 TOPPART ASSY 3034 2322 730 61222 RST SM 0805 RC11 2K2 3104 204 79250 BOTTOMPART ASSY 3104 204 18540 IR - WINDOW 3035 2322 730 61151...
Page 26 IR-RF RECEIVER RX-77...
Page 27 MECHANICAL INSTRUCTIONS Set Disassembly - IR-IF RECEIVER RX-77 1. Remove the label a little bit 2. Remove screw see picture - arrow 3. Put a sharp knife between top part and window and use this as lever to separate the two parts a little bit. 4.
Page 28 10-1 10-1 0001 F2 0002 F3 1001 E2 1002 B11 2001 F6 RFRX1A/B RF RX1 2002 F5 2003 F6 2004 E2 2005 E1 2006 F7 2007 F10 2008 C6 2010 E4 2011 G5 2013 E10 2014 F9 2015 C6 2016 G6 2017 F10 1002 2018 E8...
Page 29 10-2 10-2 1001 D10 7006 F5 1002 E10 7007 E7 1003 D11 7008 A7 1004 E11 7011 B9 RF-BLASTER 1005 D3 7012 C6 1006 C5 7013 B11 1007 B11 7014-A G3 1008 G6 7014-B G4 12v2 1009 G2 7014-C E4 3053 2003 A4 7014-D E4...
Page 30 11-1 RF RX1 BOARD - Component Layout 3104 207 1131 bl132-1 dd 12-02-02...
Page 31 11-2 PF-BLASTER BOARD - Component Layout 3104 207 1216 bl132-1 dd 11-07-02...
Page 32 12-1 MECHANICAL & ELECTRICAL PARTS LIST - IR RF RECEIVER RX-77 MECHANICAL PARTS 3104 207 14330 RX-77 only for EUROPE and UK version (3104 207 13280) 3104 207 14390 RX-77 only for US version (3104 207 12703) 3104 200 51200 ADAPTOR /N1M - EUROPE 3104 200 51210 ADAPTOR /T1M - UK...
Page 33 12-2 ELECTRICAL PARTS LIST - IR-RF RECEIVER RX-77 MAIN BOARD ASSY RESISTORS MECHANICAL PARTS 3029 2322 730 61479 RST SM 0805 RC11 47R 3030 2322 730 91002 RST SM 0805 JUMP. 0R05 3104 207 78750 TOPPART ASSY 3031 2322 730 61471 RST SM 0805 RC11 470R 3104 207 79140 BOTTOM PART ASSY...
Page 34 12-3 ELECTRICAL PARTS LIST - IR-RF RECEIVER RX-77 FILTERS RFRX1 BOARD ASSY: 3104 207 11320 - used in 434MHz version 5008 2422 535 94152 IND FXD SM 0805 27N 3104 207 11310 - used in 418MHz version 5009 2422 535 94147 IND FXD SM 0805 12N 5009 2422 535 94889...
